Technaxx
EN
Wild Cam TX–44
User Manual
The Declaration of Conformity for this device is under the
Internet link: www.technaxx.de/ (in bottom bar
"Konformitätserklärung"). Before using the device the first time,
read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14
cent/minute from German fixed-line and 42 cent/minute from
mobile networks). Free Email: support@technaxx.de
Features
Security camera for indoor and outdoor use
Ideal for viewing wild animals and for monitoring houses
2.7" CMOS sensor with 2 mega pixels
Video and photo function are selectable
Standby time up to ~ 290 days
Motion and infrared sensor for night shots
1.2 seconds triggering time
Motion Detection Distance up to ~ 15m
IPX4 splash water proof
Easy handling and installation
0
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wild Cam TX-44 and is the answer not in the manual?

Questions and answers

Related Manuals for Technaxx Wild Cam TX-44

Summary of Contents for Technaxx Wild Cam TX-44

  • Page 1 Wild Cam TX–44 User Manual The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Table of Contents 1. Introduction………..…………………..……..…..2 System Requirements...……...……………..… 2 2. Getting to know your camera…………………….. 3 Part Names (front and rear view)..……..… 3 3. Basic Camera Operation....………………… 4 Installing Batteries and MicroSD Card..... 5 Power On…..…………….…………….…….

  • Page 3: Introduction

    All manuals and user guides at all-guides.com 1. Introduction System Requirements PC System Requirement ® Intel Core2Duo 1.8G or AMD equivalent CPU Hi-speed USB2.0 port 1 GB RAM internal memory minimum HD color monitor nVIDIA GeForce MX440 or above, AMD (ATi) Radeon 9200 or above DirectX 9.0 or higher ®...

  • Page 4: Getting To Know Your Camera

    All manuals and user guides at all-guides.com 2. Getting to know your camera Part Names Front View Rear View...

  • Page 5: Basic Camera Operation

    All manuals and user guides at all-guides.com 3. Basic Camera Operation Installing Batteries and SD Card 1. Release 2 Fastener Locks of the camera. 2. Than take out the Rear Cover.

  • Page 6: Installing Batteries And Microsd Card

    All manuals and user guides at all-guides.com 3. Make sure the Power Switch of the camera is OFF. 4. Install the MicroSD card. Be sure to observe the correct polarity with clipped corner on the card to the right. All the pictures and videos will be saved in the memory card.
  • Page 7 All manuals and user guides at all-guides.com 6. Put the Battery Box into the Battery Room of the camera and make sure to observe correct polarity. 7. Press the Battery Box to the end of the Battery Room. Make sure the Battery Box has fixed in the Battery Room.

  • Page 8: Power On

    All manuals and user guides at all-guides.com Power On 1. Slide the Power Switch to ON in the left side. 2. It will initial the camera system. Wait until the LCD display the default mode on the preview screen. 3. Slide the Power Switch to the right side to turn off the camera.

  • Page 9: Operation Mode

    All manuals and user guides at all-guides.com 4. Operation Mode Define use which operation mode to record image. 1. Power On the camera. 2. Press the Menu button to enter the Main Menu. 3. Use the Up / Down key and change the Menu to Operation Mode.

  • Page 10: Pir Photo

    All manuals and user guides at all-guides.com PIR PHOTO 1. In OPERATION MODE menu, press the OK Button then the mode item is blinking. 2. Use Up / Down Keys to change the operation mode to PIR PHOTO then press OK Button again. (PIR PHOTO (default) / PIR VIDEO / TIME LAPSE) 3.

  • Page 11: Photo Quality

    All manuals and user guides at all-guides.com PHOTO QUALITY Set the resolution of still picture. The higher resolution can provide high quality picture. But it needs more memory space to save and reduce the picture number of the memory card. HIGH 5.0MP (default) / MEDIUM 2.0MP / LOW 0.5MP / BEST 8.0MP (interpolated) PHOTO DELAY...

  • Page 12: Pir Video

    All manuals and user guides at all-guides.com CONT. SHOT Set the number of continuous shoot. SINGLE (default) / 9 PHOTOS / 8 PHOTOS / ..2 PHOTOS PIR VIDEO 1. In OPERATION MODE menu, press the OK Button then the mode item is blinking. 2.

  • Page 13: Video Quality

    All manuals and user guides at all-guides.com VIDEO QUALITY Select a resolution size of video record. The higher resolution can provide high quality video. But it needs more memory space to save and reduce the record time of the memory card. 1280 X 720 (default) / 720 X 480 VIDEO LENGTH Define the time length of video record for each clip.
  • Page 14 All manuals and user guides at all-guides.com These settings are amount of time when the camera wait before it will take another video. The delay time of PIR sensor will recount after the video record finish. For example: The Rec Time is 15 seconds and PIR delay time is 30 seconds.

