30' Min-Till Folding Drill
SMALL SEEDS INSTALLATION MANUAL
MODEL 3S-3000
Original Instructions
Read the operator manual entirely. When you see
!
this symbol, the subsequent instructions and
warnings are serious - follow without exception.
Your life and the lives of others depend on it!
Illustrations may show optional equipment not
supplied with standard unit.
TP-82599
133-216M
Advertisement
Table of Contents
Related Manuals for GREAT PLAINS 3S-3000
Summary of Contents for GREAT PLAINS 3S-3000
- Page 1 Great Plains 30’ Min-Till Folding Drill SMALL SEEDS INSTALLATION MANUAL MODEL 3S-3000 TP-82599 133-216M Original Instructions Read the operator manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Illustrations may show optional equipment not supplied with standard unit.
-
Page 2: Machine Identification
Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine. -
Page 4: To Our Customer
This manual must always be kept with your machine. Great Plains wants you to be satisfied with your product. If for any reason you do not understand any part of this manual or are otherwise dissatisfied, please take the following actions first: Discuss the matter with your dealership service manager. - Page 5 Trademarks of Great Plains Manufacturing, Inc. include: AccuShot, DrillCommand, Max-Chisel, Row-Pro, Singulator Plus, Short Disk, Swath Command, Terra-Tine, Ultra-Chisel, and X-Press. Registered trademarks of Great Plains Manufacturing, Inc. include: Air-Pro, Clear-Shot, Discovator, Great Plains, Land Pride, MeterCone, Nutri-Pro, Seed-Lok, Solid Stand, Terra-Guard, Turbo-Chisel, Turbo-Chopper, Turbo-Max, Turbo-Trill, Ultra-Till, Whirlfilter, and Yield-Pro.
-
Page 6: Installation
These instructions apply to: 133-200A 3S-3000 6” Small Seeds Option 133-201A 3S-3000 7 1/2” Small Seeds Option 133-202A 3S-3000 10” Small Seeds Option 133-203A 3S-3000F 10" Small Seeds Option 133-204A 3S-3000F 7 1/2"... - Page 7 (6) to the drill box using 1/2” x 1 1/4” bolts (2) and 1/2” flange nuts (3) to the rear of main drill box at the holes where the bolts were removed. Small Seeds Box 20097 Great Plains | 133-216M | 05/12/2025...
- Page 8 3S-3000 Series Drill Installation Small Seed Chain Routing 136-104D - 62 pitch # 40 Chain 136-064D - 51 pitch # 40 Chain 136-183D - 203 pitch # 40 TP-82585 Great Plains | 133-216M | 05/12/2025...
- Page 9 2” flat washer, 1/2” lock washer and a 1/2” jam nut. Leave bolt loose while installing chain. 11. Install 51 pitch chain on the sprockets then slide the idler until the chain is tight and tighten idler bolt. Great Plains | 133-216M | 05/12/2025...
- Page 10 Note: For drills with a fertilizer kit use seed tube P/N 133-128H and use the following instructions. 1. Set the side delivery (5) down over the top of the opener directly in front of the fertilizer tube. Line Great Plains | 133-216M | 05/12/2025...
- Page 11 Use the bracket as a template to mark the holes then drill two 11/32” holes. 2. Attach SMV sign (3) to the bracket (1) using 1/4” x 3/4” bolts, 1/4” lock washers and 1/4” nuts. Great Plains | 133-216M | 05/12/2025...
-
Page 12: Seed Rate Calibration
Use the seed rate charts as a guide. Set the pounds per acre desired for your row spacing and complete the following procedure to calibrate the drill for your specific seed. Great Plains | 133-216M | 05/12/2025... -
Page 13: Small Seeds Attachment
Rate Chart” on page 9. The seed-rate handle for the small seeds attachment is shown. Small Seeds Rate Handle TP-82596 2. Calibrate the small seeds attachment to your material by following the steps under “Seed Rate Calibration” on page 7. Great Plains | 133-216M | 05/12/2025... - Page 14 9.8 11.2 12.5 13.8 15.1 16.4 17.5 18.6 20.2 21.4 22.9 24.0 25.2 Alsike, Crimson 7.5" 9.0 10.0 11.1 12.1 13.2 14.0 15.3 16.2 17.2 18.3 19.3 20.3 Clover 10" 9.7 10.3 11.2 11.9 12.6 13.4 14.2 14.9 Great Plains | 133-216M | 05/12/2025...
- Page 15 3S-3000 Series Drill Installation 133-200A 3S-3000 Without Fertilizer Kit 10” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 123-939H SMALL SEEDS TUBE WELDMENT 133-160H 1300 SML SDS BOX MOUNT RH 133-070D...
- Page 16 3S-3000 Series Drill Installation 133-201A 3S-3000 Without Fertilizer Kit 7 1/2” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 123-939H SMALL SEEDS TUBE WELDMENT 133-160H 1300 SML SDS BOX MOUNT RH...
- Page 17 3S-3000 Series Drill Installation 133-202A 3S-3000 Without Fertilizer Kit 6” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 123-939H SMALL SEEDS TUBE WELDMENT 133-160H 1300 SML SDS BOX MOUNT RH 133-070D...
- Page 18 3S-3000 Series Drill Installation 133-203A 3S-3000 With Fertilizer Kit 10” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 133-160H 1300 SML SDS BOX MOUNT RH 133-070D 3000 SMV MOUNTING BLADE 133-128H...
- Page 19 3S-3000 Series Drill Installation 133-204A 3S-3000 With Fertilizer Kit 7 1/2” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 133-160H 1300 SML SDS BOX MOUNT RH 133-070D 3000 SMV MOUNTING BLADE...
- Page 20 3S-3000 Series Drill Installation 133-205A 3S-3000 With Fertilizer Kit 6” Small Seeds Option Your Kit Includes: QTY. Part No. Description 123-492D HANDLE MOUNT RH CHAIN GUARD 133-160H 1300 SML SDS BOX MOUNT RH 133-070D 3000 SMV MOUNTING BLADE 133-128H...
- Page 22 Great Plains Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402 MADE IN USA WITH U.S. & GLOBAL COMPONENTS...
