JTS G-2 Instruction Manual

Uhf pll dual channel diversity system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
G-2/G-2TH/G-2TB
Instruction Manual
UHF PLL Dual Channel Diversity System
English/繁體中文

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-2 and is the answer not in the manual?

Questions and answers

Related Manuals for JTS G-2

Summary of Contents for JTS G-2

  • Page 1 G-2/G-2TH/G-2TB Instruction Manual UHF PLL Dual Channel Diversity System English/繁體中文...
  • Page 2 5-2 Transmitter installation // G-2TH 5-3 Transmitter installation // G-2TB 5-4 Installation of Condenser Microphones 6. System operation 6-1 How to use // G-2 6-2 How to use // G-2TH 6-3 How to use // G-2TB 7. Notes for the product...

  • Page 3: Important Caution

    1. Important Caution • Always makes all connections before plugging the unit into an AC power outlet. • Do not leave the device in a place neither with high temperature nor high humidity. • Always do not handle the power cord with wet hands! •...

  • Page 4: Specification

    3. Specification 3-1 Receiver // G-2 Model Frequency oscillation Phase-locked loop, PLL Carrier frequency 470~960 MHz(as per local regulations) Bandwidth 36MHz Signal/noise ratio >100dB(A) Total harmonic distortion <0.6%@1KHz Receiving sensitivity -95dBm S/N>80dB General frequency response 50Hz~16KHz±2dB Antenna connector BNC female...

  • Page 5: Optional Condenser Microphone

    3-3 Body-pack Transmitter // G-2TB Model G-2TB Frequency Oscillation Mode Phase-locked loop (PLL) Carrier Wave Frequency 470~960MHz Range RF Power Output 3mW/10mW(as per local regulations) RF Stability <±10KHz Fc Modulation Frequency Shift ±48KHz Harmonic Radiation <-50dBc Functions Mute, auto off, sensitivity adjustment, low power indication, RF power Display By LCD+LED Input Port...
  • Page 6 • Headset Microphone Model No CM-235i CX-504 Connector 801C4 (4P Mini XLR ) 4P Mini XLR Frequency Response 50~18,000 Hz 30~18,000 Hz Polar Pattern Omni-directional Cardioid Sensitivity (at 1000Hz) -53±3 dB -68±3 dB Impedance 1.8kΩ 680Ω Max. SPL for 1% THD 130dB 130dB 155mm(W)*...

  • Page 7: Parts Identification & Accessories

    4. Parts Identification & Accessories 4-1 Receiver // G-2 Back Front Serial No.: Serial No.: DCV INPU DCV INPUT T Freq.: Freq.: 12-15V/1A AF OUTPU AF OUTPUT T AF OUTPUT BALANCE AF OUTPUT BALANCED D UNBALANCE UNBALANCED D ANT.B ANT.B...
  • Page 8 G-2 LCD display content Content Displayed under the Non-Setting Mode: RF: Radio Frequency Signal Intensity AF : Audio Signal Intensity : Transmitter Battery Level : Frequency (Group/Channel) : Frequency : Key Lock (Key Lock ON) : Volume Scan ID SETUP Menu RX1: Set the Receiver's Channel 1.
  • Page 9 4-2 UHF PLL hand-held transmitter // G-2TH Mute/Power: push once to turn the unit on. While the unit is on, push once to mute and push again to talk. Push and hold for 2 seconds to turn off. LED indicator: it shows the transmitter’s status, including battery level and mute.
  • Page 10 4-4 Optional Condenser Microphone (OPTION) • Lavaliere Microphone // CM-501Hi / CM-201i / CM-125i Clip 4 Pin Mini XLR Windscreen CM-501Hi CM-201i CM-125i • Headset Microphone // CM-214i / CM-214Ui / CM-214ULi / CM-235i /CX-504 Gooseneck Adjustable headband Headband 4 Pin Mini XLR Windscreen CM-214ULi Standard :...
  • Page 11 • Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i Boom Adjustable Headband Adjustable ear hook Detchable Cable Cable Clip CM-801 Windscreen 4 Pin Mini XLR Option 3 Pin Mini XLR 3.5 Stereo Plug Option 4Pin Hirose connecter Option CM-8015 CM-804i CM-825i...

  • Page 12: Preparing Procedures & Basic Operation

    5. Preparing Procedures & Basic Operation 5-1 How to connect the receiver 1. Connect the audio output of receiver to mixer or amplifier 1.1. The XLR output jack or 6.3mm unbalance output jack can be selected individually to connect the AF output to a mixer or amplifier for volume control. 2.
  • Page 13 5-2 Transmitter installation // G-2TH The Mute button on the hand-held unit also triggers the power-on. That’s why the unit is on as soon as the batteries are replaced. Therefore, if you do not wish to turn on after changing the batteries, keep the Mute switch on mute.

  • Page 14: Installation Of Condenser Microphones

    Plug the connector into input socket on the body-pack transmitter. MIC IN (3) Instrument Microphones The system is compatible with JTS various instrument microphones. For detail please refer to user’s manuals of these microphones. ENGLISH 13...

  • Page 15: System Operation

    6. System operation 6-1 How to use // G-2 Parameter setting Press the "SET key" for two seconds to enter the setting mode, and then press the ▲/▼ keys to select the relevant parameters to be set. 1.FREQ: frequency setting 1MHz per unit Select with▲/▼...
  • Page 16 4.Auto Scan Auto Scan OFF, 1~10 SEC Scan ID 1~225 RSSI Low, Mid, High 5.Squelch -5 (MAX) -5~+10dB +10 (MIN) 6.RX Output Level LINE Select ▲ Select ▼ 7.Audio Effect 1+2 (1) Perfect Sound Menu 1 VOCAL / BRIGHT / BASS BOOST / OUTDOOR Menu 2 MANUAL *Menu 1...
  • Page 17 (5) Howling Supress Enable Select ▲ ▼ Diseble Select (6) AGC/Noise Gate ON/OFF Noise Gate HIGH/LOW/OFF Min Gain -20 ~ 0 Max Gain 0 ~ 20 (7) Return 8.System Options (1) Display Option Contrast 0~9 (default 5) Brightness 0~9 (default 5) (2) Factory Reset Restore factory settings Cancellation...
  • Page 18 6-2 How to use // G-2TH Parameter setting Press the SET button for 2 seconds to enter the setting mode. You can enter different setting items in order, then you can press ▲/▼ button to set the parameters, and press SET again to save the setting and leave.
  • Page 19 7.Contrast contrast 0~9 (default 5) 8.Brightnes High Select with▲/▼ Select with▲/▼ 9.Light Time Always on, 5, 10, 15, 20, 25, 30sec, and always off 10.Reset YES/NO Select ▲/▼ 11.KeyLock KeyLock ON KeyLock OFF 12.Firware verion Displays the software version. 13.EXIT 14.Compatibility Mode When the device is powered off, first press and hold the SET button, then press the Power button.
  • Page 20 6-3 How to use // G-2TB Parameter setting Press the SET button for 2 seconds to enter the setting mode. You can enter different setting items in order, then you can press ▲/▼ button to set the parameters, and press SET again to save the setting and leave.

  • Page 21: Notes For The Product

    7. Notes for the product (1) In order to achieve the optimum reception condition and also extend the operating distance, please leave a “open space” between the receiver and transmitter. (2) Keep the devices away from the metal objects or any interference sources, at least 50 cm. (3) To avoid the feed-back effect, don’t leave the mic.
  • Page 22 59508-139-03...

This manual is also suitable for:

G-2thG-2tb
