- Page 1 Operating instructions Additional languages r-stahl.com Floodlight Series 6521/4...
-
Page 2: Table Of Contents
Contents General Information ....................3 Manufacturer .......................3 Information regarding the Operating Instructions ..........3 Further Documents .....................3 Conformity with Standards and Regulations ............3 Explanation of the Symbols ................4 Symbols in these Operating Instructions ............4 Warning Notes ....................4 Symbols on the Device ..................5 Safety Notes .......................5 Operating Instructions Storage ................5 Safe Use ......................5... -
Page 3: General Information
General Information General Information Manufacturer R. STAHL Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. - 5 Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area 74638 Waldenburg Singaperumal Koil, Kancheepuram Dist., Germany Tamil Nadu – 603 204, INDIA Phone: +49 7942 943-0... -
Page 4: Explanation Of The Symbols
Explanation of the Symbols Explanation of the Symbols Symbols in these Operating Instructions Symbol Meaning Tips and recommendations on the use of the device Danger due to explosive atmosphere Danger due to live components Warning Notes Warnings must be observed under all circumstances, in order to minimize the risk due to construction and operation. -
Page 5: Symbols On The Device
• Use the device in accordance with its intended and approved purpose only. • Always consult R. STAHL Schaltgeräte GmbH if using the device under operating conditions which are not covered by the technical data. • We cannot be held liable for damage to the device caused by incorrect or unauthorised use or non-compliance with these operating instructions. -
Page 6: 3.3 Intended Use
Function and Device Design Intended Use The luminaire is equipment • for lighting areas, work spaces and objects • can be used indoors and outdoors • for stationary mounting • for use in Zones 21, 2, 22 and in the safe area Modifications and Alterations DANGER Explosion hazard due to modifications and alterations to the device! -
Page 7: Device Design
Function and Device Design Device Design 17215E00 Luminaire enclosure Mounting bracket Cable gland Lamp holder Opening for restricted Connection terminal breathing test 250341 / 6521615300 Floodlight 2021-02-22·BA00·III·en·01 Series 6521/4... -
Page 8: Technical Data
Technical Data Technical Data Explosion Protection Global (IECEx) Gas and dust IECEx TUR 10.0014 Ex nR IIC T Ex tb IIIC T IP66 Db Europe (ATEX) TÜV 11 ATEX 7008 E II 3G Ex nR IIC T Dust TÜV 10 ATEX 7875 E II 2D Ex tb IIIC T °C IP66 Db Temperature class... - Page 9 Technical Data Technical Data Electrical data Rated operational 220 to 240 V AC / DC ±6%; 0, 50, 60 Hz voltage Power Type 500 W 2.17 A 2.17 A 1000 W 4.35 A 4.35 A 230 V AC ±6%; 50 Hz compensated uncompensated Power...
- Page 10 Technical Data Technical Data 208 V AC ±6%; 60 Hz compensated uncompensated Power Type 70 W HST / HIT 0.39 A 0.50 A 0.92 1.00 A 1.30 A 0.37 150 W HST / HIT 0.80 A 1.50 A 0.94 1.80 A 2.70 A 0.42 400 W...
- Page 11 Technical Data Technical Data Inrush current maximum number of light fittings per miniature circuit breaker: compensated Type HIT / HST 500 W 1000 W 70 W 150 W 250 W 400 W 600 W B10A B16A B20A B25A C10A C16A C20A C25A uncompensated...
