- Page 1 TechnoLink Media Table Installation Instructions 10-26-18...
- Page 2 Assembled TLK Media Table Removable back panel Vertical Panel Grommet Surface Mounted Power Work Surface Steel Leg Removable cable management access panel...
- Page 3 Step 1 - Place work surface face down and attach steel leg with 4 bolts provided Step 2 – Remove back panel of vertical panel via 8 x bolts...
- Page 4 Keel Step 3 – Slide work surface keels into two slots in upright panel Slots Step 4 – With the back panel removed, connect the work surface keels to the upright panel through 4 bolts provided.
- Page 5 Rear View of Vertical Panel with back panel removed. Step 5 – Bolt through back panel and into work surface at two additional points.
- Page 6 TV Bracket DropShare unit Power Unit Power Unit Cable Management Access Panel Step 6 – Remove cable management Step 7 – Attach 2 brackets to DropShare unit, then access panel. Place power module into attach DropShare to underside of work surface in precut slot in work surface.
- Page 7 Find Technolink media table @demco.com Search: Technolink media table Call 800.962.4463 or email custserv@demco.com Step 8 – Connect DropShare unit, flat panel monitor and surface power unit. Once technology is connected and working correctly reinstall the removeable back panel and cable access panel to conceal / manage cables.
