Demco LibraCraft Picture Book Shelving Assembly Instructions

Demco LibraCraft Picture Book
Shelving Assembly Instructions
Starter Panel has
barrel inserts. A bolt
will screw into it.
STARTERS
1.
Lay out panels and top frames
NOTE: At
as shown on a carpeted floor.
least two
See # 8 before starting, multiple
people
units can be assembled and lifted
during
into place at a time. Starter panels
assembly
only begin and end a "run" of
for best
shelving.
results.
2.
Turn top frame, 1st starter and bottom frame on edge as shown. Align holes with barrel inserts. Pass bolt
with washer through the frame brace holes. HAND TIGHTEN the bolts into the starter panel barrel inserts.
DUE TO THE RISK OF TIPPING, SINGLE FACED SHELVING MUST BE ANCHORED TO THE WALL OR TO
THE FLOOR. ANY OTHER USE IS NOT WARRANTIED. THE MANUFACTURER WILL NOT BE LIABLE FOR
SHELVING THAT IS INSTALLED INCORRECTLY.
Adder Panel has holes. A
bolt will pass through it.
ADDERS
TOP
FRAMES
* On 36" to 60"H units
finished side faces up.
* On 72" & 82"H units
un-finished side faces up.
* 2-1/2" SCREWS ARE FOR SCREWING THROUGH THE
HOLES IN THE TOP FRAME BLOCKS
AND INTO THE UPRIGHT PANELS.
3.
Turn 2nd top frame, adder panel &
bottom frames on edge as shown. Align
adder panel holes with holes on the two
frame braces. Pass the bolt through both
sets top frame holes. Place the T-nut on
the bolt. HAND TIGHTEN. Repeat step 3
as needed. NOTE: Starter panels only,
begin and end a "run" of shelving.
Find Demco LibraCraft Picture Book Shelving @demco.com
Search: Demco LibraCraft Picture Book Shelving
Call 800.962.4463 or email custserv@demco.com
Double holes indicate
bottom of panels.

Tools needed:

1/2" box wrench
OR 1/2" socket
wrench, and
Philips Head
Screwdriver.
Bottom frames towards wall.
.
NOTE:
Bottom
frames
should be
placed far
enough away
from the wall to
slide backs into
place from bottom.
See # 6
