- Page 1 Networked Instructional Audio System User Manual...
-
Page 2: Table Of Contents
Media Connector Controls and Indicators Safety Warnings and Certifications Media Connector Set Up and Operation System Components Connecting Media Connector to Audio System Specifications Output Audio to Assistive Listening Device (ALD) Pairing Topcat Cascadia to Media Connector Media Connector: Audio Integration Wall Plate... -
Page 3: Overview
When disposing of the battery pack, comply with local comme dispositif de déconnexion, il doit rester facilement ordinances or regulations. utilisable après l’installation. 13. CAUTION: Risk of explosion if battery is replaced by any battery other than Lightspeed Part # L3.7V... - Page 4 USE A LICENSED ELECTRICIAN FOR POWER CONNECTIONS. constitute a risk of electric shock. Topcat Cascadia system uses standard 100 – 240VAC power. Obtain the services of a licensed electrician when supplying and connecting power to the ceiling enclosure. BE SURE The exclamation point within an equilateral electrical installation complies with local building codes.
-
Page 5: System Components And Unpacking
Power Supply NOTE ON PAIRING: Topcat Cascadia and any wireless components (microphones, Media Connector) are pre-paired at the Lightspeed factory as required for proper operation. If paired components are separated and swapped during the installation process, they must be re-paired. -
Page 6: Optional Components
Optional Components Optional equipment which may be part of your Topcat Cascadia system Power Status Media Media Connector Connector Push Audio Audio Tone Level Input Output Media Connector Wallplate Sharemike and Power Adapter Student Microphone... -
Page 7: Topcat Cascadia Controls
Topcat Cascadia Controls (Inside Speaker Door) Mounted inside the Topcat Cascadia is a Cascadia C25. To access the controls and connections of the C25 system, push the two sliders to the unlocked position and open the STATUS POWER LIGHT LIGHT SENSOR speaker door. -
Page 8: C25 Controls And Indicators
C25 Controls and Indicators FRONT PANEL POWER LIGHT AUDIO INPUT VOLUME SELECTOR: Selects Audio Input as White light: Power on the mode for the adjustment knob (3) for the audio sources connected to the audio inputs on the back of the C25. STATUS LIGHT: Microphone link and pair indicators. -
Page 9: Back Panel
REMOTE LED: Connection for external LED and IR sensor S/PDIF RCA: Digital Audio Input and Output to connect one C25 to another. when C25 is installed in a Topcat Cascadia SPEAKER OUTPUTS: This Euroblock connector is used to PAGEFIRST INPUT: Connect the input from the optional connect the C25 to the loudspeaker(s). -
Page 10: Clearmike Controls And Connections
Clearmike Controls and Connections POWER/MUTE BUTTON: Press and hold 1 second to power on. Press and hold for 2 seconds to power off. Tap to mute or talk. Press and hold for 5 seconds to initiate pairing. IR TRANSMITTER: For pairing to base unit. TALK/MUTE LIGHT: See page 10 for light color descriptions. - Page 11 Microphone Lights LEFT LIGHT / RIGHT LIGHT OFF / OFF: Mic off or no live link with base SOLID WHITE / OFF: Mute, live link with base SOLID BLUE / OFF: Talk ANY COLOR / BLINKING RED: Low Battery TALK/MUTE LIGHT POWER STATUS LIGHT BLUE/WHITE ALTERNATING / OFF: Pairing OFF / BLINKING ORANGE: Firmware update in progress...
- Page 12 Clearmike Display BATTERY INDICATOR (Full, half, empty) Student Help MUTE PROGRAMMABLE Help INDICATOR/ BUTTON 1 LABEL VOLUME PROGRAMMABLE Mode Call Call MIC NUMBER BUTTON 2 LABEL (M1 OR M2) STUDENT EXTERNAL MIC MODE DETECTION If two Clearmikes are paired with a The 3.5mm audio jack on the C25, one of the microphones can microphone can be used with an...
