DP3000HR-01/A
DP3000HR-01/B
INSTALLATION & OPERATORS
MANUAL
COPY YOUR MODEL AND SERIAL NUMBER HERE
No other WINCO generator has the same serial number as yours.
If you should ever need to contact us concerning this unit, it will
help us to respond to your needs faster.
16200-001
MODEL __________________________________________________
SERIAL NUMBER _________________________________________
PURCHASE DATE _________________________________________
DEALER NAME ___________________________________________
DEALER PHONE # ________________________________________
www.wincogen.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winco DP3000HR-01/B
Summary of Contents for Winco DP3000HR-01/B
- Page 1 MANUAL COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as yours. If you should ever need to contact us concerning this unit, it will help us to respond to your needs faster.
-
Page 2: Table Of Contents
SAFETY INFORMATION manual before starting and operating the generator. SPECIFICATIONS USING THIS MANUAL GENERATOR Congratulations on your choice of a WINCO generator. You ENGINE have selected a high-quality, precision-engineered generator INTRODUCTION designed and tested to give you years of satisfactory service. -
Page 3: Safety Information
SAFETY INFORMATION WARNING: FIRE HAZARD Gasoline and other fuels present a hazard of possible CALIFORNIA PROPOSITION 65 explosion and/or fire. A. Do not refuel when the engine is running or This product contains crude oil, gasoline, diesel fuel and hot. other petroleum products, Antifreeze to which can expose B. -
Page 4: Specifications
SPECIFICATIONS GENERATOR Model DP3000HR-01/A DP3000HR-01/B Surge Watts 3,000 Continuous Watts 2,500 Volts Amps 20.8 Generator Manufacturer Mecc Alte Spa Generator Model Number S16W-75 Part Number 16346-017 Rotor Resistance 2.62 Ohms Stator Resistance 0.97 Ohms Cap Winding Resistance 5.46 Ohms Capacitor 12.5 mF... -
Page 5: Introduction
INTRODUCTION TESTING POLICY Before any generator is shipped from the factory, it is fully checked for performance. The generator is loaded to its full capacity, and the voltage, current, and frequency are carefully checked. Rated output of generator is based on engineering tests of typical units, and is subject to, and limited by, the temperature, altitude, fuel, and other conditions specified by the manufacturer of applicable engines. -
Page 6: Unit Capabilities
UNIT CAPABILITIES GENERATOR CONNECTIONS DP3000HR-01/A: Rated at 3,000 starting Watts and 2,500 continuous Watts. Generator full output can be drawn from the 120 Volt GFCI NEMA 5-20 receptacles, mounted on the end of the generator. STARTING ELECTRIC MOTORS Electric motors require much more current (amps) to start them than to run them. -
Page 7: Preparing The Unit
damage. If any damage is noted, it is always easiest to engine. If the oil level drops below a certain point the low oil refuse the shipment and let WINCO take care of the module on the engine will shut it down. This low oil warning freight claim. -
Page 8: Initial Start Up
INITIAL START UP 6. If the choke rod has been moved to the CLOSED position to start the engine, gradually move it to the OPEN position as the engine warms up. The throttle control on these generators is preset and locked to operate at 3600 RPM (nominal) with no load speed set at 3690 RPM. - Page 9 fuel tank, it must be drained into an approved Position the throttle lever for the desired engine speed. container. C. Start the engine and allow it to run until all the fuel in the carburetor and the fuel lines has been used up and the engine stops.
-
Page 10: Connecting The Loads
CONNECTING THE LOADS STANDARD PORTABLE GENERATOR Your WINCO portable generator ships with a bonded The engine-generator covered in this manual was designed neutral. You can safely use this generator without external for portable use. Do NOT operate indoors. The unit should grounding as long as all loads are powered through the be stored in a warm, dry location. -
Page 11: Yourgen
For normal usage, the speed setting should The WINCO YourGen meter allows you to see useful not be changed. If the generator is being run continuously information about your generator from the front panel... - Page 12 Replace the battery having the POSITIVE (+) side down. the 120 Volt GFCI NEMA 5-20 receptacles, mounted on the end of the generator. Ensure the battery is secured between the battery connections. Change Oil Warning - After the first 50 hours, the engine oil should be changed. The YourGen meter will light up the oil icon ( ) and the Install Battery Between These Two Points...
-
Page 13: Engine Care
Outdoor temperatures determine the proper oil viscosity for the engines. Winco recommends our 5W-30 fully synthetic 3. Remove the foam filter from the oil to give you excellent protection in cold temperatures paper filter. -
Page 14: Sediment Cup
Paper air filter element: Tap the filter element several times on a hard surface to remove dirt, or blow compressed air [not exceeding 30 psi through the filter element from the inside. Never try to brush off dirt; brushing will force dirt into the fibers. Foam air filter element: Clean in warm soapy water, rinse, and allow to dry thoroughly. -
Page 15: Generator Care
GENERATOR CARE Proper care and maintenance of the generator is necessary to ensure a long trouble free life. EXERCISING THE GENERATOR The generator should be operated every three to four weeks. It should be operated for a period of time sufficient to warm the unit up and to dry out any moisture that has accumulated in the windings. -
Page 16: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Won’t start Low oil level Fouled spark plug Out of fuel Start switch in OFF position Fuel Valve turned off Choke Open Voltage too low Engine speed is too low Generator overloaded Defective stator Defective rotor (field) Defective capacitor Circuit breaker trips Defective load... -
Page 17: Control Panel Wiring Diagram
CONTROL PANEL WIRING DIAGRAM OPM-130/C... -
Page 18: Limited Warranty
Air cooled units purchased for stock have 1 year to be sold. The warranty to the original retail customer commences on the date of sale of the product to them. All liquid cooled units have 180 days from the Winco invoice to submit a start up date. If no startup form is submitted, then warranty period starts on the Winco invoice date unit was sold. - Page 19 Note 2: 3rd Year warranty coverage is parts only/no labor. Note 3: Round trip mileage is limited to 200 miles per trip and a total of 2 trips per repair unless authorized in writing by the WINCO Service Dept.
- Page 20 225 S. CORDOVA AVE • LE CENTER, MN 56057 Sales: 507-357-6821• sales@wincogen.com Service: 507-357-6831 • service@wincogen.com www.wincogen.com OPM-130/C...
