Summary of Contents for Deerc D20-1080P
- Page 1 Instructions For Use V 1.0 D20-1080P usa@deerc.com (USA) eu@deerc.com (EU) +1(334)336-0888...
-
Page 3: Table Of Contents
Contents Disclaimer & Warning ................Safety Guidelines ..................Maintenance ....................Package Contents ..................Drone Details ....................Transmitter Functions ................Joystick Mode ....................Preparation Before Flight Charging ....................Download App ..................Arms ......................Drone Battery ..................Propeller Guard ..................Propellers ....................Transmitter Battery ................ - Page 4 Headless Mode ..................Attitude Adjustment Trimmer ....................Stabilization Functions Altitude-Hold Function ............... APP ........................Specification ....................Contact Us ..................... General Information ...................
-
Page 5: Disclaimer & Warning
Any personal injury, property damage, legal disputes and all other adverse events caused by the violation of any of the safety instructions or due to any other factor, WILL NOT be DEERC’s responsi- bility. SAFETY GUIDELINES CHECK BEFORE USE ①... -
Page 6: Flight Environment
SAFETY GUIDELINES ④ Please perform a thorough check of the product before each use. Inspect the integrity of the parts, any signs of cracks and wear off on the propellers, battery power and effectiveness of the indicator, etc. If there is any problem found after checking the drone, please refrain from using it until the problem is resolved. -
Page 7: Operation Requirements
SAFETY GUIDELINES OPERATION REQUIREMENTS ① DO NOT use this product to follow any moving vehicles. ② During the flight, turn off the motors only in case of an emergency. ③ When the battery runs low, return the drone back to your starting point. - Page 8 SAFETY GUIDELINES ⑦ Only use the USB charging cable that comes with the drone to charge the battery. ⑧ DO NOT connect the battery directly to wall outlets or car cigarette -lighter sockets as this will damage your battery since they have different voltages.
-
Page 9: Maintenance
MAINTENANCE ① Clean the drone after each use with a clean, soft cloth. ② Avoid prolonged exposure to direct sunlight and avoid buildup of heat on the drone or batteries. ③ This device is not waterproof and must not be submerged or subjected to water under any circumstance. -
Page 10: Package Contents
PACKAGE CONTENTS Drone Transmitter Drone Battery USB Charging Propeller Guard Propeller Cable Instructions For Use V 1.0 D20-1080P usa@deerc.com (USA) eu@deerc.com (EU) +1(334)336-0888 Instructions For Screwdriver -06-... -
Page 11: Drone Details
DRONE DETAILS Propeller A Propeller B Propeller B Propeller A Camera Power Switch (Long press) Drone Battery -07-... -
Page 12: Transmitter Functions
TRANSMITTER FUNCTIONS Phone Holder Left Joystick Right Joystick Power Switch Trimmer (Long press) Power Indicator Takeoff & Landing Speed Switch /Emergency stop (Long press) 360° Flip/ Take Photo/ Headless Mode Record video (Long press) (Long press) -08-... -
Page 13: Joystick Mode
JOYSTICK MODE MODE 2 (Left hand throttle MODE 2 will be the default setting.) Left Joystick Right Joystick Ascend Forward Descend Down Down Backward Left Right Left Right Fly to Fly to Rotate Rotate Left Right Left Right MODE 1 To enter MODE 1, turn on the transmitter while holding the “Speed Switch”... -
Page 14: Preparation Before Flight
PREPARATION BEFORE FLIGHT CHARGING USB Adapter (5V/2A) Power Bank ① Connect the the drone's battery with the USB Charging Cable. ② Plug the USB Charging Cable into a USB charging port on the power bank or USB adapter (5V/2A). ③ The red indicator light on the USB charging cable will turn on when the battery is charging, and will turn off when the battery is fully charged. -
Page 15: Download App