-
Page 13: Microphone Cradle Charger
Microphone Cradle Charger DC POWER PORT: Connect the 5V/1.0A DC power cord... -
Page 14: Set-Up & Operation
Clearmike will last for up to 8 hours of use. If microphones are used daily, they should be charged each night. Replacement lithium polymer battery packs may only be purchased through Lightspeed (part # L3.7V). charging in progress charging complete... -
Page 15: Setting Up The Clearmike
Setting Up the Clearmike Once the Clearmike is charged, follow these steps for use. Remove the Clearmike from the charger and put it on by connecting the magnetic clasps behind your neck. Adjust the lanyard so that the top of the Clearmike aligns with the collarbone. - Page 16 • Place the Clearmike into the cradle charger and make sure the power supply is plugged in to an electrical outlet. • Topcat Cascadia will not power down if it has a live link to a microphone. After 60 minutes of audio inactivity, the C25 will automatically power down.
-
Page 17: Network Integration
Network Integration IP-Based PBX System Cascadia Web IP-Based Paging/ Console Intercom System For call integration TEACHER MICROPHONE Lightspeed Access transmission protocol TOPCAT CASCADIA... -
Page 18: Using An Alert Notification
Using an Alert Notification The Topcat Cascadia can integrate with some IP based alert notification systems, enabling the Clearmike to send an alert through the school’s network. This will cause the alert notification system to perform a prescribed action, such as notifying the appropriate parties of a classroom alert. -
Page 19: Placing A Call
Placing a Call The Topcat Cascadia can integrate with some IP based PBX systems to enable calls to be placed from the Clearmike. All Topcat Cascadia systems on the network will call the same phone number, determined by the school. -
Page 20: Pairing Your Clearmike
Topcat Cascadia will also start flashing blue and white. TALK / MUTE LIGHT When complete, the Status light on the Topcat Cascadia will turn blue, the Talk/Mute light on the microphone will be white, and the display on the microphone will say... -
Page 21: Using Your Microphone As A Wireless Audio Link
You can connect your 2nd microphone to your computer’s USB port to enable a wireless 2-way audio link. SEND AUDIO FROM THE COMPUTER to the Topcat Cascadia to ensure all audio from the computer (videos, video conferencing, audio books, music, etc) can be played through the Lightspeed Topcat Cascadia system and speakers. -
Page 22: Audio Integration
Audio Integration INTERACTIVE DISPLAY Audio Out TEACHER MICROPHONE AUDIO SOURCE Audio Out Lightspeed Access transmission protocol Audio In Audio Out Audio In TOPCAT CASCADIA... -
Page 23: Analog Control Features
Analog Control Features The C25 connects and responds to several important third-party life safety solutions. 1. Input Priority 2. PageFirst 3. Relay Input 4. Alert Notification MUTES CL A S SR O OM AUDIO S YS TEM MUTES CL A S SR O OM AUDIO S YS TEM MUTES CL A S SR O OM AUDIO S YS TEM INITI ATES A LER T WITH CLE A RMIK E When an audio source is connected to... - Page 24 Installing PageFirst Sensor (optional) The Topcat Cascadia can interface with an independent classroom paging system. When a page is broadcast, all audio from the system is muted, ensuring important school-wide messages are not missed. Please note that PageFirst is not compatible with telephone or IP-based paging systems.
