Demco LOBO Assembly Instructions

Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key on next page) Any parts damaged during
shipment must be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
• If assembling a Hardwood top that has a depth greater
than 36", top will be in 2 pieces (.5" undersized on
length). Place both top halves face down on a protected
flat surface. Align together the dog bone holes on both
tops.
Step 2:
• Adjust joint connector bolts to the size of the cut outs
and then place the bolt into that cut out. Using a 7/16"
wrench, tighten the bolt. Repeat for each bolt.
Step 3:
• Place LOBO frame tabs down on top of the LOBO top and
align with pre-drilled pilot holes.
Step 4:
• Starting at one corner, place the 5/16" bolt that is welded
to leg through corner support brace of frame.
Step 5:
• Using a # R2 square bit, secure the leg plate to the
tabletop with #10 x 3/4" square pan screws. Repeat for
each leg plate.
Step 6:
• Place the 5/16" lock washer and 5/16" hex nut onto the leg
bolt and tighten with 1/2" wrench. Repeat
remaining legs.
Step 7:
• Using a # R2 square bit, secure frame to table top with
#10 x 3/4" Square pan screws. One screw per tab.
Step 8:
• With someone's help, turn table upright.
Find LOBO Tables With Butcher Block Tops @demco.com
Search: LOBO Butcher Block
Call 800.962.4463 or email custserv@demco.com
Shown with
optional gussets
To o l s R e q u i r e d
• 1/2" Wrench
• Screw Gun
• # R2 Square Bit
Steps 4 & 5
on
Step
LOBO Table
2 Piece Butcherblock Top
2
Step
7
Shown with optional gussets
4
Step
5
Step
6
Step
