Summary of Contents for Genexis FiberTwist PX2120
- Page 1 FiberTwist PX2120 Installation Guide...
-
Page 2: Button Overview
Button overview Unlock button Remove FiberTwist or Blind Cover – press and hold while twisting counterclockwise Reset button (recessed) Reset - press and release Factory reset - press and hold the button until System and Uplink LED start to blink LED dim button Dim LEDs –... -
Page 3: Port Overview
Port overview LED overview Power port System ON/OFF Green – system ok TV port LAN port button Green (blinking) – booting Red – system or booting failure Red (blinking) - insufficient PON signal Off – power off Uplink Green – link ok Green (blinking) –... - Page 4 1. Press and hold the unlock button (see button overview). Box contents 2. Rotate the Blind Cover counterclockwise till it blocks. • Genexis FiberTwist (active Important: Instructions need 3. Remove the Blind Cover from the baseplate (FTU) by pulling device) to be followed precisely it towards yourself.
- Page 5 Remove dust cap Twist! 1. Take the FiberTwist out of the box. 1. Place the FiberTwist on the FTU as shown in the picture below, 2. The dust cap is connected to the red string in a 30–degree angle. located on the rear of the FiberTwist. 2.
-
Page 6: Safety Guidelines
3. Connect the supplied power adapter to the FiberTwist and plug the product, which might not be covered by Genexis warranty. adapter into a power socket. 4. Press the ON/OFF button to power on the device. - Page 7 • can expose you to electrical shock. Genexis recommends that only a trained • Keep your product away from radiators and heating sources and do not block technician services components inside these compartments. cooling vents. Prevent installing the product in direct sunlight. Blocking the •...
-
Page 8: Supplier's Declaration Of Conformity
Supplier’s Declaration of Conformity 47 CF $ 2.1077 Compliance Information Responsible Party – U.S. Contact Information Genexis Broadband, LLC, 228 E 45th St, Ste 9E, New York, NY 10017 Info.na@genexis-broadband.com FCC Compliance Statement The FiberTwist-PX2120-US-1 has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 9 Revision 1.0 - April 2025 - Copyright © 2024 Genexis Netherlands B.V. All rights reserved. Multiple languages of this document and additional product information are available on https://genexis.eu/product/fibertwist-PX2120/ Genexis assumes no responsibility for any inaccuracies in this document. Genexis reserves the...
