Asus VG275 Series Manual

Care & Cleaning

  • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord.
  • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed with a cloth dampened with mild cleaner.
  • shock hazard Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended for use with the monitor. Never spray cleaner directly on the screen, as it may drip inside the monitor and cause an electric shock.

The following symptoms are normal with the monitor:

  • The screen may flicker during the initial use due to the nature of the fluorescent light. Turn off the Power Switch and turn it on again to make sure that the flicker disappears.
  • You may find slightly uneven brightness on the screen depending on the desktop pattern you use.
  • When the same image is displayed for hours, an afterimage of the previous screen may remain after switching the image. The screen will recover slowly or you can turn off the Power Switch for hours.
  • When the screen becomes black or flashes, or cannot work anymore, contact your dealer or service center to fix it. Do not repair the screen by yourself!

Conventions used in this guide


Information to prevent injury to yourself when trying to complete a task.


Information to prevent damage to the components when trying to complete a task.


Information that you MUST follow to complete a task.

information NOTE: Tips and additional information to aid in completing a task.

Where to find more information
Refer to the following sources for additional information and for product and software updates.

  1. ASUS websites
    The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com
  2. Optional documentation
    Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package.

Product Introduction

Thank you for purchasing the ASUS LCD monitor!
The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience.

Package contents

Check your package for the following items:

  • LCD monitor
  • Monitor base
  • Quick start guide
  • Warranty card
  • Power adapter
  • Power cord
  • VGA cable (optional)
  • Audio cable (optional)
  • HDMI cable (optional)
  • DisplayPort cable (optional)

information If any of the above items is damaged or missing, contact your retailer immediately.

Device introduction

Front view

Device introduction - Front view

  1. ( 5-way) button:
    • Turns on the OSD menu. Enacts the selected OSD menu item.
    • Increases/Decreases values or moves your selection up/down/left/right.
    • Displays the input selection bar when the monitor enters standby mode or displays the "NO SIGNAL" message.
  2. button
    • Exits the OSD menu item.
    • Displays the input selection bar when the monitor enters standby mode or displays the "NO SIGNAL" message.
    • Toggles the Key Lock function between on and off with a long press for 5 seconds.
  3. button:
    • GamePlus hotkey. Move the ( ) button up/down to select and press ( ) to confirm the function needed.
    • Displays the input selection bar when the monitor enters standby mode or displays the "NO SIGNAL" message.
  4. button
    • GameVisual hotkey. This function contains 6 sub-functions you can select for your preference.
    • Displays the input selection bar when the monitor enters standby mode or displays the "NO SIGNAL" message.
  5. Power button/power indicator
    • Turns the monitor on/off.
    • The color definition of the power indicator is as the below table.
Status Description
White ON
Amber Standby mode/No signal
OFF OFF

Back view

Device introduction - Back view

  1. DC-IN port. This port connects the power cord.
  2. DisplayPort. This port is for connection for a DisplayPort compatible device.
  3. HDMI port. This port is for connection with an HDMI compatible device.
  4. VGA port. This 15-pin port is for PC VGA connection.
  5. Audio-in port. This port connects PC audio source by the bundled audio cable.
  6. Earphone jack. This port is only available when an HDMI/DisplayPort cable is connected.
  7. Kensington lock slot.
  8. Control buttons.

GamePlus Function

The GamePlus function provides a toolkit and creates a better gaming environment for users when playing different types of games. The crosshair overlay with four different crosshair options lets you choose the one that best suits the game you're playing. There's also an onscreen timer you can position on the left of the display so you can keep track of the elapsed gaming time; while the FPS (frames per second) counter lets you know how smooth the game is running. Display Alignment displays alignment lines on 4 sides of the screen, serving as an easy and handy tool for you to line up multiple monitors perfectly.

Device introduction - GamePlus Menu
To active GamePlus:

  1. Press the GamePlus hotkey.
  2. Move the ( ) button up/down to select among different functions.
  3. Press the ( ) button or move the ( ) button right to confirm the function you choose, and move the ( ) button up/down to navigate through the settings. Move the ( ) button left to go back, off, and exit.
  4. Highlight the desired setting and press the ( ) button to activate it. Press the button to inactivate it.

