Toyota PZQ5175190 Installation Instructions Manual

INSTALLATION INSTRUCTIONS
Please read these instructions carefully before completion, paying special attention to all
Notice, Caution & Warning notes. Failure to do so may result in damaged parts or injury.
Important
REQUIRED TOOLS
(all kits)
1 2
Marker Pen
8
7 Hammer
STEP
PZQ5175190 - KIT CONTENTS
1a
Check the contents of kits in tables below;
PZQ5175190 L1H1 Internal Panel Protection Set - Bagged Items
Item Description
1 M5 x 16 PH2 Pan Head
2 M5 Washer
3 M5 x 50 PH2 Pan Head
4 M5 Nutsert (Rivet Nut)
5 Panel Rivet Clips
6 M6x25 PH2 Pan Head
7 8mm Canoe Clip
8 Support Bracket
9 25mm Spacer Tube
10 32mm Spacer Tube
11 Foam Tape
PZQ5175190 L1H1 Internal Panel Protection Set - Panels
Item Description
12 Left Hand Front Upper Window Guard
13 Right Hand Front Upper Door Panel
14L / 14R Front Lower Sliding Door Panel
15L / 15R Rear Upper Panel
16L / 16R Rear Wheel Arch Panel
17 Rear Door Aluminium Panel
18 Rear Window Guard
19 Rear Door Replacement Struts
Issue 1 08/11/2019
Document Number: 3FTA034
Fitting Times:
Cordless Drill 3
Drill Bit
9
Centre Punch Masking Tape
H/T Class Qty Torque
4.6 35 2Nm
- 39 -
4.6 4 2Nm
- 39 -
- 91 -
4.6 1 6Nm
- 2 -
2 1
- 3
- 1
- 3.5m -
QTY LH QTY RH
1 -
- 1
1 1
1 1
1 1
1
1
2
Accessory Part No.: PZQ5175-190 / 210 / 230
Accessory Part Nos.:
PZQ5175190 - Int. Panel Protection Set
PZQ5175210 - Rear Window Guard
PZQ5175230 - Glass Protection Kit
NOTE: All part numbers applicable to L1H1 Only.
PZQ5175190
2H : 30Min
4
Torque
Screwdriver
Ø 7
mm
10
Drill Stop
Collar
To suit Ø7 Bit
mm
4
5
1
11
15L
19
18
16L
17
© Toyota Motor Corporation Australia Ltd. 2011. All rights reserved.
PZQ5175210 PZQ5175230
45 Min 1H : 10Min
5 6 Nutsert Tool
PH2 Phillips
Screwdriver
11 12
Hole Saw Panel Clip
Removal Tools
Ø16
mm
2
6
8
3
9
12
15R
14L
14R
16R
Page 1 of 17
.
10
7
13
