Asus VG249Q1R Series Manual
![]()
Exploded View
![Asus - VG249Q1R Series - Exploded View Exploded View]()
NO | DESCRIPTION | Q'ty | REMARK |
1 | PANEL | 1 | |
2 | LED BOARD | 1 | |
3 | KEY BOARD | 1 | |
4 | BUTTON | 1 | |
5 | LED DRIVER BD | 1 | |
6 | TP/SCREW BIND 3*5 NISI | 2 | Fixed LED DRIVER BD |
7 | SPEAKER | 2 | |
8 | MAIN BOARD | 1 | |
9 | M/SCREW BIND 3*5 NISI | 3 | Fixed MAIN BOARD |
10 | M/SCREW BIND 3*5 NISI | 3 | Fixed SHIELD |
11 | ARTICULATED CONNECTOR | 1 | |
12 | M/SCREW BIND 3*6 NISI | 2 | Fixed Articulated connector |
13 | SHIELD | 1 | |
14 | DECORATION STRIP | 1 | |
15 | BACK COVER | 1 | |
16 | M//SCREW BIND 3*6 NISI | 3 | Fixed BACK COVER |
17 | STAND ASSY | 1 | |
18 | BASE | 1 | |
19 | M/SCREW BIND 4*10 NISI | 2 | Fixed STAND ASSY |
Disassembly Procedures
Disassembly SOP
Preparation before disassemble:
- When replacing parts or circuit boards, clamp the lead wires around terminals before soldering.
- When replacing a high wattage resistor (more than 1W of metal oxide film resistor) in circuit board, keep the resistor about 5mm away from circuit board.
- Keep wires away from high voltage, high temperature components and sharp edges.
- Keep wires in their original position so as to reduce interference.
- Usage of this product please refer to also user's manual.
![]()
- This monitor should be operated only at the correct power sources indicated on the label on the rear end of the monitor. If you're unsure of the power supply in your residence, consult your local dealer or power company and check up user manual.
- Use only the special power adapter that comes with this monitor for power input.
Do not remove the monitor cabinet. There is high-voltage parts inside that may cause electric shock to human bodies, even when the power cord is unplugged. - Stop using the monitor if the cabinet is damaged. Have it checked by a service technician.
- Put your monitor only in a clean, dry environment. If it gets wet, unplug the power cable Immediately and consult your service technician.
- Always unplug the monitor before cleaning it. Clean the cabinet with a clean, dry cloth. Apply non-ammonia based cleaner onto the cloth, not directly onto the glass screen.
- Keep the monitor away from magnetic objects, TV sets, and transformer.
- Do not place heavy objects on the monitor or power cord.
Step | Figure | Description |
Preparation | ![Asus - VG249Q1R Series - SOP Disassembly - Step 1 SOP Disassembly - Step 1]() | Lay the LED on a flat, soft and clean surface. |
Remove base and stand | ![Asus - VG249Q1R Series - SOP Disassembly - Step 2 SOP Disassembly - Step 2]() | - Use tools to pry open decorative strips.
- Remove the screws remarked in red.
|
Remove back cover | ![Asus - VG249Q1R Series - SOP Disassembly - Step 3 SOP Disassembly - Step 3]() | The gap between the shell and the screen, separating the front shell from the back shell. Remove the back cover. |
Remove Speaker / LED DRIVER BD/ SHIELD | ![Asus - VG249Q1R Series - SOP Disassembly - Step 4 SOP Disassembly - Step 4]() | Remove the screws remarked in red. |
Remove MAIN BOARD | ![Asus - VG249Q1R Series - SOP Disassembly - Step 5 SOP Disassembly - Step 5]() | Remove the screws remarked in red. |
Assembly SOP
Step | Figure | Description |
Fixed MAIN BOARD | ![Asus - VG249Q1R Series - SOP Assembly - Step 1 SOP Assembly - Step 1]() | Fixed the screws remarked in red. |
Fixed Speaker / LED DRIVER BD / SHIELD | ![Asus - VG249Q1R Series - SOP Assembly - Step 2 SOP Assembly - Step 2]() | Fixed the screws remarked in red. |
Mounting BACK COVER | ![Asus - VG249Q1R Series - SOP Assembly - Step 3 SOP Assembly - Step 3]() | Plug wire remarked in red. |
Remove back cover / base and stand | ![]() | Fixed the screws remarked in red. |
| ![Asus - VG249Q1R Series - SOP Assembly - Step 4 SOP Assembly - Step 4]() | The end. |
Trouble Shooting
Problem | Possible Solution |
Power LED is not ON | - Press the
button to check if the monitor is in the ON mode. - Check if the power cord is properly connected to the monitor and the power outlet.
- Check Power Indicator function in main menu OSD. Select "ON" to turn on power LED.
|
The power LED lights amber and there is no screen image | - Check if the monitor and the computer are in the ON mode.
- Make sure the signal cable is properly connected the monitor and the computer.
- Inspect the signal cable and make sure none of the pins are bent.
- Connect the computer with another available monitor to check if the computer is properly working.
|
Screen image is too light or dark | - Adjust the Contrast and Brightness settings via OSD.
|
Screen image bounces or a wave pattern is present in the image | - Make sure the signal cable is properly connected to the monitor and the computer.
- Move electrical devices that may cause electrical interference.
|
Screen image has color defects (white does not look white) | - Inspect the signal cable and make sure that none of the pins are bent.
- Perform Reset via OSD.
- Adjust the R/G/B color settings or select the Color Temperature via OSD.
|
No sound or sound is lost | - Make sure the audio cable is properly connected to the monitor.
- Adjust the volume settings of both your monitor and computer.
- Make sure the computer sound card driver is properly installed and activated.
- Make sure the audio source is correct on the OSD.
|
Safety Precautions
FOR PRODUCTS CONTAINING LASER:
![]()
Invisible laser radiation when open. AVOID DIRECT EXPOSURE TO BEAM.
![]()
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
![]()
The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
- Must mount the module using mounting holes arranged in four corners.
Do not press on the panel, edge of the frame strongly of electric shock as this will result in damage to the screen. - Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to this panel.
- Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
- Make certain that treatment body are grounded through wrist band.
- Do not leave the module in high temperature and in areas of high humidity or a long time.
- Avoid contact with water as it may as hot circuit within the module.
- If the surface of panel became dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may damage the panel.)
SERVICE AND SUPPORT
Visit our multi-language website at https://www.asus.com/support/