PREPARATION BEFORE FLIGHT DOWNLOAD APP Scan the corresponding QR code and download the DE FPV V2 app for free. The interface and functions of DE FPV V2 may vary as the software version is updated. Actual user experience is based on the software version used. -
Page 16: Drone Battery
PREPARATION BEFORE FLIGHT DRONE BATTERY Pic 1 Pic 2 Installation: Push the battery correctly into the drone battery compart- ment. Make sure the battery is in place to ensure that the battery is jammed in the battery compartment. (Pic 1) Removal: Press the lock on the bottom of the battery and pull it back to remove the battery from the fuselage. -
Page 17: Propellers
PREPARATION BEFORE FLIGHT PROPELLERS HEAD Installation: ① An “A” “B” is printed on the each propeller. ② Lock the propellers to the corresponding motor shafts (the motor shafts are also marked) with a screw. ③ Rotate each screw clockwise. · The propeller is installed before the drone is packaged at the factory. -
Page 18: Transmitter Battery
PREPARATION BEFORE FLIGHT TRANSMITTER BATTERY Battery Cover 3 x 1.5V AA (Not included) As shown above, insert the battery into the transmitter. Please pay attention to the positive and negative polarity of the battery to ensure the correct installation of the battery. When the transmitter battery runs low, the power indicator of the transmitter will blink continuously. -
Page 19: Flight
FLIGHT All of the following operations in this manual use MODE 2. * If you first pair the drone with the transmitter, then with the cellphone, certain app functions will not work. Conversely, if you use the analog control sticks in the app to control the drone's movements first, you cannot pair the drone with the transmitter then. -
Page 20: Connect To Wi-Fi
FLIGHT CONNECT TO WI-FI DEERC FPV-******** Connect your phone to the Wi-Fi network created by the drone. You can check the drone’s status on the DE FPV V2 App. ① Make sure to turn off Bluetooth, Mobile Data, and VPN. Enter your phone’s Wi-Fi settings and click Wi-Fi to search for the Wi-Fi of the... -
Page 21: Calibrate The Gyro
FLIGHT CALIBRATE THE GYRO Make sure to place the drone on a level surface before calibrating the gyro. Push both joysticks down to the bottom right to calibrate the gyro. The indicator lights on the drone will blink quickly and turn solid, indicating calibration is completed. -
Page 22: Functions Details
FUNCTIONS DETAILS TAKE PHOTO/RECORD VIDEO Take Photo: Short press the Photo/Video button ( ) on the transmit- ter to take a photo. The transmitter will beep once, and the indicator light will flash once, confirming that the photo has been taken successfully. -
Page 23: Speed Switch
FUNCTIONS DETAILS SPEED SWITCH Short Press This drone comes with 3 speed modes (Low/Medium/High). Short press the ( ) button to switch between low, medium, and high speed. The transmitter beeps once to indicate Low Speed, beeps twice to indicate Medium Speed and beeps three times to indicate High Speed. (The Low Speed is the default speed mode.) The low speed is 4.59 ft/s. -
Page 24: Emergency Stop
FUNCTIONS DETAILS EMERGENCY STOP Long Press Press and hold the Emergency Stop button ( ) of the transmitter for 2 seconds, the motors will stop immediately. Be aware that you risk breakage of the drone if it falls a large distance or hits anything at a high rate of speed. -
Page 25: Headless Mode
FUNCTIONS DETAILS HEADLESS MODE The Headless Mode is a great training tool for beginner pilots. It is also useful when the drone is too far from the pilot (which makes it difficult to tell its orientation). It keeps the drone traveling forward, backward, left, or right when you move the right joystick in those directions, regardless of which way the front of the head of the drone points to. - Page 26 FUNCTIONS DETAILS HEADLESS MODE * Why is the orientation of the drone important? In normal flying mode, the control of the drone movement can sometimes be counter-intuitive for beginners. For instance, when the drone is in the air with its head pointing to your right, if you push the right joystick forward, the drone will fly to your right, instead of flying forward.
