  • Page 1 Service Manual F5 / Electric OFE 51X FM06-077A...

  • Page 3: Table Of Contents

    Henny Penny F5/ LOV 300 Open Fryer Table of Contents Chapter 1 Overview Safety Symbols Guide Chapter 1 Installation Crated Weights Selecting the Location Clearances Unpacking Electrical Requirements Ensuring Proper Ventilation Chapter 2 Service Procedures MAP System Theory of Operation...
  • Page 4 Henny Penny F5/ LOV 300Open Fryer Power Distribution PCB Purpose Power Modulation Unit (PMU)/High Limit PCB PMU Purpose High Limit PCB Purpose Electric Heat System Theory of Operation Purpose Electric Heat System Sequence of Operation Electric Heat Safety Circuits Electric Heat Control...
  • Page 5 Henny Penny F5/ LOV 300 Open Fryer Selector Valve Drain Filter Pan Filter Pump/Motor Wash/Polish Fill Auto Top-Off System Theory of Operation Purpose Auto Top-Off System Sequence of Operation Prerequisites Level Probes Selector Valve ATO Reservoir (JIB) ATO (JIB) Pump...
  • Page 6 Henny Penny F5/ LOV 300Open Fryer Drain Purge Bulk Oil System Theory of Operation Purpose Bulk Oil System Sequence of Operation Bulk Oil Dispose Selector Valve Bulk Oil Supply Table of Contents FM06-077 A 2023...

  • Page 7: Chapter 1 Overview

    Chapter 1 Overview Safety Henny Penny products have many safety features incorporated. However, the only way to ensure safe operation is to fully understand the proper installation, operation, and main- tenance procedures. These instructions have been prepared to aid you in learning the proper procedures.
  • Page 8 Henny Penny F5/ LOV 300Open Fryer Symbol Reference No. Symbol Title Description undesirable consequences. Caution, risk Shock Hazard Identifies equipment, for example the power of electric Symbol source, that has risk of electric shock. shock Caution, hot To indicate that the marked item can be hot and...
  • Page 9 Henny Penny F5/ LOV 300 Open Fryer Symbol Reference No. Symbol Title Description Flammable ISO 7010-W021 To warn of flammable material. material Hot water To warn of hot water. Do not Heat Temperature Do not apply direct heat to the temperature probe.
  • Page 10 Henny Penny F5/ LOV 300Open Fryer Symbol Reference No. Symbol Title Description Penny distributor. Overview FM06-077 A 2023...

  • Page 11: Chapter 1 Installation

    Henny Penny F5/ LOV 300 Open Fryer Chapter 1 Installation Crated Weights Vat Config. 1 vat 2 vat 3 vat 4 vat Full 302 lb. 441 lb. 528 lb. 702 lb. 137 kg. 200 kg. 240 kg. 319 kg. Split 317 lb.

  • Page 12: Clearances

    Henny Penny F5/ LOV 300Open Fryer to the fryer. The best efficiency is obtained by a straight line operation, i.e. raw in one side and fin- ish out the other side. Order assembly can be moved away with only a slight loss of efficiency.

  • Page 13: Electrical Requirements

    Henny Penny F5/ LOV 300 Open Fryer Electrical Requirements Shock Hazard This unit must be adequately and safely grounded (earthed) or electrical shock could result. Refer to local electrical codes for correct grounding (earthing) procedures or in absence of local codes, with The National Electrical Code, ANSI/NFPA No.
  • Page 14 Henny Penny F5/ LOV 300Open Fryer Cable Restraint Secure I-bolt to building using acceptable building construction practices. Permanently connected electric fryers with casters must be installed with flexible conduit and a cable restraint, when installed in the United States. Holes are available in the rear fryer frame for securing the cable restraint to the fryer.

