Summary of Contents for Proline PLGI BBQ.Pro Island
- Page 1 Proline BBQ Island Mount Range Hoods INCLUDES: PLGI BBQ.Pro Island PLGI BBQ.Ultra Island IN S TA L L M A N U A L...
-
Page 2: Table Of Contents
• When cleaning the unit, make sure the power is turned off. • All Proline range hoods are ETL certified. They meet all • When troubleshooting or replacing the touch panel, circuit industry standards and regulations to ensure your safety. -
Page 3: Warranty
If you’re outside of the warranty and your hood is not working properly, call us at (877) 901-5530 and we’ll help you resolve your issue. We can typically help fix your Proline range hood at a reasonable price so you don’t have to replace the whole thing. -
Page 4: Pre-Installation
Proline BBQ Island Mount Range Hood Installation Manual Pre-installation Tools Required Safety Goggles Safety Gloves Utility Knife Adjustable Pencil Tape Wrench Flathead Needle Nose Phillips Screwdriver Screwdriver Pliers Hammer Electric Drill Measuring Tape Level... - Page 5 Pre-installation (continued) Parts Supplied DESCRIPTION IMAGE QUANTITY Undercabinet Grill Hood EZ Hang Wall Bracket Screws 4 x 25 mm (to secure bracket to wall) Varies EZ Hang Wall Mount Bracket Machine Screws 4 x 12 mm (to secure bracket Varies to hood) Flat Head Screws (optional for single-piece chimney) Round Head Screws for Ducting Transition Piece...
-
Page 6: Installation
Proline BBQ Island Mount Range Hood Installation Manual Island Model Installation Attach the angle irons to the ceiling bracket using the Plan Your Installation Location – The recommended provided hardware. installation height is 36"-42" above the cooking surface. Ensure they hang vertically and are evenly spaced to accommodate the hood width. -
Page 7: Grease Try Installation
Grease Tray Installation Step 5: Connect Ducting Attach both 8" duct transitions to the top of the hood using provided screws and foam seals. Connect rigid ductwork to each transition using HVAC tape and self-tapping screws. Do not combine the two duct paths. Step 6: Slide Chimney into Final Position Install the two grease trays into the front and rear grease tunnels inside the hood. -
Page 8: Baffle Filter Installation
Proline BBQ Island Mount Range Hood Installation Manual Baffle Filter Installation Final Steps Now you just need to do a few quick things to ensure that your installation went smoothly. Tighten screws that hang the range hood. • Next, for added support, you can tighten your screws. If... -
Page 9: Operation Of Controls
Operation of Controls Maintenance This control panel gives you full command over Your hood is equipped with stainless steel baffle your BBQ hood’s ventilation and lighting. It filters and grease trays, both dishwasher safe and includes: easy to remove for cleaning To remove the baffle filters: Start with the center filter.
