Shodex GPC LF-G Operation Manual

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

(Please read this operation manual carefully to achieve the best and consistent column performance for a long time.)
Important Handling Instructions
Caution!
· Please consult the Safety Data Sheet (SDS) of reagents and solvents used with the column
and understand their proper handling methods to prevent potential health hazards or death
from occurring.
· Please wear appropriate personal protective equipment such as lab goggles and gloves
when handling organic solvents and acid and alkaline reagents. Avoid any direct physical
contact to prevent chemical injuries.
Before Using the Column
(1) Please visually inspect the column package and the column surface for any damage.
(2) Please check the product name and serial number (Serial no. or S/N) written on the column package and
adhesive label on the column body.
(3) Please download the Certificate of Analysis (CoA) for the purchased product. The CoA can be downloaded
from Shodex website (https://www.shodex.com/download/). You will be asked to enter the serial number.
1. Introduction
Thank you for purchasing the Shodex product. Shodex GPC LF-604 is a size exclusion chromatography
column used with organic solvents. LF-604 is packed with unique multi-pore gels with a wide pore-size
distribution. It provides a high linear calibration curve without inflection points. It is suitable for molecular weight
distribution analysis of polymers having a broad molecular weight distribution.
2. Column Components
Please refer to the Shodex website: https://www.shodex.com/en/da/01/07.html
3. Column Specifications
Product
Product Name
Code
GPC LF-604
F6021042
F6709621
GPC LF-G
Base Material
: Spherical porous particles of styrene divinylbenzene copolymer
Column Housing : SUS-316
Screw Type
: Internally-threaded type No.10-32 UNF
Shipping Solvent : Tetrahydrofuran (THF)
4. Usable Conditions
4.1 System Settings
Product Name
GPC LF-604
GPC LF-G
Operation Manual
Shodex GPC LF-604
Column Size
(mm)
I.D.
Length
6.0
150
4.6
10
Flow Rate (mL/min)
Recommended
Maximum
0.5
1.0
-
-
Resonac Corporation (https://www.shodex.com/)
Theoretical
Particle
Plate Number
Size (μm)
(Per Column)
6
≥ 9,000
6
(Guard Column)
Reference value only / Measured with polystyrene
*
Maximum Pressure
(MPa/column)
3.5
-
ver.20221202E
Target Molecular
Exclusion
Weight Range
*
300 - 2,000,000
2,000,000
-
Temperature (°C)
Recommended
Maximum
25 - 40
20 - 60
Limit
*
-
1