  • Page 15: Ensuring Proper Ventilation

    Henny Penny F5/ LOV 300 Open Fryer require a minimum wire size of 6 mm to be wired to the terminal block. It is recommended that a 30 mA rated protective device such as a residual current circuit breaker (RCCB) or ground fault circuit interrupter (GFCI) be used on the fryer circuit.

  • Page 16: Chapter 2 Service Procedures

    Henny Penny F5/ LOV 300Open Fryer Chapter 2 Service Procedures Service Procedures FM06-077 A 2023...

  • Page 17: Map System Theory Of Operation

    Henny Penny F5/ LOV 300 Open Fryer MAP System Theory of Operation Purpose The F5 Modular Architecture Platform (MAP) system allows for control of printed circuit boards (PCBs) responsible for each of the fryer's sub-systems. MAP allows the fryer sub-systems to integrate for more effective operation and communication.
  • Page 18 Henny Penny F5/ LOV 300Open Fryer Addressing of vat/heat type and PMUs/GMUs are handled by a series magnets physically moun- ted to the fryer and Hall effect sensors that are built into the component. The address for vat/heat type and PMU location is a string of binary digits 0 or 1.
  • Page 19 Henny Penny F5/ LOV 300 Open Fryer Well 1 Well 2 Well 3 Well 4 Control 1 - Control 2 - Control 3 - Control 4 - Address 1 Address 2 Address 3 Address 4 Vat 1 Vat 2 Vat 3...
  • Page 20 Henny Penny F5/ LOV 300Open Fryer NOTE - Swapping of components in the MAP system is not an effective method to troubleshoot or isolate problems, and will likely lead to system errors. NOTE - J26 Connector as viewed with control panel lowered.
  • Page 21 Henny Penny F5/ LOV 300 Open Fryer MAP System Block Diagram MAP System Theory of FM06-077A2023...

  • Page 22: Control Theory Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Control Theory of Operation Purpose The F5 touch screen control panel provides an operator or technician the fryer's user interface (UI). The F5 control also stores cooking programs and settings for the fryer's operation. One con- trol panel will be present per well which consists of a single full vat or dual split vats.
  • Page 23 Henny Penny F5/ LOV 300Open Fryer Control System Block Diagram Control Theory of Operation FM06-077 A 2023...

  • Page 24: Control/Map System Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Control/MAP System Sequence of Operation During fryer operation, the F5 MAP system is continually sending and receiving status messages for system components via the CAN bus. User initiated commands are received by the F5 touch- screen control and then sent as a CAN message packet to the appropriate device.

  • Page 25: Power Distribution Pcb

    Henny Penny F5/ LOV 300Open Fryer Power Distribution PCB Purpose Line AC voltage is supplied to the F5 fryer from the power cord and then converted to 24 volts DC by four separate power supplies. Four power supplies then independently feed 24 volts DC to the Power Distribution PCB which is used to operate all of the MAP system electronic components.
  • Page 26 Henny Penny F5/ LOV 300 Open Fryer Power Distribution PCB Block Diagram Power Distribution PCB FM06-077A2023...

  • Page 27: Power Modulation Unit (Pmu)/High Limit Pcb

    Henny Penny F5/ LOV 300Open Fryer Power Modulation Unit (PMU)/High Limit PCB PMU Purpose Control of the electric heat system for each vat is handled by a PMU that is powered by 24 volts DC from the Power Distribution PCB. Incoming to the PMU are main and level resistance tem- perature detector (RTD) probe resistances for the respective vat.

  • Page 28: High Limit Pcb Purpose

    Henny Penny F5/ LOV 300 Open Fryer High Limit PCB Purpose Monitoring of each vat's high limit safety circuit is handled by the High Limit PCB. Power for the high limit PCB is supplied by 24 volts DC from the Power Distribution PCB through its connection to the PMU.
  • Page 29 Henny Penny F5/ LOV 300Open Fryer Flashing yellow LED indicates a critical error and a power cycle to the PMU/High Limit is required PMU / High Limit PCB Block Diagram Full Vat Power Modulation Unit FM06-077 A 2023...
  • Page 30 Henny Penny F5/ LOV 300 Open Fryer Split Vat Power Modulation Unit FM06-077A2023...