-
Page 25: Optional Accessories
MUTE/TALK STATUS LIGHT Blue: solid = Talk White: solid = Mute MICROPHONE VOLUME UP/DOWN USB INPUT: Connect audio source to send to Topcat Cascadia. USB input can also be used for charging. IR TRANSMITTER: For pairing to base unit AUDIO INPUT: Plug a laptop or other audio device into this jack to BATTERY wirelessly transmit the audio signal to be played through the system. -
Page 26: Sharemike: Charging
It takes 5-6 hours to fully charge the battery. The light will turn green when charging is complete. PLEASE NOTE: Topcat Cascadia and microphone(s) are paired together at the factory and all components should be kept together as a system. -
Page 27: Sharemike: Initial Set-Up
Sharemike: Initial Set-Up POWER LIGHT ON ENSURE TOPCAT CASCADIA IS POWERED ON The white light on the speaker panel of Topcat Cascadia will glow. TURN ON THE SHAREMIKE • Press and hold the power button until the LED lights. POWER BUTTON •... -
Page 28: Pairing Your Sharemike
Pairing your Sharemike Your system is shipped with microphones and base units pre-paired for quick and easy use. If for any reason you need to pair new components, follow this pairing process: PLEASE NOTE: All microphones should be out of the charger while pairing. STATUS LIGHT SENSOR... -
Page 29: Media Connector Controls And Indicators
Media Connector Controls and Indicators FRONT PANEL POWER LIGHT AUDIO INPUT VOLUME SELECTOR: Selects Volume as the mode White light: Power on for the adjustment knob (2) for the audio sources connected to the audio inputs on the back of the Media Connector. POWER BUTTON / VOLUME ADJUSTMENT: Press this button to turn the system power on or off. - Page 30 Media Connector Controls and Indicators (Optional) BACK PANEL AUDIO INPUTS: 3.5mm stereo connectors for connecting classroom audio sources to be played through audio system. AUDIO OUTPUTS: 3.5mm stereo connectors for connecting to an assisted listening device (ALD) or to a computer for recording. USB INPUT: Plug the USB-C end of the power cable into this USB port on the Media Connector.
-
Page 31: Media Connector Set Up And Operation
• Do not enclose in a metal cabinet or in a location where the signal will be obstructed. NOTE: The Media Connector does not require a direct line of sight to Topcat Cascadia. However it functions best when no obstructions are between the two devices. CONNECT TO POWER... -
Page 32: Connecting Media Connector To Audio
V / . A COMPUTER SETTINGS 3.5mm cable Once connected, open computer sound setting to select “Lightspeed Audio” as the microphone and speaker. SETTING THE VOLUME LEVELS For recording, or to interface with an Assistive Listening Device, connect a 3.5mm cable to the Audio Output of the Media Connector to the microphone input on the device. -
Page 33: Output Audio To Assistive Listening Device (Ald)
Output Audio to Assistive Listening Device (ALD) Press the Audio Output Selector first, then turn the volume control on the front panel all the way down (fully counterclockwise). Determine the type of audio input jack on the ALD as manufacturers’ products differ in connector size and shape. Many require a 3.5 mm to 3.5 mm patch cable (part# MSC3535, Audio Inputs Audio Outputs... -
Page 34: Pairing Topcat Cascadia To Media Connector
Pairing Topcat Cascadia to Media Connector (Optional) Your system is shipped with microphones and base units pre-paired for quick and easy use. If, for any reason, you need to pair new components, follow this pairing process: From a powered off state,... -
Page 35: Media Connector: Audio Integration
Media Connector: Audio Integration INTERACTIVE DISPLAY Video In TOPCAT CASCADIA HDMI Out Audio Out LAPTOP TEACHER CLEARMIKE Audio In Lightspeed Access transmission protocol Power Status Media Media Connector Connector Push Audio Audio Tone Level Input Output MEDIA CONNECTOR... -
Page 36: Wall Plate
Wall Plate AUDIO INPUT • 3.5mm stereo connector for connecting classroom audio sources to be played through audio system. AUDIO OUTPUT • Audio Output: 3.5mm stereo connector for connecting to an assisted listening device (ALD) or to a computer for recording. USB-C •... -
Page 37: Software Operation
Software Operation Cascadia Web Console HEADLINE The Cascadia Web Console is a web interface for the network software that monitors all the C25 bases on a network. Installing the Cascadia Web Console server software For installation instructions see “Cascadia Software Installation Guide”... -
Page 38: Dashboard
Dashboard The dashboard is the default page for the web console. When a C25 base is connected to the network, it will show up in the dashboard table. (See following page for definitions) Location of Base Product Base Name Seria Number Base Call Date... - Page 39 Dashboard Definitions Location: Alphanumeric user defined location of the base. New bases on the network will have no location data. Product: Product model number Base Name: Alphanumeric user defined name of the base. New bases on the network will have no name data. If left blank this field will default to the location data.