-
Page 27: Attitude Adjustment
ATTITUDE ADJUSTMENT TRIMMER Trim adjustments are designed to counter drifts not caused by airflow. F/B Sidewards Drift Trim: Short press the Trimmer button ( ) to enter the Trimmer function. If the drone drifts forward, push the right joystick down to balance the drone. If the drone drifts backwards, push the right joystick up to balance the drone. -
Page 28: Stabilization Functions
STABILIZATION FUNCTIONS AlTITUDE-HOLD FUNCTION The drone is designed with altitude-hold function so the drone can maintain its altitude after you release the left joystick (the left joystick will automatically spring back to the middle). -24-... -
Page 29: App
12 13 14 Return: Tap to return to APP main screen. On/Off: Tap to turn on/off the virtual joysticks. Only when it is on the drone can be controlled by virtual joysticks. The virtual joysticks work just the same as real joysticks on transmitter. This feature is only effective when the transmitter is not connected. - Page 30 Draw a line freely within the designated box, and the drone will follow the drawn trajectory. The maximum distance for the aircraft's pointed flight is 3 meters. During Tap Fly, the drone cannot be manually controlled. Please ensure that there are no people or obstacles within a radius of five meters, while using this feature to prevent potential injury or damage to...
- Page 31 VR Split Screen: This feature requires a VR device (sold separate- ly, not necessarily be of Deerc brand). Tap to switch to VR mode and mount the phone onto the VR device. The drone cannot be controlled via VR devices. Using this feature allows the user to experience immersive...
-
Page 32: Specification
SPECIFICATIONS DRONE Model: D20 Weight: 71g/2.5oz Max Flight Speed: 11.15ft/s Max Wind Speed Resistance: 4.92ft/s Max Flight Height: 131 ft/40m Max Flight Time: 10 minutes (per battery) Motor Model: 716 Operating Temperature Range: 32° to 104°F (0° to 40°C) Size: 178*117*42 mm(Unfolded) 94*90*42 mm(Folded) DRONE BATTERY Model: 701855P... -
Page 33: Contact Us
Max Transmission Distance: 98 feet/30m (outdoor and unobstructed) Photo Formats: JPEG Video Formats: MP4 USB CHARGING CABLE Input: 5V/2A Rated Power: ≤10W CONTACT US Please do not hesitate to contact us if you need further support. usa@deerc.com (USA) eu@deerc.com (EU) +1(334)336-0888 -29-... -
Page 34: General Information
The Supplier's Declaration of Conformity is available at the following address: https://www.deerc.com/Download/US/D20_FCC_sDoC.pdf. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 35 GENERAL INFORMATION WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiator &...
- Page 36 GENERAL INFORMATION CAN NMB-003 (B) RF Exposure Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator & your body.
- Page 37 GENERAL INFORMATION BATTERY WARNING: 1. Failure to follow all the instructions may result in serious injury, irreparable damage to the battery may cause a fire, smoke or explosion as well. 2. Always check the battery’s condition before charging or using it. 3.
- Page 38 2014/53/EU, the RoHS Directive 2011/65/EU, Toy Directive 2009/48/EC and UAS Delegated Regulation 2019/945/EU amended by Delegated Regulation 2020/1058/EU. The full EU declaration of conformity is accessible at the following website: http://www.deerc.com/Download/CE/D20_EU_DOC.pdf This product can be used among EU member states. -34-...
- Page 39 GENERAL INFORMATION MANUFACTURER INFORMATION Manufactured by Xiamen Huoshiquan Import & Export CO.,LTD. Address: Unit 1, Room 501, Hongxiang Building, No.258 Hubin Nan Road, Siming District, Xiamen, China +1(334)336-0888 MTOM Statement D20 is a quadrotor drone. The MTOM of D20 is 71g, including the propellers, the Flight Battery, which is compliant with C0 requirements.
- Page 40 GENERAL INFORMATION 2. Prevent the drone from flying in restricted airspace. Refer to the Flight Environment Requirements section for details. 3. If the drone disconnects from the transmitter, the indicator light on the drone will continuously flash. The drone will slowly descend at its current position until it lands.
