Parts List
Part Name
Left-Hand End Panel
Right-Hand End Panel
Top Support Frame
(part of assembled canopy)
Dust Cover
(part of assembled canopy)
Removable Fascia
Left-Hand Door
(handle mounting hole on left)
Right-Hand Door
(handle mounting hole on right)
Leg Support with Foot Installed
Fascia Track
(part of assembled canopy)
Door Install Spacer
(labeled Pry Board)
Hardware Kit
L Brackets
Door Handles
Door Handle Attachment Bolt
Door Hanging Bracket
Track Rollers
Door Stoppers
Wall Spacer Kit
Wood Dowels
End Panel Attachment Fittings, Bolts
End Panel Attachment Fittings, Washers
End Panel Attachment Fittings, Washers
End Panel Attachment Fittings, Lock Washers
Door Mounting Fittings
Door Mounting Fittings
Fascia Attachment Fittings and Leg
Support Fittings
Door Guide Fittings
L Bracket Fittings
Leg Support Fittings
Floor-Mounted Door Guide
Assembly Instructions
Lock
Questions? Contact Demco Customer Service.
custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.)
Show & Stow System Assembly Instructions
Part Number
Qty
SSLEP
1
SSREP
1
SSTSP
1
SSDC
1
SSRF
1
SSLHD
1
SSRHD
1
SSALS
1
GT70048
1
SSDIS
1
53019
4
SL-2.5PCAP
2
SO-SCB
2
GT7034
6
GT7000N
6
GT7014
4
SSWSK
1
12
12
8
4
12
12
12
8
1
1
1
SSFMG
1
1
B00I386R30
1
Tools required
• Level (48"L is best)
• Hammer
• Rubber mallet
• Flathead screwdriver
• Phillips head screwdriver
• Drill and drill bit(s)
• Tape measure
• Allen head wrench
• Applicable wall mounting hardware
Drywall: Wall anchors
Wood studs in drywall: Wood screws
Steel studs: Self-tapping steel screws
Brick and concrete: Tapcon concrete screws
Unit of
Measure
Each
89-1/2"H x 26"W x 1"D
Each
89-1/2"H x 26"W x 1"D
Each
94"W x 23-13/32"W x 5"H
Each
94"W x 26"W x 1"D
Each
96"W x 6"H x 1"D
Each
86-1/4"H x 48-1/32"W x 11/16"D
Each
86-1/4"H x 48-1/32"W x 11/16"D
1-1/4" x 1-1/4" sq. x 87"H. (includes 2x Allen Bolts and
Each
Floor Glide)
Each
94"L
Each
Each
2-1/2"H x 1-5/16"W
Each
2-1/2" dia. x 5/16"H
Each
5/8" head dia., 23/32" thread length, 5/16-18" thread size.
Each
Each
Each
Each (Kit of 8)
5" x 5" sq. Quantities: 4x 1/2"D, 4x 1/4"D
Each
Each
5/16" x 1-1/2"
Each
5/16" x 1-1/4"
Each
5/16" x 7/8"
Each
5/16"
Each
Fittings to attach doors to Door Hanging Bracket: 12x T-nuts
Fittings to attach doors to Door Hanging Bracket: 12x machine
Each
screws
Connector Bolts 8x 1/4", 20 x 50mm
Fitting Set
(6 to attach fascia to dust cover, 2 to attach leg support)
Fittings to attach door guide to floor:
Fitting Set
2x Hexhead Tapcon, 3/16" dia. x 1-3/4"L and 2x black cover caps
Fittings to attach L Brackets to floor and end panels:
Fitting Set
4x Hexhead Tapcon, 3/16" dia. x 1-1/4"L; 4x Phillips Round Head
Wood Screws, 3/4" long thread
Fitting Set
1x Hexhead Tapcon – 3/16" dia. x 1-1/4"L, 1x washer
Each
5" dia. x 1"H
Each
Each
Dimensions
www.demco.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Demco Show & Stow System
Summary of Contents for Demco Show & Stow System
- Page 1 Fitting Set 1x Hexhead Tapcon – 3/16" dia. x 1-1/4"L, 1x washer Floor-Mounted Door Guide SSFMG Each 5" dia. x 1"H Assembly Instructions Each Lock B00I386R30 Each Questions? Contact Demco Customer Service. www.demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.)
- Page 2 5. Once upright, move the unit into its final position against the wall (fig. 9). Tip: Rather than picking the unit up, use the end panels as supports to "walk" it into position. fig. 9 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 3 (figs. 15, 16, 17). fig. 15 fig. 16 fig. 17 Use the appropriate hardware to attach the unit to the wall (fig. 17). Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 4 (figs. 15, 16, 17). fig. 15 fig. 16 fig. 17 Use the appropriate hardware to attach the unit to the wall (fig. 23). fig. 23 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 5 (fig. 27). fig. 25 fig. 26 fig. 27 If your Show & Stow System includes shelving, turn to page 12 STOP! to complete shelving installation BEFORE proceeding. Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 6 (figs. 36, 36). Tip: Do not fully tighten the fittings yet. This will save time and make it easier to adjust during installation. fig. 36 fig. 37 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 7 6. Tighten the lock nuts on the hanging brackets to secure them to the track rollers (figs. 42, 43). fig. 42 fig. 43 NOTE Hang and level right-hand door before hanging left-hand door. Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 8 6. Use the predrilled hole with the fitting provided to attach the door handles, one per door (figs. 46, 47, 48). fig. 46 fig. 47 fig. 48 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 9 52 7. Attach the door guide to the floor with two of the 1-3/4" screws provided. 8. Install the black cover caps to conceal the fittings. Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 10 6. Use a wrench to adjust the floor glide. Torque the glide incrementally to address any canopy top deflection (fig. 57). Tip: Use a flat edge or level on top of the canopy to determine when the canopy is flat (fig. 58). fig. 57 fig. 58 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 11 1/8" to 1/4" clear gap at most. 6. When positioned correctly, tighten the set screw to hold in place (fig. 63). fig. 63 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 12 7. Slide the right-hand door back to the right-hand position (fig. 67). 8. Slide the lock into the guide channels on the ratchet (fig. 68). Adjust as needed. Lock with key. fig. 67 fig. 68 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
-
Page 13: Shelving Installation
7" from each end panel (fig. 69). Note: Mounting holes should be toward the top of the rail. fig. 69 2. Using the predrilled holes as a guide, drill pilot holes into the wall (fig. 70). fig. 70 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306... - Page 14 We recommend initially positioning the top brackets with eight empty slots visible above each. 9. Place a shelf onto the brackets. Ensure the shelf is centered and pushed back against the standards (fig. 75). fig. 75 Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 15 If you have a pegboard to install, continue to next page. If not, return to page 6 to complete assembly of your Show & Stow System. Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 16 2. Once positioned, use the eight hole placements in the pegboard to drill into your wall. 3. Use the appropriate hardware for your wall type (not included). fig. 77 (Two pegboards shown) Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
- Page 17 3. Use the appropriate hardware for your wall type (not included). fig. 78 When shelving and pegboard installation is complete, return to page 6 to complete assembly of your Show & Stow System. Questions? Contact Demco Customer Service. demco.com custserv@demco.com | 800.962.4463 (M–F, 7:30 a.m.–5 p.m.) 240306...