-
Page 40: Base Details: Status
Base Details: Status NOTE: Double clicking on a base in the dashboard brings up a details page for that base. Name: Field to enter name for the base. Location: Field to enter location of the base. Required field for alerts. Dashboard: Base status shown on dashboard Network: State of network connectivity Emergency: State of emergency alert... -
Page 41: Base Details: Paired Devices
Base Details: Paired Devices Paired Devices Lists all the devices that are currently paired with the base. These devices include the Clearmike, Sharemike, and Media Connector (MCN). Serial Number: Serial number of device Type: Device type Connected: Status of wireless connection between the device and the base. -
Page 42: Base Details: Audio Settings
Base Details: Audio Settings The audio settings for the base can be adjusted from either the front panel on the base or the Audio portion of the Base Details page. Click the edit icon to adjust the audio settings. When using the PageFirst sensor, adjusting the sensitivity of the system can be done in the Base Details page. -
Page 43: Base Details: Status History
Base Details: Status History The base details page includes a Status History that shows displays the last eight events associated with the base. All events for all bases are saved in a global log file that can be exported using the Logs menu button. Double clicking an event will bring up the Log Entry Details. -
Page 44: Maps
Maps The Cascadia Web Console has a map feature that can be set up to give a visual representation of the Base Status from the Dashboard. If alerts have been set up in the Cascadia Web Console, the status of the alerts will also be shown on the map. For details on how to set up the map, see the “Cascadia Software Installation Guide”. -
Page 45: Logs
Logs Logs for all the bases on the network are saved as a system log. As a default, the settings for events to be logged are set to the maximum. This system log can be downloaded by clicking the “Download System Logs” button. LOG LEVEL: Chose the level of detail included in log events. -
Page 46: Firmware: Download
Firmware: Download Firmware updates can be downloaded directly to the Cascadia Web Console using an internet connection or can be manually loaded. Firmware files for the C25, Clearmike, Sharemike, and Media Connector are included in a firmware bundle. -
Page 47: Firmware: Update
Firmware: Update Applying a firmware bundle update to a base will also update all paired devices. Bases can be updated individually or in bulk using the check box. The devices that will be updated are highlighted in yellow. -
Page 48: Programming: Stand Alone
Programming: Stand Alone The programming web page has options to pick an integration partner and to program the buttons on the paired Clearmike. select an integration partner The Standalone selection can be used for generic integrations if a building is equipped with an alert notification system. The Alert Button can be programmed to control the contact closure on the rear panel of the C25, which external systems can use to perform a prescribed action, such as notifying the appropriate parties of a classroom alert. -
Page 49: Programming: Integration Partners
Programming: Integration Partners Options other than Standalone For options other than Standalone, the integration is handled through the network. For details on how to set up the network integration with various partners, see the “Cascadia Software Installation Guide”. Program buttons on the Clearmkie The button programming options control what is displayed on the microphone screen and the commands sent over the network. -
Page 50: Sip Calling
SIP Calling Use the SIP Calling web page to integrate with a school’s phone system to enable SIP calls. Follow the phone system instructions on how to register a third-party SIP device. Double click on a base to edit the individual base SIP settings. SIP address to call IP address of phone server Protocol type: TCP or UTP... -
Page 51: Ldap
LDAP Use the LDAP web page to integrate with a school’s LDAP system. SERVER: IP address or system name of LDAP server. SERVER PORT: Port number to communicate with LDAP server. ADMIN DN: Distinguished name of LDAP account with read access. ADMIN PASSWORD: Password for above LDAP account. -
Page 52: Maintenance And Troubleshooting
