FIELD ADJUSTMENT GUIDE
Planters
3-Point Stack-Fold Air-Pro Planter
Date: September 23, 2015
Document #
PLUS300C-0002A
Models Affected:3P4025AH
General Information
Proper servicing and adjustment is key to the long life of all farm equipment. With careful and systematic
inspection of equipment, costly maintenance, time and repair can be avoided. The following information
will assist with recommended servicing and adjustments:
48775
1 of 6
Document
#PLUS300C-0002A
