GENMAX GENERATOR
INVERTER GENERATOR
USER'S MANUAL
GM4300iASD
DUAL-FUEL INVERTER GENERATOR
WARNING: SAVE THIS MANUAL FOR FUTURE REFERENCE
This manual contains important information regarding safety. Operation,
maintenance and storage of this product. Before use, read carefully and
understand all cautions, warnings, instructions and product labels. Failure to do
so could result in serious personal injury and/or property damage.
Advertisement
Table of Contents
Related Manuals for GENMAX GM4300iASD
Summary of Contents for GENMAX GM4300iASD
- Page 1 GENMAX GENERATOR INVERTER GENERATOR USER'S MANUAL GM4300iASD DUAL-FUEL INVERTER GENERATOR WARNING: SAVE THIS MANUAL FOR FUTURE REFERENCE This manual contains important information regarding safety. Operation, maintenance and storage of this product. Before use, read carefully and understand all cautions, warnings, instructions and product labels. Failure to do...
- Page 2 DISCLAIMERS: All information, illustrations and specifications in this manual are based on the latest information available at the time of publishing. The illustrations used in this manual are intended as representative reference views only. Moreover, because of our continuous product improvement policy, we may modify information, illustrations and/or specifications to explain and/or exemplify a product, service or maintenance improvement.
- Page 3 DESCRIPTION OF FITTINGS Spark Plug Socket Wrench Dual-Purpose Screwdriver Funnel Phillips and slot blade Used in spark plug maintenance, screwdriver used for generator It's used to oil the generator. inspection, and installation. maintenance. Engine Oil Be sure to add oil before starting the generator.
-
Page 4: Limited Warranty
2. WHO GIVES THIS WARRANTY (WARRANTOR): CHONGQING DINKING POWER MACHINERY CO., LTD 3. WHO RECEIVES THIS WARRANTY(PURCHASER):The original purchaser (other than for purposes of resale) of the Genmax's inverter. 4. WHAT PRODUCTS ARE COVERED BY THIS WARRANTY: Any portable generator supplied or manufactured by Warrantor. -
Page 5: Table Of Contents
TABLE OF CONTENTS LIMITED WARRANTY SAFETY NAMES OF COMPONENTS CONTROL FUNCTIONS PREPARATIONS Adding Engine Oil........................12 Adding Gasoline..........................12 Connecting an LPG Tank......................13 OPERATION Generator Location........................15 Starting the Generator........................15 Shutting Down the Generator.....................18 USING THE GENERATOR Service Environment of the Generator..................19 Generator Wiring........................19 Generator Grounding.........................20 SERVICE AND MAINTENANCE Checking and Filling Fuel......................22... -
Page 6: Safety
SAFETY Personal and property safeties of you and others are very vital. Please read the Safety Warning in the User's Manual and the decals of the generator set carefully.The Safety Warning can alert you to those potential hazards that could harm you and others. In front of each Safety Warning, there is one of four words "DANGER"... - Page 7 SAFETY CO Sentry Indicator Lights ● DO NOT run this product inside homes, garages, basements, crawlspaces, sheds, or other partially- enclosed spaces even if using fans or opening doors Carbon monoxide has accumulated around the and windows for ventilation. Carbon monoxide can generator.
- Page 8 SAFETY ● The use of generators has laws and regulations, BEFORE USING THE GENERATOR please comply with labor safety and health regulations, fire protection laws, electrical industry ● In order to operate the generator correctly, be familiar laws, etc. with the operation of the various components and ●...
- Page 9 SAFETY ● Keep fuel away from sparks, open flames, heat, and ● Connect Parallel Kit only to terminals marked other ignition sources. "Parallel Outlets" on the front of the Generator. ● Check fuel lines, tank, cap, and fittings frequently for ●...
- Page 10 SAFETY SAFETY LABELS AND DECALS...
-
Page 11: Names Of Components
NAMES OF COMPONENTS ① Fuel Tank Cap: Open the fuel tank cap and fill with ⑦ Right Exterior Cover: Unscrew the bolts to proper amount of gasoline. remove the outer cover, add or replace the oil and maintain the air filter. ②... -
Page 12: Control Functions
④ Output Indicator: Indicates the inverter is ready to parallel kit sold by GENMAX. The connector sockets be used. is only used to connect two inverter generators. ⑤ Multi-Switch: Turn position to CHOKE to start the They can not used for AC power output. -
Page 13: Preparations
PREPARATIONS ADDING ENGINE OIL No oil is filled into this generator when being delivered. Do not start up the generator without filing sufficient oil. Recommended Engine Oil Type Your generator was functionally tested in the factory and may 10W-30 contain minimum residual oil. Additional oil is required to operate the unit. -
Page 14: Connecting An Lpg Tank
PREPARATIONS 1. Make sure the generator is on a solid, flat, level surface. 2. Unscrew the fuel cap and set it aside. 3. Slowly add gasoline to the fuel tank. Be careful not to overfill. 4. Replace the fuel cap and wipe up any spilled gasoline with a dry cloth then remove the cloth from the area. - Page 15 PREPARATIONS 3. Remove the cover on the generator LPG/propane inlet. LPG Inlet 4. Tighten the LPG hose to the LPG inlet of the generator. IMPORTANT: DO NOT use thread seal tape or any other type of sealant to seal the LPG hose connection. 5.