MAINTENANCE & TROUBLESHOOTING Clearmike Battery Replacement Battery part #L3.7V Push down on the latch and carefully pull the battery pack away from the Clearmike. Insert new battery pack as shown and make sure the latch is secure. Place the Clearmike in a cradle charger to charge the battery pack. -
Page 53: Sharemike Battery Replacement
Sharemike Battery Replacement Battery part #L3.7V Push down on the latch and carefully pull the battery pack away from the Sharemike. Insert new battery pack as shown and make sure the latch is secure. BATTERY Place the Sharemike in a cradle charger to charge REMOVAL the battery pack. -
Page 54: Troubleshooting
• Slowly turn up the volume level while talking into the microphone. SOLUTION: Follow these steps to ensure the system is ready to use. If you still have questions after reviewing these instructions, call Lightspeed • Power cycle the microphone using either the Power/Mute button or by placing Technical Services at 800.732.8999, 5am–5pm, PST. -
Page 55: Tips For Optimum Audio Performance
Tips for Optimum Audio Performance • Speak in a natural voice. A normal conversational speech level will provide an adequate signal. It is not necessary to increase the intensity of your voice— the audio system provides adequate amplification (approximately 5–10 dB) above ambient room noises. -
Page 56: Warranty, Safety & Specifications
(5) years, beginning at the date of the purchase invoice. If such malfunction occurs, the product will be repaired or replaced (at Lightspeed’s option) without charge during the warranty period. -
Page 57: Safety Warnings And Certifications
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND (servicing) instruction in the literature accompanying this product. THE HAZARDS INVOLVED. USE A LIGHTSPEED SUPPLIED BATTERY ONLY CERTIFICATIONS This product is listed to UL standards and requirements for electrical safety by Underwriters Laboratories Inc. -
Page 58: Précautions De Sécurité Et Certifications
Européenne suivantes : 2004/108/ EC Electromagnetic Compatibility (EMC) and 2006/95/ EC Low Voltage Directive (LVD). Lightspeed Technologies a lancé un programme de recyclage de produits en Europe conformément à la directive de l’Union Européenne 2002/96/CE relative aux déchets d’équipements électriques et électroniques (directive «... -
Page 59: Canada, Industry Canada (Ic) Notices
Canada, Industry Canada (IC) Notices English This device complies with Industry Canada license exempt RSS standard(s). This Class B digital apparatus complies with Canadian ICES-003 and CAN ICES-3(B)/ NMB-3(B).Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. -
Page 60: Fcc Notice To User
FCC Notice to User French This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: NOTE IMPORTANTE: Pour se conformer au règles d’exposition des ondes RF par la FCC, This device may not cause harmful interference; and la (ou les) antenne(s) utilisée(s) par ce transmetteur doivent être installées de façon à... -
Page 61: Rf Radiation Exposure Statement
NOTICE FOR USB NOTE: Lightspeed is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. -
Page 62: Eu Declaration Of Conformity
Directive based on its design and type, as brought into circulation by us. In case of alteration of the system, not agreed upon by us, this declaration will lose its validity. Products: Redcat, Topcat Cascadia, 975, Access Link, Flexmike, Sharemike, Pod, Activate Station, Media Connector, TCQ2, DRQ, Mobile Connector Model Numbers:... -
Page 63: System Components
System Components STANDARD COMPONENTS OPTIONAL ACCESSORIES Topcat Cascadia all-in-one ceiling-mount wireless audio base station Sharemike handheld transceiver with battery pack 24V2.5-NA 24V/2.5A power supply for C25 L3.7V Lithium Polymer rechargeable battery pack for Sharemike FSCC USB C Transceiver cradle charger, power supply... -
Page 64: System Specifications
System Specifications TOPCAT CASCADIA CLEARMIKE Product Description All-in-one Instructional Audio System Description Pendant-style transceiver Wireless Communication Access Technology (1.9 GHz) Earbud Lanyard Magnetic clasp with integrated earbud Frequency Response 20 Hz - 20 kHz Audio Out, 150 Hz - 6.5 kHz Wireless Wireless Communication Access Technology (1.9 GHz) - Page 65 Access to powerful in-the-moment insights to the learning process. Our audio and video solutions improve student engagement, enable teachers to activate small groups, and encourage collaboration. 11509 SW Herman Road Tualatin, Oregon 97062 Toll Free: 800.732.8999 Phone: 503.684.5538 Fax: 503.684.3197 lightspeed-tek.com MN0725US01-1...