GameVisual Function

The GameVisual function helps you select among different picture modes in a convenient way.
To active GameVisual:
Press the GameVisual hotkey repeatedly to select.

  • Scenery Mode: This is the best choice for scenery photo displaying with GameVisual Video intelligence Technology.
  • Racing Mode: This is the best choice for racing game playing with GameVisual Video intelligence Technology.
  • Cinema Mode: This is the best choice for movie watching with GameVisual Video intelligence Technology.
  • RTS/RPG Mode: This is the best choice for Real-Time Strategy (RTS)/ Role-Playing Game (RPG) playing with GameVisual Video intelligence Technology.
  • FPS Mode: This is the best choice for First Person Shooter game playing with GameVisual Video intelligence Technology.
  • sRGB Mode: This is the best choice for viewing photos and graphics from PCs.

information

  • In the Racing mode, the following function(s) are not user-configurable: Saturation, Skin Tone, Sharpness, ASCR.
  • In the sRGB mode, the following function(s) are not user-configurable: Brightness, Contrast, Saturation, Color Temp., Skin Tone, Sharpness, ASCR.

Setup

Assembling the unit arm/base

Setup - Assembling the unit arm/base
To assemble the monitor base:

  1. Have the front of the monitor face down on a table.
  2. Attach the base into the arm, making sure the tab on the arm fits into the groove on the base.
  3. Fix the base to the arm by fastening the bundled screw.


We recommend that you cover the table surface with soft cloth to prevent damage to the monitor.

Adjusting the unit

  • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you.
  • Hold the stand to prevent the monitor from falling when you change its angle.
  • The recommended adjusting angle is +33˚ to -5˚ (for tilt)/+90˚ to -90˚ (for swiveling/+130 mm (for height adjustment)/90˚ (for portrait view).

Setup - Adjusting the unit

information It is normal that the monitor slightly shakes while you adjust the viewing angle.

Pivoting the monitor

  1. Lift the monitor to the highest position.
  2. Tilt the monitor to its maximum angle.
  3. Pivot the monitor to the angle you need.

information It is normal that the monitor slightly shakes while you adjust the viewing angle.

Detaching the arm

(for VESA wall mount)
The detachable arm/base of this monitor is specially designed for VESA wall mount.

To detach the arm/base:

  1. Have the front of the monitor face down on a table.
  2. Remove the rubbers in the four screw holes.
  3. Remove the base.
  4. Use a screwdriver to remove the screw on the hinge, then remove the hinge.

caution We recommend that you cover the table surface with soft cloth to prevent damage to the monitor.

information

  • The VESA wall mount kit (100 x 100 mm) is purchased separately.
  • Use only the UL Listed Wall Mount Bracket with minimum weight/load 22.7kg (Screw size: M4 x 10 mm)

Connecting the cables

Setup - Connecting the cables
Connect the cables as the following instructions:

  • To connect the power cord:
    1. Connect the power adapter securely to the monitor's DC input.
    2. Connect one end of the power cord to the power adapter and the other end to a power outlet.
  • To connect the VGA/HDMI/DisplayPort cable:
    1. Plug one end of the VGA/HDMI/DisplayPort cable to the monitor's VGA/ HDMI/DisplayPort port.
    2. Connect the other end of the VGA/HDMI/DisplayPort cable to your computer's VGA/HDMI/DisplayPort port.
    3. Tighten the two screws to secure the VGA connector.
  • To connect the audio cable: connect one end of the audio cable to the monitor's Audio-in port, the other end to the computer's audio-out port.
  • To use the earphone: connect the end with plug type to the monitor's earphone jack when an HDMI or DisplayPort signal is fed.

Turning on the unit

Press the power button . See "Device Introduction" for the location of the power button. The power indicator lights up in white to show that the monitor is ON.

General instructions

OSD menu

How to reconfigure

OSD menu reconfiguration

  1. Press the ( ) button to activate the OSD menu.
  2. Move the ( ) button up/down to navigate through the functions. Highlight the desired function and press the ( ) button to activate it. If the function selected has a sub-menu, move the ( ) button up/down again to navigate through the sub-menu functions. Highlight the desired submenu function and press the ( ) button or move the ( ) button right to activate it.
  3. Move the ( ) button up/down to change the settings of the selected function.
  4. To exit and save the OSD menu, press the button or move the ( ) left repeatedly until the OSD menu disappears. To adjust other functions, repeat steps 1-3.

