- Page 1 Operating instructions Additional languages www.r-stahl.com Floodlight LED Series 6125...
-
Page 2: Table Of Contents
Contents General Information ....................3 Manufacturer .......................3 Information regarding the operating instructions ..........3 Conformity with standards and regulations ............3 Explanation of the symbols .................4 Symbols in these operating instructions .............4 Warning notes .....................4 Symbols on the device ..................5 Safety notes ......................5 Operating instructions storage ................5 Safe use ......................5 Intended Use .......................6... -
Page 3: General Information
General Information General Information Manufacturer R. Stahl Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. - 5 Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area 74638 Waldenburg Singaperumal Koil, Kancheepuram Dist., Germany Tamil Nadu – 603 204, INDIA Phone: +49 7942 943-0... -
Page 4: Explanation Of The Symbols
Explanation of the symbols Explanation of the symbols Symbols in these operating instructions Symbol Meaning Tips and recommendations on the use of the device General danger Danger due to explosive atmosphere Danger due to energised parts Risk of damage to the eyes caused by optical radiation Warning notes Warnings must be observed under all circumstances, in order to minimize the risk due to construction and operation. -
Page 5: Symbols On The Device
Safety notes CAUTION Danger to persons Non-compliance with the instruction can result in light injuries to persons. NOTICE Avoiding material damage Non-compliance with the instruction can result in material damage to the device and / or its environment. Symbols on the device Symbol Meaning CE marking according to the currently applicable directive. -
Page 6: 3.3 Intended Use
Function and device design Intended Use The LED floodlight 6125 is equipment • for stationary mounting • for use in Zones 1, 21, 2, 22 and in the safe area • can be used indoors and outdoors • for lighting areas, work spaces and objects Modifications and alterations DANGER Explosion hazard due to modifications and alterations to the device! -
Page 7: Device Design
Function and device design Device design 17562E00 1 - Cable glands Seal 2 - Mounting bracket Luminaire glass cover 3 - Connection terminal Mounting screws 4 - Heat sink (only for 210 W version) Enclosure cover 5 - LEDs 10 - LED-Driver 1 251652 / 612560300010 Floodlight LED 2018-01-12·BA00·III·en·04... -
Page 8: Technical Data
Technical data Technical data Explosion Protection Global (IECEx) Gas and dust IECEx EPS 15.0087 Ex db eb op is IIC T4 Gb Ex tb op is IIIC T*°C Db Europe (ATEX) Gas and dust EPS 15 ATEX 1 114 E II 2G Ex db eb op is IIC T4 Gb E II 2D Ex tb op is IIIC T*°C Db Type Power... - Page 9 Technical data Technical Data Luminous characteristics 6125/11..-2 6125/11..-4 Power consumption [W] Colour rendering [CRI] ) 70 ) 70 Colour temperature [K] 5,700 5,700 wide beam Luminous flux [lm] 11,763 19,658 Luminaire efficiency [lm/W] medium beam Luminous flux [lm] 12,669 20,966 Luminaire efficiency [lm/W] narrow beam Luminous flux [lm]...
- Page 10 Technical data Technical Data Service life Ambient temperature T ( +40 °C +45 °C +50 °C +55 °C +60 °C 100,000 h 80,000 h 80,000 h 60,000 h 50,000 h At the end of the service life: - Luminous flux decreases by “x” percent. - up to "y"...
-
Page 11: Transport And Storage
Transport and storage Alternative material: Enclosure: • stainless steel SS304 (1.4301 or V2A) single powder-coated • stainless steel SS316L (1.4404 or V4A) without powder coating Bracket: • stainless steel SS304 (1.4301 or V2A) without powder-coated Transport and storage • Transport and store the device only in the original packaging. •... -
Page 12: 7.2 Mounting / Dismounting, Operating Position
Mounting and installation Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations 445 [17,52] 405 [15,94] 13 x 8,50 Ø [13 x 0,33] Ø 8,50 Ø 0,33] Ø R 20 [R 0,79] 250 [9,84] 3 x 13 Ø [3 x 0,51] Ø... -
Page 13: Installation
Mounting and installation Installation 7.3.1 Opening and Closing of the Enclosure DANGER Explosion hazard due to hot built-in components! Accidents or fatal injury are almost certain to happen! • Only open the enclosure in switched-off state. • The device must be allowed to cool down for at least 15 minutes before opening it. - Page 14 The standard luminaire is delivered with 2 entries, 1 cable gland, 1 cable entry and 1 stopping plugs. Tightening torques for components from R. STAHL Schaltgeräte GmbH Luminaires with installed cable entries and stopping plugs from R. STAHL Schaltgeräte GmbH must be tightened using the following values: Tightening torque Connection thread Pressure screw Cable entry M20 x 1.5...
- Page 15 Mounting and installation Luminaires with approved cable entries and stopping plugs; not supplied by R. STAHL Schaltgeräte GmbH DANGER Explosion hazard due to impermissible cable entries and stopping plugs! Non-compliance results in severe or fatal injuries. • Only use separately certified cable entries and stopping plugs.
-
Page 16: Commissioning
Commissioning Connection terminals Standard: Optional: Spring clamp terminals Spring clamp terminals Clamping range: Klemmbereich: 0.75 ... 4 mm solid and finely stranded 0.75 ... 4 mm finely and extra finely (2 free clamping units per pole available) stranded 0.75 ... 6 mm solid (2 free clamping units per pole available) Stripping length:... -
Page 17: Maintenance, Overhaul, Repair
Maintenance, Overhaul, Repair • Check whether all the cable entries and stopping plugs have been tightened firmly. • Check if all conductors have been clamped firmly. • Check if the line voltage and the rated operational voltage are consistent. • Check if the permissible conductor diameter for the corresponding cable entries have been used. -
Page 18: Maintenance
Maintenance, Overhaul, Repair Maintenance DANGER Explosion hazard due to hot built-in components! Accidents or fatal injury are almost certain to happen! • Only open the enclosure in switched-off state. • The device must be allowed to cool down for at least 15 minutes before opening it. -
Page 19: Repair
R. STAHL Schaltgeräte GmbH. Returning the device Use the "Service form" to return the device if repair or service is required. On the internet site "www.stahl-ex.com" under "Downloads > Customer service": • Download the service form. • Fill out the service form. -
Page 20: Disposal
Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. For accessories and spare parts, see data sheet on our homepage www.r-stahl.com.
