  • Page 1 ® INSTALLATION OBID classic-pro ID CPR.03-VP/AB-A Multitag Reader Data/Clock Page 1 of 11...
  • Page 2 ELECTRONIC GmbH does not give any guarantee promise for perfect function in cross environments. FEIG ELECTRONIC GmbH assumes no responsibility for the use of any information contained in this manual and makes no representation that they free of patent infringement. FEIG ELECTRONIC GmbH does not convey any license under its patent rights nor the rights of others.
  • Page 3: Table Of Contents

    Technical Specifications Dimensions ..........................6 Approval .........................6 Installation Mounting ........................7 Connection........................8 Configuration .........................9 4.3.1 Default Configuration....................9 4.3.2 Reloading the configuration..................9 Normal Operating Mode Digital Inputs........................10 Data-/Clock Interface....................11 Asynchronous Interface: RS232-TTL ................11 System Delivery Contents FEIG ELECTRONIC GmbH Page 3 of 11...
  • Page 4: Safety Instructions / Warning - Read Before Start-Up

    The data-/clock interface could configured like Wiegand- or magnetic stripe format (ISO7811-2, 5 Bit). The configuration could changed while installation with a ConfigCard transponder. This ConfigCard could prepared comfortable before Installation with a separate tool. FEIG ELECTRONIC GmbH Page 4 of 11...
  • Page 5: Technical Specifications

    Applicable Standards: • RF approval EN 300 330 - Europe FCC 47 CFR Part 15 - USA EN 301 489 • • Safety EN 60950 - Low Voltage EN 50364 - Human Exposure FEIG ELECTRONIC GmbH Page 5 of 11...
  • Page 6: Dimensions

    (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance void the user's authority to operate the equipment. FEIG ELECTRONIC GmbH Page 6 of 11...
  • Page 7: Installation

    Use the screws provided (3.2 x 25 mm) for installation on 60 mm DIN flush-mounting boxes. • For other installation methods use 3 mm countersunk-head screws to DIN 963 or with a coun- tersunk head max. diameter of head 5.6 mm. Assembling Disassembling FEIG ELECTRONIC GmbH Page 7 of 11...
  • Page 8: Connection

    **) The digital inputs may only be wired to ground. Wiring to an external power supply may destroy the input. max. 150 m Controller +9..15 V DC green Data / Data0 white Clock / Data1 violet grey LED green brown LED red yellow Beeper blue Hold black pink red/blue FEIG ELECTRONIC GmbH Page 8 of 11...
  • Page 9: Configuration

    3 x LED rot + Beep ⇒ Fault ConfigCard Identifier is not read correctly. ⇒ Repeat procedure. ⇒ Check the ConfigCard for correct programming. Note: ConfigCards with incorrect AFI are not recognized by the reader. No signaling is possible FEIG ELECTRONIC GmbH Page 9 of 11...
  • Page 10: Normal Operating Mode

    Activates the green LED and deactivates the red LED, as long as the input is connected to GND. Beeper: Activates the beeper LED, as long as the input is connected to GND. Hold: Will not accept a transponder, as long as the input is connected to GND. FEIG ELECTRONIC GmbH Page 10 of 11...
  • Page 11: Data-/Clock Interface

    The firmware update is described in ID CPR.03-VP/AB-A Manual (Document No: H60100-#e-ID-B) System Delivery Contents 1 x housing base including sealed-in electronics 1 x housing cover 1 x accessory bag (2 screws 3,2x 25 mm 1 x Mounting Instruction FEIG ELECTRONIC GmbH Page 11 of 11...