OSD function introduction

  1. GameVisual
    Please refer to "GameVisual Function".
    OSD function introduction - GameVisual
  2. Blue Light Filter
    In this function, you can adjust the blue light filter level.
    OSD function introduction - Blue Light Filter
    • Level 0: No change.
    • Level 1~4: The higher the level, the less blue light is scattered. When Blue Light Filter is activated, the default settings of Racing Mode will be automatically imported. Between Level 1 to Level 3, the Brightness function is user-configurable. Level 4 is optimized setting. It is compliance with TUV Low Blue Light Certification. The Brightness function is not user-configurable.

information Please refer to the following to alleviate eye strains:

  • Users should take some time away from the display if working for long hours. It is advised to take short breaks (at least 5 mins) after around 1 hour of continuous working at the computer. Taking short and frequent breaks is more effective than a single longer break.
  • To minimize eye strain and dryness in your eyes, users should rest the eye periodically by focusing on objects that are far away.
  • Eye exercises can help to reduces eye strain. Repeat these exercises often. If eye strain continues please consult a physician. Eye exercises:
    1. Repeating look up and down
    2. Slowly roll your eyes
    3. Move your eyes diagonal.
  • High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light Filter to reduce 70% (max.) harmful blue light to avoiding CVS (Computer Vision Syndrome).
  1. Color
    Set a desired color setting from this menu.
    OSD function introduction - Color Settings
    • Brightness: the adjusting range is from 0 to 100.
    • Contrast: the adjusting range is from 0 to 100.
    • Saturation: The adjusting range is from 0 to 100.
    • Color Temp.: contains 4 modes including Cool, Normal, Warm, and User Mode.
    • Skin Tone: contains three color modes including Reddish, Natural, and Yellowish.
    • Smart View: provides better display quality under big viewing angle.
  2. Image
    Set the image related setting from this menu.
    OSD function introduction - Image Settings
    • Sharpness: The adjusting range is from 0 to 100.
    • Trace Free: Adjusts the response time of the monitor.
    • Aspect Control: Adjusts the aspect ratio to full, 4:3 or OverScan.

information 4:3 is only available when input source is in 4:3 format. OverScan is only available for the HDMI input source.

  • VividPixel: Enhances the outline of the displayed picture and generates high-quality images on screen.
  • Position (Only available for VGA.input): adjusts the horizontal position (H-Position) and the vertical position (V-Position) of the image. The adjusting range is from 0 to 100.
  • Focus (Only available for VGA input): reduces Horizonal-line noise and Vertical-line noise of the image by adjusting (Phase) and (Clock) separately. The adjusting range is from 0 to 100.

information

  • Phase adjusts the phase of the pixel clock signal. With a wrong phase adjustment, the screen shows horizontal disturbances.
  • Clock (pixel frequency) controls the number of pixels scanned by one horizontal sweep. If the frequency is not correct, the screen shows vertical stripes and the image is not proportional.
  • Auto Adjust.: Automatically adjusts the image to its optimized position, clock, and phase (for VGA mode only).
  • ASCR: Turns on/off the ASCR (ASUS Smart Contrast Ratio) function.
  • FreeSync (HDMI/DisplayPort input only): Allows an FreeSync supported* graphics source to dynamically adjust display refresh rate based on typical content frame rates for power efficient, virtually stutter free and low-latency display update.

information
*FreeSync can only be activated within 40Hz ~ 75Hz.
*FreeSync supported AMD GPUs: AMD Radeon R9 300 Series, AMD Radeon R9 Fury X, AMD Radeon R9 360, AMD Radeon R7 360, AMD Radeon R9 295X2, AMD Radeon R9 290X, AMD Radeon R9 290, AMD Radeon R9 285, AMD Radeon R7 260X, AMD Radeon R7 260.
*For supported GPUs, minimum PC system and driver requirements, please contact the GPU manufactures.

