Owner's Manual and Instructions
Congratulations!
You have purchased the finest kerosene portable forced air construction heater available.
Your new L.B. White heater incorporates the benefits from the most experienced
manufacturer of heating products using state-of-the-art technology.
We, at L.B. White, thank you for your confidence in our products and welcome any
suggestions or comments you may have...call us, toll-free, at (800) 345-7200.
ATTENTION ALL USERS
This heater has been tested and evaluated by C.S.A. International in accordance with
the requirements of Standard UL 733 and ANSI A10.10-1998, CAN/CSA B140.0-03
and CSA B140.8 - 1967 and is listed and approved as a Kerosene forced-air
construction heater with application for the temporary heating of buildings under
construction, alteration, or repair. If you are considering using this product for any
application other than its intended use, then please contact the L.B. White Co., Inc.
Tradesman Kerosene Heaters
MODELS
OUTPUT (BTUH)
CP045BK
45,000
CP075BK
75,000
Certification by:
FUEL
1-K
Kerosene
150-28270
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for L.B. White CP045BK
Summary of Contents for L.B. White CP045BK
- Page 1 Your new L.B. White heater incorporates the benefits from the most experienced manufacturer of heating products using state-of-the-art technology. We, at L.B. White, thank you for your confidence in our products and welcome any suggestions or comments you may have...call us, toll-free, at (800) 345-7200.
- Page 2 Read this Owner’s Manual before installing or using this product. Only properly-trained service people should repair or install this heater. Save this Owner’s Manual for future use and reference. Owner’s Manuals and replacement labels are available at no charge. For assistance, contact L.B. White at 800- 345-7200. WARNING...
-
Page 3: Table Of Contents
This manual will instruct you in the operation and care of your unit. Have your qualified installer review this manual The L.B. White Co., Inc. has a policy of continuous product with you so that you fully understand the heater and how it improvement. -
Page 4: Heater Specifications
Heater Specifications Model SPECIFICATIONS CP045BK CP075BK Fuel Type 1-K, Kerosene Max Input (BTUH) 45,000 75,000 Ventilation Air Required to Support Combustion 175 CFM 265 CFM Pump Pressure (psig) Fuel Consumption per Hour (gal) Ball Bearing Motor Characteristics 1/8 HP, 3,300 RPM... -
Page 5: Safety Information
Safety Information HAZARD DEFINITIONS DANGER Indicates an imminently hazardous situation which, if not avoided WILL result in death or serious injury. WARNING Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury. - Page 6 GENERAL SAFETY INFORMATION (cont.) WARNING WARNING Risk of CO Poisoning! Risk of Burns/Fire/Explosion! Use this heater only in well ventilation areas. Provide proper Keep all combustible materials away from this heater. Minimum Clearances ventilation. See heater specifications (page 4). Outlet 8 feet (250 cm) Sides, Top and Rear 4 feet (125 cm)
-
Page 7: Heater Specifications
Figure 3 – Component Identification Front Guard Handle Screw Wedged Portion Slit Hole Side Cover Cord Wrap Supporter Screw F F i i g g u u r r e e 4 4 – Handle and Cord Wrap Installation CP045BK and CP075BK... -
Page 8: Assembly
Kerosene deteriorates over time. OLD Model Internal Shut-off Temp. Reset Temp. KEROSENE WILL NOT BURN PROPERLY IN THIS HEATER. +/-10 Degrees +/-10 Degrees Use 1-K kerosene in this heater. #1 fuel is a suitable CP045BK/CP075BK F/80 F/50 substitute. -
Page 9: Fueling Your Heater
Pour the kerosene out, making sure that you AWG conductor. remove 4. CP045BK model only: Push power switch to “ON” it all. position. Power lamp will light and heater will start. 5. CP075BK Model only: Turn thermostat control knob to IMPORTANT: Do not store kerosene over summer for use desired setting and push power switch to “ON”... -
Page 10: Maintenance
MAINTENANCE USE ORIGINAL EQUIPMENT REPLACE MENT PARTS. Use of third-party or other alternate components will void warranty and may cause unsafe operating conditions. AIR OUTPUT FILTER, LINT FILTER WARNING Air Output Fire or explosion hazard! Filter Never service heater while it is plugged in or while hot! End Filter Cover Air Intake... -
Page 11: Nozzle
MAINTENANCE (cont.) NOZZLE Screw Combustion Chamber Screw Ignitor Wire Spark Plug Spark Plug Ignitor Wire Nozzle Adaptor Nozzle Adaptor Spark Plug Burner Head Fuel Line Air Line F F i i g g u u r r e e 1 1 1 1 – Spark Plug Replacement CLEAN AND REGAP EVERY 600 HOURS OF OPERATION OR REPLACE AS NEEDED. -
Page 12: Photocell
FUEL FILTER Wire Circuit Fuel Filter Board Screw Fuel Line F F i i g g u u r r e e 1 1 2 2 – Photocell Replacement for CP045BK Switch Wires Side Cover Screw Side Cover Power Switch... -
Page 13: Pump Pressure Adjustment
Wires Fuse Fuse Holder Model : CP045BK F F i i g g u u r r e e 1 1 6 6 – Replacin g Fuse NOTE: The heater is fuse protected. If your heater fails to ignite, DO Relief Valve NOT RETURN YOUR HEATER TO THE STORE. -
Page 14: Display Pcb
8A/125VAC BLACK BLACK AC120V GREEN 60Hz WHITE EARTH F F i i g g u u r r e e 1 1 7 7 – Wiring Diagram Model CP045BK CONTROL PCB SPARK PLUG BLACK BLACK IGNITOR BLUE BLACK POWER LAMP... -
Page 15: Troubleshooting
Troubleshooting Troubleshooting Chart Symptom Possible Cause(s) Corrective Action 1. Wrong pump pressure 1. See Pump Pressure Adjustment, page 13 Heater ignites but MAIN PCB assembly shuts heater off after a 2. Dirty Air Output, Air Intake or Lint Filter 2. See Air Output, Air Intake and Lint Filters, page 10 short period of time. -
Page 16: Parts Identification
15-2 15-3 18-2 18-5 18-8 18-1 18-9 18-3 18-10 18-6 18-7 F F i i g g u u r r e e 1 1 9 9 – Repair Parts Illustration for Portable Oil-Fired Heaters Models CP045BK, CP075BK 4 16... -
Page 17: Parts List
PARTS LIST Reference Part Number for Models: Number Description CP045BK CP075BK Fuel Tank Assembly 572701 572700 Fuel Gauge ----------572150---------- Fuel Cap ----------572157---------- Panel Right Side Assembly 572253 572256 Power Switch ----------572251---------- Thermostat Wire ------ 572149 Display P.C.B. Assembly 572162 -----... -
Page 18: Warranty Policy
12 months from date of shipment from L B. White. found to be defective, L.B. White Co., Inc. will at its option, repair or replace the defective part or heater, with a new part or heater, F.O.B., Onalaska, Wisconsin.