  • Page 31: Electric Heat System Theory Of Operation

    Henny Penny F5/ LOV 300Open Fryer Electric Heat System Theory of Operation Purpose The F5 electric heat system uses electrical power applied through a heating element to raise the cooking oil temperature when demanded by a user and the control system. Incoming to the elec- tric heat system is three-phase electrical power, safety circuit checks, and temperature probe readings.
  • Page 32 Henny Penny F5/ LOV 300 Open Fryer Electric Heat System Block Diagram Full Vat Electric Heat System Theory FM06-077A2023...
  • Page 33 Henny Penny F5/ LOV 300Open Fryer Split Vat Electric Heat System Theory FM06-077 A 2023...

  • Page 34: Electric Heat System Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Electric Heat System Sequence of Operation Electric Heat Safety Circuits User initiated control commands to preheat the oil or to start a product cook cycle create a demand for the F5 fryer's electric heat system. Before heat can be applied, the control system checks the electronic fuse, high limit, and heating element tilt switch safety circuits to ensure they are closed.

  • Page 35: Electric Heat Control

    Henny Penny F5/ LOV 300Open Fryer 100 ohm RTD probe(s) for element temperature feedback Full vat has two RTD probes mounted to element Split vat has one RTD probe mounted per element Element Tilt Switch The electric heating element for each vat is able to be pivoted up for cleaning, or down for cook- ing.
  • Page 36 Henny Penny F5/ LOV 300 Open Fryer Heat Contactor When heat is demanded by the vat's control system a 24 volt DC signal is sent to the heat con- tactor which closes the heating element circuit providing three-phase line voltage AC to the heat- ing element.
  • Page 37 Henny Penny F5/ LOV 300Open Fryer Resistance Power Voltage System System Resistance Current System Phase- Rating Rating Voltage Wiring Phase-N Draw Type Wiring Phase (kW) (VAC) (VAC) Type (ohm) (ohm) 4 Wire 21.59 20.21 4 Wire 23.51 19.48 Full 6 Wire 14.54...

  • Page 38: Preheat

    Henny Penny F5/ LOV 300 Open Fryer Resistance Power Voltage System System Resistance Current System Phase- Rating Rating Voltage Wiring Phase-N Draw Type Wiring Phase (kW) (VAC) (VAC) Type (ohm) (ohm) 4 Wire 19.76 10.64 4 Wire 21.59 10.10 4 Wire 23.51...

  • Page 39: Rapid Heat

    Henny Penny F5/ LOV 300Open Fryer it reaches the exit point of 180°F (82°C). Afterwards, constant heating of the oil is performed up to the set point. Preheat mode is not available if the oil temperature is above 180°F (82°C).

  • Page 40: Cook Cycle

    Henny Penny F5/ LOV 300 Open Fryer Cook Cycle During a product cook cycle, the F5 control system applies heat in a varying duty cycle depending on the oil temperature readings. Generally, full heat is applied for a period at the beginning of a cook cycle to anticipate the effect of product lowering oil temperature.

  • Page 41: Oil Management System (Oms)

    Henny Penny F5/ LOV 300 Open Fryer Oil Management System (OMS) OMS Purpose Tracking of oil movement along with filter queuing and logic is managed by the OMS PCB. Primar- ily, the OMS is powered by 24 volts DC from the Power Distribution PCB. Additionally, line voltage is supplied to the OMS by two of the 15 A push button circuit breakers.
  • Page 42 Henny Penny F5/ LOV 300Open Fryer OMS Block Diagram Oil Management System FM06-077 A 2023...

