Page 1: Helideck Lighting System
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight TRANBERG® IMT HELIDECK FLOODLIGHT TEF 9976 LED Floodlight Helideck Lighting System Document properties (TUM7707) Revision Comment Revision date Approved First issue 22.11.2024 Add inrush data 14.02.2025... -
Page 2: Table Of Contents
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Installation and operating manual Contents Helideck Lighting System ............................1 Document properties (TUM7707) ..........................1 Warnings and risk levels ............................3 General information ..............................3 Marking and intended use ............................4 Specific conditions for use ............................ -
Page 3: Warnings And Risk Levels
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Warnings and risk levels DANGER Non-compliance with the instruction results in risk of severe or fatal injuries to persons WARNING Non-compliance with the instruction may result in risk of severe or fatal injuries to persons CAUTION Non-compliance with the instruction may result in risk of injuries or damage to equipment NOTICE... -
Page 4: Marking And Intended Use
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Marking and intended use DANGER Not for use in EX areas CAUTION TEF9976 LED floodlight is intended for use on onshore, offshore and ship-borne helidecks. TEF9976 is made from aluminum, and should not be exposed to corrosive media such as acids and bases. Never open the sealed parts of the lighting fixtures. -
Page 5: Specific Conditions For Use
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Specific conditions for use DANGER Specific conditions for use are critical conditions to maintain the explosion protection of the equipment. These shall be adhered to in all cases and under all circumstances. •... -
Page 6: Mounting And Installation
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Mounting and installation DANGER Incorrect mounting and installation may lead to explosion risks, risk of falling objects, risk for electric shock and risk for equipment malfunction. In turn, this can lead to severe damage and/or injuries. NOTICE Only qualified personnel may install this product. - Page 7 Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Cables shall be stripped according to the instructions of the cable manufacturer with the appropriate tools to guarantee the properties of the cable. Wire sleeves suitable for the quadratic wire diameter shall be placed at the bare wire ends and fixed with a specified tool according to the instructions of the manufacturer.
-
Page 8: Commissioning
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight NOTICE Terminals A and B are for external communications - DALI Commissioning Installations in which the TRANBERG® IMT Floodlight (TEF 9976) are installed can be tested by means of an insulation test. -
Page 9: Disposal
Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight Disposal CAUTION This equipment or part of this equipment is considered EE-Waste, and shall be handled accordingly • Observe national and local regulations and statutory regulations regarding disposal • Separate materials when sending it for recycling •... - Page 10 Installation and operating manual - TUM7707 TEF 9976 Helideck Floodlight...
