Summary of Contents for Henny Penny ODS-400
- Page 1 MODEL ODS-400 R E G I S T E R W A R R A N T Y O N L I N E AT W W W. H E N N Y P E N N Y. C O M...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Page Section 1. SAFETY ...........................1-1 Section 2. ASSEMBLY ........................2-1 Section 3. OPERATION WITH EVOLUTION ELITE OPEN FRYERS .........3-1 Section 4. OPERATION WITH 500 & 600 PRESSURE FRYERS ..........4-1 Section 5. DISPOSING OF OIL INTO DISPOSAL CONTAINER ..........5-1 Section 6. -
Page 4: Section 1. Safety
ODS-400 SECTION 1. SAFETY Where information is of particular importance or is safety related, the words NOTICE, CAUTION, or WARNING are used. Their usage is described below: SAFETY ALERT SYMBOL is used with DANGER, WARNING, or CAUTION which indicates a personal injury type hazard. -
Page 5: Section 2. Assembly
ODS-400 SECTION 2. ASSEMBLY USING BOLTS & NUTS PROVIDED, ATTACH HANDLE TO SHUTTLE. REMOVE THESE PARTS AND DISCARD, THEY ARE NOT USED. CLEAN THREADS (EX: LAQUER THINNER & BRUSH) AND THEN APPLY TEFLON TAPE OR PIPE SLIDE PUMP AND TUBE... - Page 6 ODS-400 LOCATE FILTER HOSE HOLDER AND SLIDE HOLDER INTO HOLDER BRACKET AND THEN SLIDE THE FILTER HOSE ASSEMBLY INTO HOLDER Filter Hose Assembly APPLY PIPE SEALANT OR TEFLON TAPE TO THREADS OF PIPE FITTING AND ATTACH HOSE ASSEMBLY TO Holder Bracket...
-
Page 7: Section 3. Operation With Evolution Elite Open Fryers
ODS-400 SECTION 3. OPERATION WITH EVOLUTION ELITE OPEN FRYERS 1. Open the door, lift-up on the drain pan stop and pull-out the drain pan assembly, using the handle on the drain pan. Figures 1 & 2. 2. Release cover latch, and hinge back cover on oil disposal shuttle. - Page 8 ODS-400 6. With discard shuttle rolled into place, press √ button and display shows “OPEN DRAIN”. Pull-out on drain knob to open drain and display shows “DRAINING”. Oil now drains from the vat into the shuttle. If oil disposal shuttle is not properly in place, “IS DISPOSAL UNIT IN PLACE?”...
-
Page 9: Section 4. Operation With 500 & 600 Pressure Fryers
ODS-400 SECTION 4. OPERATION WITH 500 & 600 PRESSURE FRYERS 1. Move the fryer main power switch to the OFF position. 2. Remove and empty the condensation drain pan. 3. Disconnect the filter union and remove the drain pan from under the frypot. -
Page 10: Section 5. Disposing Of Oil Into Disposal Container
ODS-400 SECTION 5. DISPOSING OF OIL INTO DISPOSAL CONTAINER 1. Remove the oil disposal shuttle from under fryer and replace with the filter pan assembly. 2. Close and latch the cover and roll oil disposal shuttle to disposal container. 3. Grasp the wooden handle and remove the hose assembly from the holder. - Page 11 ODS-400 CLEANING Daily, remove the crumb catcher (Figure 6) and take it to a sink and clean with soap and water. Clean the exterior of the shuttle with a soft cloth and soap and water. It’s not necessary to clean the interior of the unit, but if desired, it can be wiped down with paper towels.
-
Page 12: Section 6. Parts Information
This section identifies and lists the replaceable parts of the Henny Penny Oil Disposal Shuttle. 6-2. GENUINE PARTS Use only genuine Henny Penny parts in your unit. Using a part of lesser quality or substitute design may result in unit damage or personal injury. - Page 13 ODS-400...
- Page 14 ODS-400 Item Part Number Number Description 91076 ASSY – FILTER HOSE ODS FP02-033 NIPPLE – ¾ NPT X 4 IN LG-BI 21753 HOSE SHORTENING DISCARD FP01-221 ¾ COUPLING HOSE 91075 WELD ASSY - FILTER RINSE HOSE FP01-097 TEE – ¾ NPT FEMALE PIPE BI FP01-140 PLUG - ¾...
- Page 15 Henny Penny Corporation P.O.Box 60 Eaton,OH 45320 1-937-456-8400 1-937-456-8402 Fax Toll free in USA 1-800-417-8417 1-800-417-8434 Fax *FM05-064-D* www.hennypenny.com Henny Penny Corp., Eaton, Ohio 45320, Revised 6-25-13...