  1. Sound
    Set the sound related setting from this menu.
    OSD function introduction - Sound Settings
    • Volume: the adjusting range is from 0 to 100.
    • Mute: toggles the monitor sound between on and off.
    • Source: decides the monitor sound comes from which source.
  2. Input Select
    In this function, you can select your desired input source.
    OSD function introduction - Input Select
  3. System Setup
    Allows you to adjust the system.
    OSD function introduction - System Setup
    • GameVisual Demo Mode: Activate the demo mode for the GameVisual function.
    • ECO Mode: reduces power consumption.
    • OSD Setup:
      * Adjusts the OSD timeout from 10 to 120 seconds.
      * Enables or disables the DDC/CI function.
      * Adjusts the OSD background from opaque to transparent.
    • Language: There are 21 languages for your selection, including English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesia, Persian.
    • Keylock: To disable all function keys. Press over 5 seconds to cancel the key lock function.
    • Information: Shows the monitor information.
    • Power Indicator: Turn the power LED indicator on/off.
    • Power Key Lock: Enables or disables the power key.
    • All Reset: "Yes" allows you to restore the default settings.
  4. MyFavorite
    Loads/Saves all settings on the monitor.
    OSD function introduction - MyFavorite

Specifications summary

Panel Type TFT LCD
Panel size 27"W (16:9, 68.6 cm) wide screen
Max. Resolution 1920 x 1080
Pixel pitch 0.311 mm x 0.311 mm
Brightness (Typ.) 300 cd/m2
Contrast Ratio (Typ.) 1000:1
Contrast Ratio (Max.) 100,000,000:1 (with ASCR on)
Viewing angle(H/V).CR>10 170˚/160˚
Display colors 16.7 M
Response time 1 ms (Gray to gray)
Color temperature selection 4 color temperatures
Analog input D-sub
Digital input HDMI x 2, DisplayPort
Earphone jack Yes
Audio input Yes
Speaker (Built-in) 2 W x 2 Stereo, RMS
USB 3.0 port No
Colors Black
Power LED White (On)/Amber (Standby)
Tilt +33˚~ -5˚
Swivel +90˚~ -90˚
Height adjustment 130 mm
VESA wall mount 100 x 100 mm
Kensington lock Yes
Voltage rating AC: 100~240V
DC: 19V, 2.1A (AC adapter)
Power consumption Power On: < 40 W, Standby: < 0.5 W, Power Off: < 0.5 W
Temperature (Operating) 0˚C~40˚C
Temperature (Non-operating) -20˚C~+60˚C
Dimensions (W x H x D) with stand 619 x 506 x 211 mm (highest)
619 x 376 x 211 mm (lowest)
700 x 190 x 458 mm (package)
Weight (Esti.) 5.5 kg (Net); 8.0 kg (Gross)
Multi-languages 21 languages (English, French, German, Italian, Spanish, Dutch, Portuguese, Russian, Czech, Croatian, Polish, Romanian, Hungarian, Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesia, Persian)
Accessories VGA cable (optional), Audio cable (optional), HDMI cable (optional), DisplayPort cable (optional), power adapter, power cord, Quick start guide, warranty card
Compliance and Standards UL/cUL, CB, CE, ErP, FCC, CCC, BSMI, CU, RCM, VCCI, PSE, CEL Level 1, J-MOSS, RoHS, WEEE, Windows 7/8.1/10 WHQL, KCC, E-STANDBY, TUV-Flicker Free, TUV-Low Blue Light, UkrSPEPRO, MEPS, ISO9241-307

*Specifications are subject to change without notice.

