Speck Pumpmeister PM10 Operating Instructions Manual

Advertisement

Quick Links

Operating Instructions
SPECK "Pumpmeister" Pumps and Pump Units
PM10 PM15 PM20 PM30 FPM80 FPM100 FPM150
Each individual pump undergoes a lengthy run on our test stand before it leaves our works. The assembled pump
units comply with the EC guidelines for machinery, 89/329/EWG, Annex II, A.
1.1 Application
SPECK piston pumps are used for pumping drinking and general domestic water in -
• Single / Multi-storey Houses • Agriculture/Farming • Gardens/Green Houses • Ships • Industry
Standard piston pumps and pump units are not to be used for conveying any medium other than water, except if
written consent is given by the manufacturer. Special versions are built by us for the pumping of other media.
1.2 Economy
Speck piston pumps save energy. They only require 0.25 kW/h to pump 1 cbm of water. The comparatively high price
of a piston pump is rewarded in time by its low power consumption and long-working life.
1.3 Accessories
A belt-guard is available for V-belt drive. The law on technical appliances obligates the manufacturer to always supply
a belt-guard, even with pumps without motors. Please pay attention to this when ordering.
Declaration of Conformity
that the following pump units:
"Pumpmeister" Pump with Motor:
PM10
PM15
PM20
PM30
Fresh Water Pump Unit:
FPM80
FPM100
FPM150
Country of Origin: Federal Republic of Germany
S P E C K - K O L B E N P U M P E N F A B R I K
O t t o S p e c k G m b H & C o . K G · P . O . B o x 1 2 4 0 · D - 8 2 5 2 3 G e r e t s r i e d
D1507 1 0904L
Spare Parts List
1. In General
We herewith declare
Pump Units:
PM10/100L Pressure Tank
PM10/150L Pressure Tank
PM15/100L Pressure Tank
PM15/150L Pressure Tank
PM15/200L Pressure Tank
PM20/150L Pressure Tank
PM20/200L Pressure Tank
PM20/300L Pressure Tank
PM30/300L Pressure Tank
comply with pertinent stipulations as per:
EC Machine Guidelines 89/392/EWG
Applied compatible standards:
EN 809
EN 292 T1
EN 292 T2
Electromagnetic Compatibility: 89/336/EWG
Applied compatible standards:
EN50 081-1
EN50 082-2
Use of Electrical Equipment within specified
Voltage Limits: 73/23/EWG
Applied compatible standards:
EN60 335-1
EN60 335-2-51
T e l . ( 0 8 1 7 1 ) 6 2 9 3 0 · T e l e f a x ( 0 8 1 7 1 ) 6 2 9 3 9 9
Declaration of the Manufacturer
that the following
Pumps without motor:
PM10
PM15
PM20
PM30
ppa. ........................................
(Technical Director)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pumpmeister PM10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Speck Pumpmeister PM10

  • Page 1 Special versions are built by us for the pumping of other media. 1.2 Economy Speck piston pumps save energy. They only require 0.25 kW/h to pump 1 cbm of water. The comparatively high price of a piston pump is rewarded in time by its low power consumption and long-working life.
  • Page 2 1.4 Technical Data and Dimenions Pumpmeister Model PM10 PM15 PM20 PM30 Flow Rate 1000 1500 2000 3000 Water Head 40/60 40/60 40/60 40/60 normal/maximum Motor Performance 0.25 0.37 0.37 0.55 at 40m Motor Performance 0.37 0.55 0.55 0.75 at 60m No.
  • Page 3 1.5 Spare Parts Section 1.51 Spare Parts List Part No. Description PM10 PM15 PM20 PM30 Part No. Description PM10 PM15 PM20 PM30 Crankcase 01.0033 01.0336 01.0151 01.0152 Hexagon Screw 21.0290 21.0256 Gear Cover 03.0096 03.0120 03.0097 Motor Rocker Assy 00.2441 00.2442 00.2443 Valve Casing Assy w.
  • Page 4 1.52 Exploded View...
  • Page 5 2. Safety This Operation Manual gives basic instructions which are to be observed during installation, operation and maintenance of the pump. It is therefore imperative that this manual be read by the responsible personnel/operator prior to assembly and commissioning. It is always to be kept available at the installation site. It is not only the general safety instructions contained under this main heading `Safety` that are to be observed, but also the specific information provided under the other main headings.
  • Page 6: Transport And Storage

    4. Description 4.1 “Pumpmeister” SPECK piston pump series “Pumpmeister” have drop-forged crankshafts in silent running ball bearings, a crank mechanism which has proved itself over and over again. When turned in the correct direction, the gear is lubricated by an oil-dip bath with flooded crosshead. Suction and discharge connections are on the valve casing and are interchangeable.
  • Page 7 5. Set-Up and Installation (to be done only by skilled persons) 5.1 Pump Unit The complete pump unit with horizontal pressure tank is supplied ready assembled. A special foundation is not necessary. The tank can be fixed to the foundation by 4 spacer blocks. The room must be frost-proof and dry.
  • Page 8 (Does not apply to units with horizontal tanks) To make installation easier, the suction and discharge sides of SPECK “Pumpmeister” pumps can be interchanged by converting the suction and discharge valves. This often saves inconvenient installation of suction and discharge lines.
  • Page 9: Operation

    6. Operation 6.1 To Fill Pump with Oil Fill crankcase with an SAE30 quality oil through opening (28) above crosshead (23). PM10 PM15 PM20 PM30 0.1 litres 0.1 litres 0.2 litres 0.3 litres 6.2 To Fill Pump with Water Fill up pump head with water by pouring the water in via filler plug (33). At the same time, turn the pump V-belt pulley (18) manually in the direction of the arrow.
  • Page 10: Maintenance And Servicing

    7.4 Gear The gear of the original SPECK “Pumpmeister”consists of a forged-steel crankshaft which runs in two ball bearings. The conrod also has a ball bearing. Other than the servicing (lubrication) mentioned under 7.1, hardly any further maintenance is necessary for years. One should check every now and then to make sure the radial shaft seal (32a) on the gear wheel side is seal-proof and that there is no oil leakage.
  • Page 11 8. Failures and Remedies If you have trouble with your pump, you may be able to help yourself by reading the tips we give you below. If you can’t find the reason for the trouble, call a plumber or write to us, not forgetting to mention the pump model and its serial number.
  • Page 12 8.4 Pump switches on automatically although taps are turned off Possible Reason Remedy a) A tap is leaking or air is escaping from the tank. Check by switching off the complete unit overnight. Turn off all taps and check whether the pressure drops.