  • Page 43: Filter System Theory Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Filter System Theory of Operation Purpose Regular filtering of cooking oil maintains quality, extends its life, and improves product quality. Oil filtration processes for the F5 fryer are tracked by the OMS PCB to ensure only one filter oper- ation is performed at a given time.
  • Page 44 Henny Penny F5/ LOV 300Open Fryer Filter System Block Diagram Filter System Theory of FM06-077 A 2023...

  • Page 45: Filter System Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Filter System Sequence of Operation Prompts Filter cycles for each vat are initiated through the F5 control panel using different prompts. For Express Filter cycles, the user may be prompted for a filter cycle automatically by the control, or choose to initiate one on their own.

  • Page 46: Filter Pan Switch

    Henny Penny F5/ LOV 300Open Fryer Filter Pan Switch After the user initiates a filter cycle, the F5 control system first checks to verify the filter pan is in place. Filter pan position is confirmed through a circuit from the OMS PCB through a normally open magnetic proximity switch and back to the OMS PCB.

  • Page 47: Drain

    Henny Penny F5/ LOV 300 Open Fryer Drain During the drain sequence, a 24 volt DC signal is sent from the OMS PCB to the drain valve actu- ator which causes the valve to open. With the drain valve open, cooking oil to be filtered flows by gravity from the vat to the drain trough and then to the filter pan.

  • Page 48: Wash/Polish

    Henny Penny F5/ LOV 300Open Fryer motor from the output shaft end, rotation will be in the counterclockwise or anticlockwise (CCW or ACW) direction. The filter pump input shaft connects directly to the motor shaft and the pump body is mounted to the motor hub, secured with three (3) set screws.
  • Page 49 Henny Penny F5/ LOV 300 Open Fryer RTD probes to the PMU PCB. Having a vat filled with oil and temperature increase readings, the OMS PCB opens the board mounted relay stopping single-phase line voltage to the pump motor. Opposite polarity 24 volt DC signal to close drain valve...

  • Page 50: Auto Top-Off System Theory Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Auto Top-Off System Theory of Operation Purpose Maintaining proper oil level in all vats is performed by the Auto Top-Off (ATO) system. With nor- mal use, the oil level in any vat will drop lower due cook and filter cycles. A low oil level will result in reduced oil and product quality, oil life, and ultimately nuisance tripping of the high limit safety system.
  • Page 51 Henny Penny F5/ LOV 300Open Fryer ATO System Block Diagram Auto Top-Off System Theory FM06-077 A 2023...

  • Page 52: Auto Top-Off System Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Auto Top-Off System Sequence of Operation Prerequisites Vat oil conditions that must be met before the Auto Top-Off (ATO) system engages are: Oil level status is low 30 Seconds or more after a cook cycle 60 Seconds after oil temperature has been within 10°F (6°C) below set point...

  • Page 53: Selector Valve

    Henny Penny F5/ LOV 300Open Fryer Low oil status: level probes - main probe ≤ -15°F (-8°C) Full oil status: level probes - main probe > -15°F (-8°C) Selector Valve Orientation of the selector valve to the vat being topped occurs as the first ATO action. By first rotating the selector valve to the proper vat position this allows for an open path for new oil to flow.

  • Page 54: Fill

    Henny Penny F5/ LOV 300 Open Fryer Single-phase line voltage AC from OMS PCB 30 second ATO cycle ATO pump energize time Full vat: 6 seconds Split vat: 4 seconds Remaining 20-25 seconds of ATO cycle for evaluation ATO cycle repeats if needed...

  • Page 55: Cart Dispose Theory Of Operation

    Disposal of used cooking oil is necessary whenever a vat is filled with new oil. To properly collect and transport used oil, Henny Penny offers a disposal cart that is inserted under the F5 fryer in place of its filter pan. Timing of disposing used cooking oil is entirely up to the the user with no pre- set schedule programmed into the F5 control system.
  • Page 56 Henny Penny F5/ LOV 300Open Fryer Cart Dispose Block Diagram Cart Dispose Theory of FM06-077 A 2023...

