Summary of Contents for Proline PLFL CL 28
- Page 1 Insert Range Hood Installation Guide IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference...
-
Page 2: Table Of Contents
Proline Insert Range Hood Installation Guide Table of Contents Before the Installation ........3 What You Will Need . -
Page 3: Before The Installation
Before the Installation 1. Check the contents of your box. They should include, depending on the specific model of your hood: • Hardware packet with screws and anchors, depending on the model As you unpack your hood, remove any protective film the filters, or the range hood before installation. 2. -
Page 4: Install Ductwork
Proline Insert Range Hood Installation Guide Install Ductwork 1. Plan where your ductwork will be located. • Install your ductwork in the shortest unobstructed path to the outside of your home. • Select a path that avoids studs, electrical wires, and other obstacles in your walls. - Page 5 Best Practices when Ducting Your Range Hood • Include at least 18" straight from the transition piece before using an elbow in the duct. • Make sure there is at least 24" of straight duct between other elbows. • Use rigid galvanized steel or metal HVAC ducting only. •...
-
Page 6: Range Hood Installation
Proline Insert Range Hood Installation Guide Step 1 Install the adaptor. • All inserts have blowers that connect to ductwork. • To make the installation easy, we send you an airtight transition piece that connects the range hood and the duct. - Page 7 Step 4 Screw the insert into the cabinet. • Using the screws in the box, drill the insert into the cabinet through each of the four holes on each corner of the hood. Step 5 Attach and seal the ductwork to the range hood. •...
-
Page 8: After The Installation - Final Steps
Proline Insert Range Hood Installation Guide After the Installation – Final Steps Now you just need to do a few quick things to ensure that your installation went smoothly. Assemble and insert baffle filters and the grease tray (if included). -
Page 9: Safety Information
• Clean your range hood filters, grease trays, and the range hood every few weeks. Heavy grease buildup shortens the life of your hood and it may lead to a grease fire. • All Proline range hoods are ETL certified. They meet all industry standards and regulations to ensure your safety. -
Page 10: Warranty Information And Return Policy
If you’re outside of the warranty and your hood is not working properly, call us at (877) 901-5530 and we’ll help you resolve your issue. We can typically help fix your Proline range hood at a reasonable price so you don’t have to replace the whole thing. - Page 12 4375 W 1980 S, Salt Lake City, UT 84104 Call (877) 901-5530 support@prolinerangehoods.com www.prolinerangehoods.com Our Support team hours are: Mon-Fri 8:30 am – 5:00 pm MST...
