3x1 Wallplate Transmitter Switcher with HDMI and VGA Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance. -
Page 3: Safety Precautions
3x1 Wallplate Transmitter Switcher with HDMI and VGA SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ... -
Page 4: Table Of Contents
3x1 Wallplate Transmitter Switcher with HDMI and VGA Table of Content 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ...................... 2 2. Specification ....................... 3 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................5 3.3 Side Panel ...................... -
Page 5: Product Introduction
3x1 Wallplate Transmitter Switcher with HDMI and VGA 1. Product Introduction Thanks for choosing the TPUH408TV-EU 3x1 Wallplate Transmitter Switcher, which is designed to switch and extend HDMI or VGA input signal to far-end display device, and the transmission distance is up to 131ft/40m at 4K and 229ft/70m at 1080P video by using a single CATx cable. -
Page 6: Package List
3x1 Wallplate Transmitter Switcher with HDMI and VGA 1.2 Package List 1x TPUH408TV-EU 1x 2-pin Terminal Block 2x 3-pin Terminal Blocks 1x Power Adapter (24V 1.25A) 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the... -
Page 7: Specification
151mm x 80mm x 39mm Net Weight 245g Note: The TPUH408TV-EU also can be powered from the HDBaseT receiver which supports 48V PoH. The CAT6A cable is recommended when the TPUH412R HDBaseT receiver is chosen to be used with the TPUH408TV-EU wallplate transmitter switcher. -
Page 8: Panel Description
3x1 Wallplate Transmitter Switcher with HDMI and VGA 3. Panel Description 3.1 Front Panel ① IR: Built-in IR sensor to receive IR signal from IR remote to control display. ② HDMI IN 1: Type-A HDMI port to connect HDMI source. ③... -
Page 9: Rear Panel
3x1 Wallplate Transmitter Switcher with HDMI and VGA 3.2 Rear Panel 2 3 4 ① HDBT (POC): RJ45 HDBaseT output port to connect to the HDBT IN port of the receiver by a CATx cable. It supports 24V-48V PoC to enable the switcher can be powered from a compatible receiver. -
Page 10: Side Panel
3x1 Wallplate Transmitter Switcher with HDMI and VGA 3.3 Side Panel ① FIRMWARE: Micro-USB port for firmware upgrade. -
Page 11: System Connection
3x1 Wallplate Transmitter Switcher with HDMI and VGA 4. System Connection Usage Precautions: Make sure all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ... -
Page 12: Button Control
3x1 Wallplate Transmitter Switcher with HDMI and VGA 5. Button Control 5.1 Source Switching 1) Press the SOURCE AUTO button to switch to next source device, and then the corresponding input LED will turn green. 2) Press and hold the SOURCE AUTO button at least 3 seconds to enable auto switching mode, and it abides by the following principles: New Input ... -
Page 13: Rs232 Control
3x1 Wallplate Transmitter Switcher with HDMI and VGA 6. RS232 Control 6.1 RS232 Connection According the RS232 control mode, there are two types of RS232 connection can be selected. ① When only control the local switcher, connect a control device (e.g. PC) to the RS232 port of the switcher, the connection diagram shown as below: ②... -
Page 14: Rs232 Control Software
Uninstallation: Delete all the control software files in corresponding file path. Basic Settings: Connect TPUH408TV-EU with all input devices and output devices needed, then to connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. -
Page 15: Rs232 Command
3x1 Wallplate Transmitter Switcher with HDMI and VGA 6.3 RS232 Command Communication protocol: RS232 Communication Protocol Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none 6.3.1 Device Control Command Function Feedback Example 50617% Restore factory default. FACTORY RESET 50698% Software upgrade. -
Page 16: Vga Audio Control
3x1 Wallplate Transmitter Switcher with HDMI and VGA 50720% 1920x1080 @50Hz. RESOLUTION: 1920x1080 50Hz 50721% 1920x1080 @60Hz. RESOLUTION: 1920x1080 60Hz 50722% 1920x1200 @60Hz. RESOLUTION: 1920x1200 60Hz 50723% 3840x2160@30Hz. RESOLUTION: 3840x2160 30Hz 6.3.4 VGA Audio Control Command Function Feedback Example 50726% Mute VGA Audio Input. -
Page 17: Cec Control
3x1 Wallplate Transmitter Switcher with HDMI and VGA Enable EDID user-defined mode. Uploading the user-defined EDID 50781% EDID: USER USB UPGRADE file by Micro-USB port within 10 seconds. 50782% Invoke the user-defined EDID. EDID: USER 50783% EDID bypass. EDID: BYPASS EDID:1920x1200@60, 2CH EDID:1360x768@60 EDID:1080P, 2D 2CH... -
Page 18: Button User-Defined
3x1 Wallplate Transmitter Switcher with HDMI and VGA 6.3.8 Button User-defined Press the DISPLAY ON/OFF button can turn on/off the display. If the incompatible display device needs to be used, the DISPLAY ON/OFF button can be defined to send control characters by following the below command format. Command Function Command Example... -
Page 19: Panel Drawing
3x1 Wallplate Transmitter Switcher with HDMI and VGA 7. Panel Drawing 151.00 mm 70.00 mm 3.00 mm 39.10 mm 108.60 mm lower level 39.1mm 26.2mm... -
Page 20: Troubleshooting & Maintenance
3x1 Wallplate Transmitter Switcher with HDMI and VGA 8. Troubleshooting & Maintenance Problems Potential Causes Solutions Color losing or no video signal output in HDMI display. The connecting cables No HDMI signal output in Check whether the cables may not be connected the device while local are connected correctly correctly or it may be... -
Page 21: Customer Service
3x1 Wallplate Transmitter Switcher with HDMI and VGA 9. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