-
Page 16: Operation
OPERATION GENERATOR LOCATION ● NEVER operate the generator inside any building, garage, basement, crawlspace, shed, or enclosure, including the generator compartment of a recreational vehicle. ● NEVER operate or start the generator in the back of an SUV, camper, trailer, truck bed (regular sides, flat or other configuration), under staircases, stairwells, next to walls or buildings, or any other location that could limit airflow or trap exhaust. - Page 17 OPERATION 4. Press the LOW IDLE Switch to "OFF". 5. Turn Multi-Switch to "CHOKE" position. Tip: When hot engine is started up, it is unnecessary to close the choke valve, but turn the combination switch to "RUN". 6. First gently pull startup handle, until guy cable is hooked tight, and then pull it with effort.
- Page 18 OPERATION AT T EN T ION For gasoline starting in cold ambient temperature < 59°F (15°C): Keep the Multi-Switch in the “START” position until engine starts. As soon as the engine starts and runs smoothly turn the Multi-Switch to the “RUN” position.
-
Page 19: Shutting Down The Generator
OPERATION Do not run the engine with too little oil. Engine will shut off if engine oil level is too low. Low Idle 1. Turn on a low idle mode to limit noise and fuel consumption with a light generator load. 2. -
Page 20: Using The Generator
USING THE GENERATOR SERVICE ENVIRONMENT OF THE GENERATOR ● Applicable temperature: 23℉/-5℃ ~ 104℉/40℃; ● Applicable humidity: below 95%; ● Applicable altitude: regions below 1,500 m (It shall be used by reducing power in regions above 1,000 m). Standard atmospheric condition ●... -
Page 21: Generator Grounding
USING THE GENERATOR Connection of AC power All electrical equipment shall be disconnected before inserting the plug. ● Make sure that all electrical equipment, including wires and plugs, are in good condition before connecting to the generator; ● Make sure that all loads driven by the generator are within rated load range; ●... -
Page 22: Service And Maintenance
SERVICE AND MAINTENANCE Good maintenance and service is the best guarantee for safe, economical and zero-failure operation. It also contributes to environmental protection. In order to keep the generator in good condition, you must inspect and maintain it regularly. The maintenance schedule is as follows: Then every three Maintenance cycle... -
Page 23: Checking And Filling Fuel
SERVICE AND MAINTENANCE Please shut down the engine first before performing any maintenance. The engine shall be placed in a horizontal position. In order to prevent the engine from starting up, separate spark plug cap shall be separated from spark plug. -
Page 24: Engine Oil Change
SERVICE AND MAINTENANCE 2. Unscrew the spark plug from the generator using the spark plug wrench included with this product. 3. Inspect the Spark Plug If the electrode is oily, clean it using a clean, dry rag. If the electrode has deposits on it, clean it with a brass wire brush. -
Page 25: Cleaning/Replacing The Air Filter
SERVICE AND MAINTENANCE 1. The oil dipstick is on the right side of the generator. 2. Unscrew oil dipstick. 3. Drain engine oil. Place an oil pan under the engine, tilt the generator to quickly pour out oil; After discharging the oil, put the generator back on level ground. 4. -
Page 26: Clean The Fuel Filter
SERVICE AND MAINTENANCE 4. Clean the components with cleaning agent. After cleaning, wrap the components in a cloth and screw them dry. NOTE: If the air filter element is damaged, replace it with a new one. 5. Drip a few drops of oil to foam filter element and squeeze off excess oil. -
Page 27: Storage And Transport
STORAGE AND TRANSPORT GENERATOR STORAGE If it is stored long-term, in order to prevent aging, you shall take some storage measures. 1. Turn off the generator and let it cool completely. 2. Open fuel tank cap, to take out fuel filter screen. Pump all fuel in fuel tank into special fuel tank, and then reassemble fuel tank cap back. -
Page 28: Troubleshooting
TROUBLESHOOTING... - Page 29 TROUBLESHOOTING...
-
Page 30: Technical Parameters
TECHNICAL PARAMETERS Item GM4300iASD Rated Power (kW) 3.35(GAS.)/3.0(LPG) Max. Power (kW) 4.3(GAS.)/3.7(LPG) 164F/P-2 Engine Model Input valve：0.03~0.08mm, Output valve：0.03~0.08mm Valve Clearance 64x45 Stroke x Bore (mm) Engine Type 4-stroke Displacement (cc) Gas Distribution Mode Cooling Mode Forced cooling wind Rated Speed (RPM) -
Page 31: Choosinga Generator
CHOOSING A GENERATOR... - Page 32 In production management, based on orderly, efficient, scientific principles. trying to do as better as possible in product design, development, production, inspection, etc. to make our production can keep orderly. And will continue to make improvement to make sure that keep the competitiveness.
