Place these instructions in vehicle's glove box after installation is complete
Care Instructions:
Do not slam bonnet.
ISSUE 2: 10/05/10
PARTS, SERVICE & ACCESSORIES
FJ CRUISER
May 2010 Production Onwards
ACRYLIC HEADLAMP COVERS
Installation Instructions
PZQ14-60120
Clean Headlamp Covers
with a mild detergent and
water solution.
Item
Component Name
1
Headlamp Covers Set
Metal Clips
Abrasive Resistant Tapes
Washers
2
Screws
Alcohol Wipe
Fitting Instructions
Do not use automatic
car wash.
Qty
Part number
PZQ14-60120
1
4
4
4
PZQ14-60120-FK
4
1
1
Part No. PZQ14-60120
Installation Time: Approx. 15 mins
Do not use abrasive,
spirit or solvent
based cleaners.
H4012
Page 1 of 4
