- Page 1 Operating instructions Additional languages r-stahl.com Floodlight Series 6521/5...
-
Page 2: Table Of Contents
Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Further documents ....................3 Conformity with standards and regulations ............3 Explanation of the symbols .................4 Symbols in these operating instructions .............4 Warning notes .....................4 Symbols on the device ..................5 Safety notes ......................5 Operating instructions storage ................5 Safe use ......................5... -
Page 3: General Information
General Information General Information Manufacturer R. STAHL Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. - 5 Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area 74638 Waldenburg Singaperumal Koil, Kancheepuram Dist., Germany Tamil Nadu – 603 204, INDIA Phone: +49 7942 943-0... -
Page 4: Explanation Of The Symbols
Explanation of the symbols Explanation of the symbols Symbols in these operating instructions Symbol Meaning Tips and recommendations on the use of the device Danger due to explosive atmosphere Danger due to live components Warning notes Warnings must be observed under all circumstances, in order to minimize the risk due to construction and operation. -
Page 5: Symbols On The Device
• Use the device in accordance with its intended and approved purpose only. • Always consult R. STAHL Schaltgeräte GmbH if using the device under operating conditions which are not covered by the technical data. • We cannot be held liable for damage to the device caused by incorrect or unauthorised use or non-compliance with these operating instructions. -
Page 6: 3.3 Intended Use
Function and device design Intended Use The luminaire is equipment • for lighting areas, work spaces and objects • can be used indoors and outdoors • for stationary mounting • for use in Zones 21, 2, 22 and in the safe area Modifications and alterations DANGER Explosion hazard due to modifications and alterations to the device! -
Page 7: Device Design
Function and device design Device design 17215E00 Luminaire enclosure Mounting bracket Cable gland Lamp holder Cable gland Connection terminal 214040 / 6521613300 Floodlight 2020-07-27·BA00·III·en·01 Series 6521/5... -
Page 8: Technical Data
Technical data Technical data Explosion Protection Global (IECEx) Gas and dust IECEx TUR 12.0001 Ex nAc IIC T Ex tb IIIC T IP66 Europe (ATEX) TÜV 12 ATEX 7173 E II 3G Ex nAc IIC T Dust TÜV 12 ATEX 7174 E II 2D Ex tb IIIC T °C IP66 Lamp... - Page 9 (finely stranded) (2 free clamping units per pole available) Mounting U-shaped holding bracket made of stainless steel, continuously swivelable around the rotary axis of the flood lights. For further technical data, see r-stahl.com. 214040 / 6521613300 Floodlight 2020-07-27·BA00·III·en·01 Series 6521/5...
-
Page 10: Transport And Storage
Transport and storage Transport and storage • Transport and store the device only in the original packaging. • Store the device in a dry place (no condensation) and vibration-free. • Do not drop the device. Mounting and installation DANGER Explosion hazard due to incorrect installation of the device! Non-compliance results in severe or fatal injuries. -
Page 11: Mounting / Dismounting, Operating Position
Mounting and installation Dimensional drawings (all dimensions in mm [inches]) – Subject to modification Accessories 97 [3.82] 89 [3.50] 89 [3.50] 76 [2.99] 75 [2.95] 60 [2.36] Ø Ø 09724E00 250 [ 9,84] Ø Ø 09725E00 Mounting base (rotatable) Pole mounting attachment Mounting / dismounting, operating position The mounting position of the floodlight is optional. -
Page 12: Installation
Mounting and installation Installation 7.3.1 Opening and Closing of the Enclosure DANGER Risk of electric shock due to improper opening! Non-compliance results in severe or fatal injuries. • Open luminaires without switch only in de-energized state (see information plate on the lock)! Opening: •... - Page 13 Mounting and installation Loop in/loop out wiring of the mains connection Loop in/loop out wiring with max. 12 A possible • Insert the cable. 21967E00 • Connect the conductor to the spring clamp terminal. • Check that the cable is clamped properly.
- Page 14 The standard luminaire is delivered with 3 lead-in holes, 1 cable glands and 1 stopping plug. Tightening torques for components from R. STAHL Schaltgeräte GmbH Luminaires with installed cable entries and stopping plugs from R. STAHL Schaltgeräte GmbH must be tightened using the following values: Tightening torque Connection thread Pressure screw Cable entry M20 x 1.5...
-
Page 15: Commissioning
Commissioning Commissioning DANGER Explosion hazard due to incorrect installation! Non-compliance results in severe or fatal injuries. • Check the device for proper installation before commissioning. • Comply with national regulations. NOTICE Malfunction or device damage caused by condensation. Non-compliance can result in material damage! •... -
Page 16: Operation
The control gear is defective. Replace the control gear. If the error cannot be eliminated using the mentioned procedures: • Contact R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number of the device •... -
Page 17: 10.1 Maintenance
• Avoid condensation and thermal bridges! 10.2 Repair DANGER Explosion hazard due to improper repair! Non-compliance results in severe or fatal injuries. • Repair work on the devices must be performed only by R. STAHL Schaltgeräte GmbH. 214040 / 6521613300 Floodlight 2020-07-27·BA00·III·en·01 Series 6521/5... -
Page 18: 10.3 Returning The Device
• Only return or package the devices after consulting R. STAHL! Contact the responsible representative from R. STAHL. R. STAHL's customer service is available to handle returns if repair or service is required. • Contact customer service personally. • Go to the r-stahl.com website.
