PLEASE READ THESE INSTRUCTIONS BEFORE USING THE X-TRONIC MODEL #7040-PRO-X HOT AIR REWORK STATION TABLE OF CONTENTS Product Specifications............3 Package Contents .............4 Safety Precautions ............4 Unit Diagram ..............5 Initial Set-up ...............6 Features................8 Temperature Unit Conversion ..........8 Mute/Unmute Function ............8 Hot Air Auto Cool Down / Standby Mode ......8 Powering On/Off Individual Components ......8... -
Page 5: Product Specifications
SPECIFICATIONS Model XTR-7040-PRO-X Power Consumption 775 Watts Power Cord USA Type B - 3-pin Grounded Plug Voltage AC 110V 60Hz Current ≤ 8 Amps Dimensions 8.5 L x 9.0” W x 9.0” H Weight 7.5 lbs Working Environment 32°F ~ 104°F / 0°C ~ 40°C Storage Environment -4°F ~ 176°F / -20°C ~ 80°C... -
Page 6: Package Contents
PACKAGE CONTENTS • 775 Watt Main Power Unit • 75 Watt Soldering Iron with Ergonomic Grip • Deluxe Soldering Iron Stand Attached to Main Unit • Soldering Cord Extension Holder • Brass Sponge Tip Cleaner - Inside Soldering Iron Holder •... -
Page 7: Panel Diagram
PANEL DIAGRAM X-TRONIC 7040-PRO-XI TEMP SETTING TEMP - - - - - - - - - - - - ACTUAL TEMP TEMP TEMP HEAT GUN IRON 1. Hot Air Gun Temperature Display 2. Air Flow Speed Display 3. Hot Air Gun Temperature Increase Button 4. -
Page 8: Initial Set-Up
INITIAL SET - UP 1. Plug the Hot Air Gun into the cord receptacle on the back side of the unit and tighten the ring nut (same side as the hot air gun holder). 2. Place the hot air gun into the holder on the left side of the unit. 3. - Page 9 HOT AIR GUN 1. The top display will show “---” when the hot air gun is in its holder and in sleep/standby mode. 2. Press the Hot Air Temperature Adjustment Buttons (▲ or ▼ ) on the right side of the unit to set the hot air gun temperature. The top display on the left side will show the temperature being set.
-
Page 10: Features
FEATURES TEMPERATURE CONVERSION 1. Ensure the soldering iron and the hot air gun are in their respective holders and that the unit is off. 2. Press and hold the hot air gun temperature increase button while turning on the unit with the power switch on the top of the unit. 3. -
Page 11: Soldering Iron Sleep Function
CALIBRATION FUNCTION When is it time to Calibrate your Soldering/Hot Air Station? All X-Tronic Stations come with a high quality ceramic heating element in the soldering iron that is calibrated to within ±3.6°F/2.0°C of the temperature that is shown on the LED Display and a high quality heating element in the hot air gun that is calibrated to within ±1.8°F/1.0°C of the temperature that is shown... - Page 12 The age of the heating element, the hours of use, and the temperature at which the soldering iron/hot air gun are regularly used will affect the life of the heating element and can cause fatigue. When a heating element begins to fatigue, the heat that is transferred to the soldering tip/blowing air from the heating element will begin to drop.
- Page 13 IMPORTANT - PLEASE READ Infrared (IR) Thermometers should NOT be used to measure the temperature of the soldering iron tip as they often provide inaccurate readings. All IR Thermometers are different and the capability depends on the Distance to Spot (D:S) ratio of the model being used.
-
Page 14: Maintenance
MAINTENANCE SOLDERING TIP PREPARATION & CARE 1. Keep the soldering tip properly tinned. Always use solder with sufficient rosin flux or the tip will degrade. A well tinned tip will be bright all over when hot, with no dull or discolored spots. 2. -
Page 15: Replacing The Soldering Iron Heating Element
REPLACING THE SOLDERING IRON HEATING ELEMENT Bakelite Screw Cap Spring Soldering Tip Cord Collar Metal Tip Retaining Ergonomic Grip Handle Heating Element 1. Turn off the unit and unplug it from the outlet. Allow the soldering iron to cool down to room temperature. Never attempt to handle the tip while the iron is hot. -
Page 16: Replacing The Hot Air Gun Heating Element
REPLACING THE HOT AIR GUN HEATING ELEMENT Handle Cover - Side 1 Retaining Cap Handle Cover - Side 2 Circuit Heating Reducer Board Element Mica Paper Discharge Tube Nozzle 1. Turn off the unit and unplug it from the outlet. Allow the hot air gun to cool down to room temperature. -
Page 17: Troubleshooting
• Ensure the unit is powered on with the power switch on top of the unit. • Ensure that the outlet is functional. • Contact X-Tronic International for assistance - Contact information on back of manual Soldering Iron • This is expected behavior. The “rattle” is a small ball “Rattles”... -
Page 18: Warranty
(b) any product shipped outside of the United States, the District of Columbia or Canada, or (c) anyone who may have purchased it from someone other than X-Tronic International Inc.. Proof of purchase is required for in- warranty service. We recommend you promptly register this product on our website (www.XTronicUSA.com) to facilitate verification of the date of the original... - Page 19 WHAT DOES THIS WARRANTY NOT COVER? This limited warranty during the Warranty Period does not cover any damage due to: (a) improper use; (b) failure to follow the product instructions or to perform any preventive maintenance; (c) modifications; (d) unauthorized repair; (e) normal wear and tear that comes with household use;...
-
Page 20: Contact Information
Compliments please call or email us. Toll Free: 844-861-4762 Info@XTronicUSA.com Our Business Hours are: Monday - Thursday: 8am - 4pm CST Friday: 8am - Noon CST If you would like to shop for other X-Tronic International Products Please visit our website www.XTronicUSA.com...