  • Page 15: Time Lapse

    All manuals and user guides at all-guides.com TIME LAPSE 1. In OPERATION MODE menu, press the OK Button then the mode item is blinking. 2. Use Up / Down Keys to change the operation mode to TIME LAPSE then press OK Button again. T.L.
  • Page 16 All manuals and user guides at all-guides.com T.L. DELAY Time Lapse is an interval capture function. You can set an interval time to take picture one by one. The camera will take a picture one by one after every 15 seconds automatic until the memory full or battery power empty or terminate it by manual.

  • Page 17: Setting

    All manuals and user guides at all-guides.com 5. Setting For change all default settings if need. 1. Power On the camera. 2. Press the Menu button to enter the Main Menu. 3. Use the Up / Down keys and change the Menu to Setting.

  • Page 18: Setup Date

    All manuals and user guides at all-guides.com SETUP DATE Adjust the current date. Use the Up / Down keys to adjust the number and use the Left / Right keys to shift next item M/D/Y. SETUP TIME Adjust the current time. Use the Up / Down keys to adjust the number and use the Left / Right keys to shift next item HR mm:ss.

  • Page 19: Camera Name

    / video clips were taken by which camera. Use the Up / Down keys to change the alphabet / number and use the Left / Right keys to shift next text. TECHNAXX (default)
  • Page 20 All manuals and user guides at all-guides.com INFO BAR Print an information stamp on the picture. You can see the record date, time and some other information from the picture directly. ON (default) / OFF Record the temperature during Temperature: this picture taken.
  • Page 21 All manuals and user guides at all-guides.com The main purpose is the active of most animals have a relation with the moon phase. This information is helpful to search the animals. Capture Time: Record the time information when this picture taken. Capture Date: Record the date information when this picture taken.

  • Page 22: Erase All

    All manuals and user guides at all-guides.com ERASE ALL Delete all files (picture / video) in the memory card. NO (default) / YES Note: 1. All data will be lose and can’t restore after delete. Make sure you have backup all data in the hard disk or other storage device before format it.

  • Page 23: Test Mode

    All manuals and user guides at all-guides.com 3. Use the Up / Down keys and change the Menu to Version. 4. The firmware version show on the screen. 6. TEST Mode Before camera. Make sure the PIR sensor work normally. Test its sensitivity and a correct detection zone for your purpose.
  • Page 24 All manuals and user guides at all-guides.com 1. Slide the Power Switch to TEST position. 2. Close the rear cover. 3. Lock Fastener Locks completely then fix the camerawhere you want to monitor.

  • Page 25: Surveillance Mode

    All manuals and user guides at all-guides.com 4. Walk back and forth in front of the camera. The Red TEST LED will illuminate when the camera sensor has detected you. Using this method you can accurately position your camera as desired. Note: This TEST LED does not illuminate in Surveillance mode.
  • Page 26 All manuals and user guides at all-guides.com 2. The Operation Mode show which record mode is in use. The File Counter show how many files have saved in the memory card. 3. The camera starts to countdown 30 seconds and show it on the Delay Time Counter.

  • Page 27: Playback

    All manuals and user guides at all-guides.com 8. Playback Download 1. Release 2 Fastener Locks of the camera. 2. Than take out the Rear Cover. 3. Make sure the Power Switch of the camera is Off.

  • Page 28: Playback From Pc

    All manuals and user guides at all-guides.com 4. Take the micro SD card out and insert it to a compatible card reader. 5. You may download your record files from the "X:\DCIM\100SIMOS" folder. Playback from PC The video file format is AVI which can be played by Windows Media Player with PC.

  • Page 29: Appendix

    Power Source 8 x LR6 AA batteries* (* not included) Storage MicroSDHC up to 32GB Weight 324g (without batteries) Dimension (L) 13.0 x (W) 5.5 x (H) 19.0cm Package contents Wild Cam TX-44, Belt cable, Battery box (without batteries), User Manual...

  • Page 30: Ui Flow

    All manuals and user guides at all-guides.com UI Flow OPERATION MODE (default) VIDEO DELAY PIR PHOTO (default) 5 S (default) PHOTO QUALITY 30 M HIGH 5.0MP (default) 10 M MEDIUM 2.0MP LOW 0.5MP BEST 8.0MP 30 S 15 S PHOTO DELAY 10 S 5 S (default) 30 M...
  • Page 31 12HR 03:45AM (default) 24HR 03:45 TIME START 06:00PM TIME STOP 18:00PM TIME SHOT OFF (default) NIGHT ONLY DAY ONLY CAMERA NAME TECHNAXX INFO BAR ON (default) LANGUAGE ENG (default) TEMP UNIT ° F (default) ° C ERASE ALL NO (default) DELETEING...

  • Page 32: Warnings & Hints

    Wipe the cleaned device accurately. Important Notice: Should battery fluid leak from a battery, wipe the battery case with a soft cloth dry. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany...
