SMC Networks LECP1 Operation Manual

Transfer procedure
Hide thumbs Also See for LECP1:

Advertisement

Quick Links

Transfer Procddure
LECP1/LECP2
LECP1
LECP2
Please use this instruction manual together with the controller (LECP1, LECP2,
JXC51/61) instruction manual and controller setting software (ACTController2).
機 種 名 称
型式 / シリーズ
JXC51/61
No. DOC1127384
(NN73917700)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LECP1 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks LECP1

  • Page 1 No. DOC1127384 機 種 名 称 Transfer Procddure 型式 / シリーズ LECP1/LECP2 LECP1 JXC51/61 LECP2 Please use this instruction manual together with the controller (LECP1, LECP2, JXC51/61) instruction manual and controller setting software (ACTController2). (NN73917700)
  • Page 2: Table Of Contents

    1. Safety Instructions ..............2 2.Transfer Procedure ............4 2.1 Overview ....................4 3.Step1 Change the LECP1/LECP2 mode of the JXC51/61 4 3.1 Preparation ................... 4 3.2 How to change LECP1/LECP2 mode ........4 4.Step2 Write Setp date to the JX51/61 ....5 4.1...
  • Page 3: Safety Instructions

    Controller 1. Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4: Limited Warranty And Disclaimer/Compliance Requirements

    Controller Safety Instructions Caution SMC develops, designs, and manufactures products to be used for automatic control equipment, and provides them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not allowed. Products SMC manufactures and sells cannot be used for the purpose of transactions or certification specified in the Measurement Act of each country.
  • Page 5: 2.Transfer Procedure

    Figure 1. System configuration diagram SIk) 3.2 How to change LECP1/LECP2 mode Please refer to "How to change between LECP1 mode and LECP2 mode" on page 40 of the ACTController2 instruction manual (for JXC51/61 controllers equipped with LECP1 and LECP2 modes). - 4 -...
  • Page 6: 4.Step2 Write Setp Date To The Jx51/61

    The remaining connections will be the same as in "3.1 Preparation." 4.2 Writing setp data Since LECP1/LECP2 cannot output or save step data externally, it is necessary to register and write new step data to JXC51/61. For the setting values for each number of the LECP1/LECP2 forward/reverse speed switch and forward/reverse acceleration switch, please refer to the LECP1 instruction manual, "10.
  • Page 7: 4.3 Step Data Writing Completed

    (2) LECP2 mode Enter the step data "Speed", "Position", "PushingF", "TriggerLV" and "PushingSp" values, and click the "Write step data" button. -Stroke learning- Stroke learning is performed by clicking the "Stroke learning" button in the step data window in test mode. If you are not using the controller setting software (ACTController2), you can perform it by inputting the STUDY input signal (terminal number: A9) after powering on.
  • Page 8: Step3 Change The Product Installation

    5. Step3 Change the product installation 5.1 Product dimensions and changes There is no compatibility between the LECP1/LECP2 and JXC51/61 product exterior dimensions and installation dimensions. Table 1. Product appearance dimension comparison LECP1/LECP2 external dimensions (1)Screw mounting(LECP1/2□□-□) (2)DIN rail mounting (LECP1/2□□D-□) Figure 4.
  • Page 9 (2) (JXC518□-□、JXC618□-□) DIN rail mounting Figure 5. JXC51/61 external dimensions - 8 -...
  • Page 10: Step4 Change The Power Supply Wiring

    6. Step4 Change the power supply wiring 6.1 Power supply wiring method and changes The LECP1/LECP2 power cable (LEC-CK1-1) will be changed to a JXC51/61 power plug (JXC-CP2). Due to a lack of compatibility between parts, the power supply will need to be rewired.
  • Page 11: Step5 Change The Io Cable Wiring

    7.1 The IO cable wiring method and changes The IO cable for LECP1/LECP2 (LEC-CK4-*) will be changed to the IO cable for JXC51/61 (LEC-CN5- Since there is no compatibility of parts, it will be necessary to rewire the IO cable.
  • Page 12 (Reference) (1) IO cable wiring example for JXC51/61 in LECP1/LECP2 mode Figure 12. LECP1/LECP2 mode wiring for JXC51/61 (2) Additional information about the *ALARM output signal The *ALARM output signal is a b-contact type. The *ALARM output signal turns ON when no alarm has occurred and the servo is ON.
  • Page 13: Step6 Change The Actuator Cable Wiring

    8. Step6 Change the actuator cable wiring 8.1 Actuator cable wiring method and modifications There are no changes to the actuator cables for LECP1/LECP2 and JXC51/61 and they can be used in common. Revision history First Edition [June 2025] https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