-
Page 12: Transport And Storage
Mounting U-shaped holding bracket made of stainless steel, continuously swivelable around the rotary axis of the flood lights. For further technical data, see r-stahl.com. Transport and Storage • Transport and store the device only in the original packaging. • Store the device in a dry place (no condensation) and vibration-free. -
Page 13: Mounting And Installation
Mounting and Installation Mounting and Installation DANGER Explosion hazard due to incorrect installation of the device! Non-compliance results in severe or fatal injuries. • Carry out installation strictly according to the instructions and national safety and accident prevention regulations to maintain the explosion protection. - Page 14 Mounting and Installation Dimensional drawings (all dimensions in mm [inches]) – Subject to modification 450 [17,72] 360 [14,17] 250 [9,84] 200 [7,87] 150 [5,91] 41,50 Ø [3 x 0,35] [1,63] Ø 85,50 [3,37] Ø Ø Ø [4 x 0,35] [7 x 0,51] [3 x 0,35]...
- Page 15 Mounting and Installation Dimensional drawings (all dimensions in mm [inches]) – Subject to modification 450 [17,72] 360 [14,17] 250 [9,84] 200 [7,87] 150 [5,91] 46,80 Ø [1,84] [3 x 0,35] Ø 95,50 [3,76] Ø Ø Ø [4 x 0,35] [7 x 0,51] Ø...
-
Page 16: 7.2 Mounting / Dismounting, Operating Position
Mounting and Installation Mounting / Dismounting, Operating Position The mounting position of the floodlight is optional. The luminaire axis must be horizontal. DANGER Explosion hazard due to inadmissible heating! Non-compliance results in severe or fatal injuries. • Avoid external heat sources and/or direct sunlight (risk of change of temperature class or change of maximum permissible surface temperature). - Page 17 Mounting and Installation 7.3.2 Electrical Connections Electrical connection Observe the maximum clamping possibility of the connection terminals (see chapter "Technical data"). Observe the following when connecting to the electrical connection: • Clamping must be carried out precisely. • Do not clamp any part of the conductor insulation. •...
- Page 18 Mounting and Installation Loop in/loop out wiring of the mains connection Loop in/loop out wiring with max. 12 A possible • Insert the cable. 21967E00 • Connect the conductor to the spring clamp terminal. • Check that the cable is clamped properly.
- Page 19 The standard luminaire is delivered with 3 lead-in holes, 1 cable glands and 1 stopping plug. Tightening torques for components from R. STAHL Schaltgeräte GmbH Luminaires with installed cable entries and stopping plugs from R. STAHL Schaltgeräte GmbH must be tightened using the following values: Tightening torque Connection thread Pressure screw Cable entry M20 x 1.5...
-
Page 20: Commissioning
Commissioning Commissioning DANGER Explosion hazard due to incorrect installation! Non-compliance results in severe or fatal injuries. • Check the device for proper installation before commissioning. • Comply with national regulations. DANGER Explosion hazard due to incorrect installation! Non-compliance results in severe or fatal injuries. •... -
Page 21: Operation
The control gear is defective. Replace the control gear. If the error cannot be eliminated using the mentioned procedures: • Contact R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number of the device •... -
Page 22: 10.1 Maintenance
Maintenance, Overhaul, Repair 10.1 Maintenance • Consult the relevant national regulations to determine the type and extent of inspections. • Adapt inspection intervals to the operating conditions. • Perform maintenance and repair work in accordance with IEC 60079-17 and IEC 60079-19. Observe the relevant national regulations in the country of use. - Page 23 Recommendation Check the luminaire by using the handheld testing instrument for restricted breathing from R. STAHL Schaltgeräte GmbH (see data sheet). The test should only be carried out at constant temperature conditions. If the luminaire is only marked with the type of protection for dust (IIIC), the cable entries and stopping plugs do not need to meet the requirements for restricted breathing (nR).
-
Page 24: 10.2 Repair
• Only return or package the devices after consulting R. STAHL! Contact the responsible representative from R. STAHL. R. STAHL's customer service is available to handle returns if repair or service is required. • Contact customer service personally. • Go to the r-stahl.com website. -
Page 25: Cleaning
Malfunction or damage to the device due to the use of non-original components. Non-compliance can result in material damage. • Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH. For accessories and spare parts, see data sheet on our homepage r-stahl.com.
