2304
MODEL 2304
QuickStart
U S E R ' S
G U I D E
SPEED
HIGH
PRECISION
READBACK
P O W E R S U P P L Y

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2304 and is the answer not in the manual?

Questions and answers

Summary of Contents for Keithley 2304

  • Page 1 All manuals and user guides at all-guides.com 2304 MODEL 2304 QuickStart U S E R ’ S G U I D E SPEED HIGH PRECISION READBACK P O W E R S U P P L Y...
  • Page 2: Safety Precautions

    As described in the International Electrotechnical Commission (IEC) Standard IEC 664, digital multimeter measuring circuits (e.g., Keithley Models 175A, 199, 2000, 2001, 2002, and 2010) measuring circuits are Installation Category II. All other instruments’...
  • Page 3 As users become more familiar with the Model 2304, it may not be necessary to follow this sequence so strictly. For each Model 2304 operating mode, an example set of bus commands is provided.
  • Page 4 :sense:current:range maximum ; set to 5 A range Turning supply output on/off The output of the Model 2304 is turned on and off using the front panel OPERATE button. The word “ON” appears on the display when the output is turned on.
  • Page 5 FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING. FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING. Figure 2. Rear panel of the Model 2304. Note the location of the digital voltmeter inputs.
  • Page 6 Sense + Source + Source + Figure 3. Typical method of connecting the Model 2304 to a DUT. DVM Input Mode: This operating mode configures the Model 2304 to display the voltage applied to the DVM input terminals and to return these readings via the bus. If using the front panel controls, press the DISPLAY button and select DVM INPUT using the buttons.
  • Page 7 The Model 2304 com- putes one measurement parameter (high, low or average) at a time. The desired measurement mode can be selected with the buttons on the front panel.
  • Page 8 All manuals and user guides at all-guides.com M O D E L 2 3 0 4 Notes: 1. For a reading to be performed and returned via the bus, the :read? command must be sent after the instrument is configured to the desired mode.
  • Page 9 All manuals and user guides at all-guides.com H I G H S P E E D P R E C I S I O N R E A D B A C K P O W E R S U P P L Y Front Panel Pulse-current measurement procedure: 1.
  • Page 10 (in sec) for low pulse measurements :sense:pcurrent:time: high .xxxxxx ; specify integration time (in sec) for average pulse measurements :sense:pcurrent:time:auto ; Model 2304 sets integration times :sense:pcurrent:mode high ; set up Model 2304 to calculate and return high pulse value...
  • Page 11 H I G H S P E E D P R E C I S I O N R E A D B A C K P O W E R S U P P L Y :sense:pcurrent:mode low ; set up Model 2304 to calculate and return low pulse value :sense:pcurrent:mode average ; set up Model 2304 to calculate and return average pulse value :sense:pcurrent:synchronize: delay .xxxxx ; specify trigger delay in sec, 0.1 sec maximum in 10...
  • Page 12 All manuals and user guides at all-guides.com Keithley Instruments, Inc. • 28775 Aurora Road • Cleveland, Ohio 44139 440-248-0400 • Fax: 440-248-6168 • http://www.keithley.com © Copyright 1998 Keithley Instruments, Inc. Printed in the U.S.A. Part No. 2304-903-01 Rev A /1-98...
