DP14000VE-03/A
DP14000VE-03/B
GENERATOR
INSTALLATION AND
OPERATORS MANUAL
COPY YOUR MODEL AND SERIAL NUMBER HERE
No other WINCO generator has the same serial number as
yours. If you should ever need to contact us concerning this
unit, it will help us to respond to your needs faster.
MODEL
16200-007
SERIAL NUMBER
PURCHASE DATE
DEALER NAME
DEALER PHONE #
www.wincogen.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winco DP14000VE-03/B
Summary of Contents for Winco DP14000VE-03/B
- Page 1 OPERATORS MANUAL COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as yours. If you should ever need to contact us concerning this unit, it will help us to respond to your needs faster.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION SAVE THESE INSTRUCTIONS SPECIFICATIONS GENERATOR ENGINE INTRODUCTION TESTING POLICY INTENDED USES RESTRICTED USES UNIT CAPABILITIES GENERATOR CONNECTIONS STARTING ELECTRIC MOTORS PREPARING THE UNIT UNPACKING LUBRICATION OIL RECOMMENDATIONS OIL ALERT SYSTEM FUELING BATTERY INSTALLATION BATTERY CHARGING LIFTING EYE INSTALLATION OPTIONAL DOLLY KIT INITIAL START UP... -
Page 3: Safety Information
SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS WARNING: FIRE HAZARD This engine generator set has been designed and Gasoline and other fuels present a hazard of possible manufactured to allow safe, reliable performance. Poor explosion and/or fire. maintenance, improper or careless use can result in A. -
Page 4: Save These Instructions
Should you experience a problem please follow the “Troubleshooting Tables” near the end of this manual. The warranty listed in the manual describes what you can expect from WINCO should you need service assistance in the future. OPM-167/C... -
Page 5: Specifications
SPECIFICATIONS GENERATOR Model DP14000VE-03/A DP14000VE-03/B Surge Watts 14,000 Continuous Watts 11,760 Volts 120/240 Amps 98/49 Generator Manufacturer Mecc Alte Generator Model Number S20F-230/A Part Number 16428-002 Capacitors 300323-112 (qty 1) 300323-212 (qty 2) ENGINE Engine Manufacturer Briggs & Stratton Engine Model Number... -
Page 6: Introduction
INTRODUCTION TESTING POLICY Before any generator is shipped from the factory, it is fully checked for performance. The generator is loaded to its full capacity, and the voltage, current, and frequency are carefully checked. Rated output of generator is based on engineering tests of typical units, and is subject to, and limited by, the temperature, altitude, fuel, and other conditions specified by the manufacturer of applicable engines. -
Page 7: Unit Capabilities
UNIT CAPABILITIES The heavy surge of current required for starting motors GENERATOR CONNECTIONS is required for only an instant. The generator will not be damaged if it can bring the motor up to speed in a few DP14000VE: 120 Volt and 240 Volt receptacles are seconds of time. -
Page 8: Preparing The Unit
If any damage is noted, it is always easiest to consumption. Check the oil level frequently. refuse the shipment and let WINCO take care of the freight 5W-30 claim. If you sign for the unit, the transfer of the ownership... -
Page 9: Battery Installation
Never use gasoline that has been stored for an extended normal operating conditions, but were not intended to be period of time as the fuel will lose its volatile properties used as a battery charger. and you will be left with varnish residue. The varnish like substance will clog the carburetor and will not burn WARNING properly. -
Page 10: Initial Start Up
INITIAL START UP STARTING HINTS WARNING: PERSONAL INJURY Improper maintenance, or failure to fix any problems 1. COLD WEATHER during operation, could cause equipment damage A. Use the proper oil for the temperature expected. and possible serious injury. Always inspect unit prior to B. - Page 11 STOPPING AND STORING 1. Move the key to the “OFF” position. 2. Turn off the fuel supply valve. 3. Before extended storage (over 30 days) certain precautions must be taken to ensure the fuel doesn’t deteriorate and clog the fuel system. NOTE: The use of a fuel additive, such as Sta-Bil or equivalent will minimize the formation of gum deposits during storage.
-
Page 12: Connecting The Loads
The NFPA 70 250:34-35 are good technical references. STANDARD PORTABLE GENERATOR Your WINCO portable generator ships with a bonded neutral. You can safely use this generator without external grounding as long as all loads are powered through the receptacle panel. - Page 13 these units are designed to power only 240 Volt tools. There are two hot leads and a ground wire, but no neutral connection, in the 3-wire 240Volt receptacle. A 4-wire receptacle (two hot, one ground, and one neutral) has been provided on the control panel for use in temporary power applications requiring 120/240 Volt power.
-
Page 14: Yourgen
YOURGEN overriding the governor and operating the generator at The WINCO YourGen meter allows you to see useful low voltage may damage both the generator and any load information about your generator from the front panel connected to it. Running the engine at excessively high... - Page 15 output) generator. A & B represent the 120 volt output legs of this generator. Up to 5,880 watts at 120 volts (58 Amps) can be drawn from the receptacles attached to either A or B output legs. This generator is capable of producing 58 Amps of 240 volt current at C.
-
Page 16: Engine Care
Outdoor temperatures determine the proper oil viscosity for air filter on a hard surface. the engines. Winco recommends our 5W-30 fully synthetic If the air filter is excessively dirty oil to give you excellent protection in cold temperatures replace with a new filter. You... -
Page 17: Spark Plug
Then allow it to thoroughly air dry. DO NOT oil the pre- cleaner. 7. Install the pre-cleaner to the air filter 8. Assemble the dry pre-cleaner to the air filter 9. Install the air filter 10. Install the cover and secure with the fasteners SPARK PLUG CAUTION: EQUIPMENT DAMAGE Incorrect spark plugs can damage the engine. -
Page 18: Generator Care
GENERATOR CARE TROUBLESHOOTING Proper care and maintenance of the generator is necessary Problem Possible Causes to ensure a long trouble free life. Won’t start Low oil level Fouled spark plug EXERCISING THE GENERATOR Out of fuel Start switch in OFF position The generator should be operated every three to four Fuel Valve turned off weeks. -
Page 19: Receptacle Wiring Diagram
RECEPTACLE WIRING DIAGRAM DP14000VE-03/A OPM-167/C... - Page 20 RECEPTACLE WIRING DIAGRAM DP14000VE-03/B OPM-167/C...
-
Page 21: Limited Warranty
Air cooled units purchased for stock have 1 year to be sold. The warranty to the original retail customer commences on the date of sale of the product to them. All liquid cooled units have 180 days from the Winco invoice to submit a start up date. If no startup form is submitted, then warranty period starts on the Winco invoice date unit was sold. - Page 22 Note 2: 3rd Year warranty coverage is parts only/no labor. Note 3: Round trip mileage is limited to 200 miles per trip and a total of 2 trips per repair unless authorized in writing by the WINCO Service Dept.
-
Page 23: California Evaporative Emission Control
2020 generator. In California, new equipment that uses small off-road engines must be designed, built, and equipped to meet the State’s stringent anti-smog standards. WINCO must warrant the evaporative emission control system on your generator for the period listed below provided there has been no abuse, neglect or improper maintenance of your equipment leading to the failure of the evaporative emission control system. - Page 24 225 S. CORDOVA AVE • LE CENTER, MN 56057 Sales: 507-357-6821• sales@wincogen.com Service: 507-357-6831 • service@wincogen.com www.wincogen.com OPM-167/C...