Supported operating mode

Resolution Vertical Frequency (Hz) Horizontal Frequency (KHz)
640x480 59.94(N) 31.47(N)
640x480 66.66(N) 35.00(N)
640x480 72.82(N) 37.87(N)
640x480 75.00(N) 37.5(N)
720x400 70.08(P) 31.47(N)
800x600 56.25(P) 35.16(P)
800x600 60.32(P) 37.88(P)
800x600 72.12(P) 48.08(P)
800x600 75.00(P) 46.86(P)
832x624 74.55(P/N) 49.72(P/N)
1024x768 60.00(N) 48.36(N)
1024x768 70.069(N) 56.476(N)
1024x768 75.00(N) 60.02(N)
1152x864 75.00(P/N) 67.5(P/N)
1280x720 60.00(N) 45.00(P)
1280x768 60.00(N) 47.78(P)
1280x800 60.00(N) 49.7(P)
1280x960 60.00(N) 60.00(P)
1280x1024 60.02(P) 63.98(P)
1280x1024 75.02(P) 79.98(P)
1360x768 59.79(P) 47.712(P)
1366x768 59.79(P) 47.712(P)
1440x900 59.89(P) 55.94(N)
1600x1200 60.00(P) 75.00(P)
1680x1050 60.00(P) 65.29(N)
1920x1080 60.00(P) 67.5(P)
1920x1080* 75.00((N) 83.9(P)

*Supported only when the HDMI/DisplayPort port is in use.

When the monitor is operating in the video mode (i.e., not displaying data), the following high definition modes shall be supported in addition to standard definition video.

Preset Timing Name Pixel Format Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Rate (MHz) OSD Display
1 480p 720 x 480 31.469 60 27 480p-60Hz
2 720p60 1280 x 720 45 60 74.25 720p-60Hz
3 576p 720 x 576 31.25 50 27 576p-50Hz
4 720p50 1280 x 720 37.5 50 74.25 720p-50Hz
5 1080p60 1920 x 1080 67.5 60 148.5 1080p-60Hz
6 1080p50 1920 x 1080 56.25 50 148.5 1080p-50Hz

Troubleshooting/FAQ

Problem Possible. Solution

Power LED is not ON

  • Press the button to check if the monitor is in the ON mode.
  • Check if the power cord is properly connected to the monitor and the power outlet.
The power LED lights amber and there is no screen image
  • Check if the monitor and the computer are in the ON mode.
  • Make sure the signal cable is properly connected the monitor and the computer.
  • Inspect the signal cable and make sure none of the pins are bent.
  • Connect the computer with another available monitor to check if the computer is properly working.

Screen image is too light or dark

  • Adjust the Contrast and Brightness settings via OSD.

Screen image is not centered or sized properly

  • Adjust the H-Position or V-Position settings via OSD.
Screen image bounces or a wave pattern is present in the image
  • Make sure the signal cable is properly connected to the monitor and the computer.
  • Move electrical devices that may cause electrical interference.
Screen image has color defects (white does not look white)
  • Inspect the signal cable and make sure that none of the pins are bent.
  • Perform All Reset via OSD.
  • Adjust the R/G/B color settings or select the Color Temperature via OSD.

Safety information

  • Before setting up the monitor, carefully read all the documentation that came with the package.
  • burn hazardshock hazard
    To prevent fire or shock hazard, never expose the monitor to rain or moisture.
  • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury.
  • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
  • Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
  • Slots and openings on the back or top of the cabinet are provided for ventilation. Do not block these slots. Never place this product near or over a radiator or heat source unless proper ventilation is provided.
  • The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supply to your home, consult your dealer or local power company.
  • Use the appropriate power plug which complies with your local power standard.
  • burn hazardshock hazard
    Do not overload power strips and extention cords. Overloading can result in fire or electric shock.
  • Avoid dust, humidity, and temperature extremes. Do not place the monitor in any area where it may become wet. Place the monitor on a stable surface.
  • Unplug the unit during a lightning storm or if it will not be used for a long period of time. This will protect the monitor from damage due to power surges.
  • Never push objects or spill liquid of any kind into the slots on the monitor cabinet.
  • If you encounter technical problems with the monitor, contact a qualified service technician or your retailer.
  • Adjustment of the volume control as well as the equalizer to other settings than the center position may increase the ear-/headphones output voltage and therefore the sound pressure level.
  • The adapter is only used for this monitor, do not use it for other purpose. Your device uses one of the following power supplies:
    • Manufacturer: Delta Electronics Inc., Model: ADP-40KD BB

Documents / Resources

References

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download Asus VG275 Series Manual

Advertisement

Need help?

Need help?

Do you have a question about the VG275 Series and is the answer not in the manual?

Questions and answers

Table of Contents