  • Page 57: Cart Dispose Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Cart Dispose Sequence of Operation Prompts Dispose to cart sequences are user initiated through the F5 control panel manually. The F5 con- trol system has no provision for automatic prompting of oil dispose sequences. During the on- screen cart dispose control prompts the user is directed to remove the filter pan and then insert the dispose cart.

  • Page 58: Drain

    Henny Penny F5/ LOV 300Open Fryer in the dispose sequence. The selector valve is a rotary valve with a fixed body and inner spool that rotates. Rotation and positioning of the selector valve inner spool is provided by a motor/en- coder assembly.

  • Page 59: Bulk Oil System Theory Of Operation

    Bulk oil systems provide the F5 fryer with a method for storing disposed and supplying fresh cook- ing oil. Processes and communication between the external (non-Henny Penny) bulk oil system and the F5 fryer are tracked by the OMS PCB. Bulk oil processes are divided into two types, bulk dispose and bulk supply.
  • Page 60 Henny Penny F5/ LOV 300Open Fryer Bulk Oil System Block Diagram Bulk Oil System Theory of FM06-077 A 2023...

  • Page 61: Bulk Oil System Sequence Of Operation

    Henny Penny F5/ LOV 300 Open Fryer Bulk Oil System Sequence of Operation Bulk Oil Dispose Control Configuration Prompts Bulk dispose sequences are user initiated through the F5 control panel manually. The F5 control system has no provision for automatic prompting of oil dispose sequences. During the on-screen bulk dispose control prompts the user is directed to drain used oil to the filter pan.

  • Page 62: Selector Valve

    Henny Penny F5/ LOV 300Open Fryer Normally open magnetic proximity switch Filter pan switch is actuated closed with pan inserted Filter Pan Collecting drained oil to be disposed is handled by the filter pan. As oil flows down through the gravity drain system it is first collected for by the dispose cart before being sent to the bulk dis- pose tank.
  • Page 63 Henny Penny F5/ LOV 300 Open Fryer Purge Clearing of old oil in the vat's plumbing is performed by the purge stage. The drain valve remains open and while the user is purging oil and a line voltage AC single-phase signal is sent from the OMS PCB to the ATO pump.
  • Page 64 Depending on bulk oil system type and fryer configuration, the flexible dispose oil line will be either supplied by Henny Penny or the bulk oil system vendor. The Henny Penny provided bulk oil dispose line has a female quick disconnect coupling end that must be mated properly to the bulk oil plumbing before disposed oil will flow.

  • Page 65: Bulk Oil Supply

    Henny Penny or the bulk oil system vendor. Vendor supplied bulk oil supply hose would have a threaded connection to the fryer rear.
  • Page 66 Henny Penny F5/ LOV 300Open Fryer Selector Valve Orientation of the selector valve to the vat or ATO reservoir (JIB) being filled occurs as the first bulk supply action. By first rotating the selector valve to the proper vat or ATO reservoir fill pos- ition this allows for an open flow path.
  • Page 67 Henny Penny F5/ LOV 300 Open Fryer Return check valve requires 2 PSI (138 mbar) OMS PCB 24 volt AC signal to bulk oil supply pump motor stops when user ends fill request to control Filling ATO Reservoir (JIB) Filling of the ATO reservoir (JIB) requires the bulk supply pump to be energized to move oil from the tank.
  • Page 69 U.S. and Canada: +1-800-417-8405 Global: +1-937-456-8405 text: +1-937-456-8405 email: technicalservices@hennypenny.com live chat Contact Parts by: Copyright belongs to Henny Penny email: partsdepartment@hennypenny.com Corporation 2023. All rights Contact Warranty by: Henny Penny Corporation 1219 U.S. 35, Eaton, OH 45320 1-937-456-8400 FM06-077A 02 March 2023...
