Summary of Contents for Proline PLGW BBQ.Pro UC
- Page 1 Proline BBQ Under Cabinet Mount Range Hoods INCLUDES: PLGW BBQ.Pro UC PLGW BBQ.Ultra UC IN S TA L L M A N U A L...
-
Page 2: Table Of Contents
• When troubleshooting or replacing the touch panel, circuit • All Proline range hoods are ETL certified. They meet all board, or other electrical components, turn power to the industry standards and regulations to ensure your safety. -
Page 3: Warranty
If you’re outside of the warranty and your hood is not working properly, call us at (877) 901-5530 and we’ll help you resolve your issue. We can typically help fix your Proline range hood at a reasonable price so you don’t have to replace the whole thing. -
Page 4: Pre-Installation
Proline BBQ Under Cabinet Mount Range Hood Installation Manual Pre-installation Tools Required Safety Goggles Safety Gloves Utility Knife Adjustable Pencil Tape Wrench Flathead Needle Nose Phillips Screwdriver Screwdriver Pliers Hammer Electric Drill Measuring Tape Level... - Page 5 Pre-installation (continued) Parts Supplied DESCRIPTION IMAGE QUANTITY Undercabinet Grill Hood EZ Hang Wall Bracket Screws 4 x 25 mm (to secure bracket to wall) Varies EZ Hang Wall Mount Bracket Machine Screws 4 x 12 mm (to secure bracket Varies to hood) Flat Head Screws (optional for single-piece chimney) Round Head Screws for Ducting Transition Piece...
-
Page 6: Installation
Proline BBQ Under Cabinet Mount Range Hood Installation Manual Under Cabinet Model Installation Plan Your Installation Location – The recommended Step 3: Mount the Hood and Connect Ducting installation height is 36"-42" above the cooking Use the appropriate mounting method you chose in Step 1: surface. -
Page 7: Grease Try Installation
Grease Tray Installation Direct Mount Method With help, lift the hood into final position against the wall and ceiling. Secure back of hood directly into structural framing using lag screws. Align and connect the rigid ductwork through the back or top. -
Page 8: Baffle Filter Installation
Proline BBQ Under Cabinet Mount Range Hood Installation Manual Baffle Filter Installation Final Steps Now you just need to do a few quick things to ensure that your installation went smoothly. Tighten screws that hang the range hood. • Next, for added support, you can tighten your screws. If... -
Page 9: Operation Of Controls
Operation of Controls Maintenance This control panel gives you full command over Your hood is equipped with stainless steel baffle your BBQ hood’s ventilation and lighting. It filters and grease trays, both dishwasher safe and includes: easy to remove for cleaning To remove the baffle filters: Start with the center filter.
