TEF2580
BlueLine Series
TEF 2580 LED Floodlight
Safe Area
Document properties (TUM6650)
Revision Comment
A
Added more info on wiring QPD plug
B
Added diameter on wire
C
Added sealing plug
Installation and operating manual
LED Floodlight
Revision
Approved
date
06.10.2020
CKR
16.06.2021
CKR
24.08.2022
CKR
Advertisement
Table of Contents
Related Manuals for Stahl TRANBERG BlueLine Series
Summary of Contents for Stahl TRANBERG BlueLine Series
-
Page 1: Document Properties (Tum6650)
Installation and operating manual TEF2580 LED Floodlight BlueLine Series TEF 2580 LED Floodlight Safe Area Document properties (TUM6650) Revision Comment Revision Approved date Added more info on wiring QPD plug 06.10.2020 Added diameter on wire 16.06.2021 Added sealing plug 24.08.2022... -
Page 2: Table Of Contents
Installation and operating manual TEF2580 LED Floodlight Installation and operating manual Contents Document properties (TUM6650) ..........................1 Warnings and risk levels ............................3 General information ..............................3 Marking and intended use ............................4 Technical data ................................. 5 Product description ..............................5 Transport and storage ............................. -
Page 3: Warnings And Risk Levels
Installation and operating manual TEF2580 LED Floodlight Warnings and risk levels DANGER Non-compliance with the instruction results in risk of severe or fatal injuries to persons WARNING Non-compliance with the instruction may result in risk of severe or fatal injuries to persons CAUTION Non-compliance with the instruction may result in risk of injuries or damage to equipment NOTICE... -
Page 4: Marking And Intended Use
Installation and operating manual TEF2580 LED Floodlight Marking and intended use CAUTION Not intended for use in “these” conditions (Where mud may be present, on helidecks, underground, direct sunlight, heavy vibrations, high risk of impact, harsh cleaning agents, high pressure washer etc.) -
Page 5: Technical Data
Installation and operating manual TEF2580 LED Floodlight Technical data Property Material Seawater resistant aluminium (powder coated), acrylic or glass Voltage 100-240 VAC, model dependant Light output Up to 30 000 lm, 5000K, 70 CRI Power consumption Up to approx. 300W Ingress Protection (IP) IP 66 Weight... -
Page 6: Mounting And Installation
Check the condition of the equipment and the contents when unpacking. Any damage done to the equipment during transportation is not the responsibility of R. Stahl Tranberg AS. If the content is not complete, file a claim to the manufacturer immediately. - Page 7 Installation and operating manual TEF2580 LED Floodlight The luminaire can be adjusted into desired angle within a range of 185°. Only qualified electrical personnel may install and start up the QPD components. If the lamps are not electrical connected at the installation time, make sure that the QPD plugs are properly sealed by a sealing plug (or protective cap) for unused cable entries (part no 50500231).
-
Page 8: Electrical Connections
Installation and operating manual TEF2580 LED Floodlight Electrical connections Cable termination Cable diameter: Ø6-11 mm or Ø9-16 mm. Part # 2880***0* delivered as standard with terminal nut for Ø6-11 mm cable. All other variants delivered with terminal nut for Ø9-16 mm cable. Wire cross section: 1.0 mm2 to 2.5 mm2. -
Page 9: Maintenance And Cleaning
TEF2580 LED Floodlight CAUTION Do not open the product. The R. Stahl TRANBERG TEF2580 series is sealed for life. Non-compliance with the instruction may result in risk of injuries or damage to equipment Maintenance and cleaning No maintenance required. Clean only with a damp cloth, water and mild detergents. Avoid chemicals with high or low pH, abrasives, high pressure washer, strong detergents, solvents, petroleum- or alcohol based cleaning agents and similar. -
Page 10: Disposal
Installation and operating manual TEF2580 LED Floodlight Disposal CAUTION This equipment or part of this equipment is considered EE-Waste, and shall be handled accordingly Observe national and local regulations and statutory regulations regarding disposal • Separate materials when sending it for recycling •... - Page 11 Installation and operating manual TEF2580 LED Floodlight Appendix #1...
-
Page 12: Appendix #2, Doc
Installation and operating manual TEF2580 LED Floodlight Appendix #2, DoC...
