PLEASE READ THESE INSTRUCTIONS BEFORE USING YOUR NEW X-TRONIC MODEL #3090-PRO-X SOLDERING STATION TABLE OF CONTENTS Product Specifications............2 Package Contents .............2 Safety Precautions ............3 Unit Diagram ..............4 Set-up & Operation ............5 Function Settings ..............6 Temperature Unit Conversion ..........6 Sleep Function ..............6 Mute / Unmute ..............6... -
Page 4: Product Specifications
SPECIFICATIONS Model XTR-3090-PRO-X Input voltage 110/120V 60Hz Dimensions 6.0 x 5.5 x 6.0 in Weight 1.5 lbs / .65 kg Working Environment 32°F ~ 104°F / 0°C ~ 40°C Storing Environment -4°F ~ 176°F / -20°C ~ 80°C Storage Humidity... -
Page 5: Safety Precautions
SAFETY PRECAUTIONS 1. When not in use always turn the power off and unplug the unit from the electrical outlet. 2. Never use the soldering iron near any flammable substance, material, or gas. 3. Never touch the metallic components of the soldering iron while they are in use. -
Page 6: Unit Diagram
UNIT PARTS 1. Helping Hands 2. Mini Mag Lamp 3. Solder Roll Holder 4. Digital LED Temperature Readouts 5. Memory Preset Indicators 6. Anti-static Ground Wire Alligator Clip 7. Temperature Adjustment Buttons 8. Wet Sponge Tip Cleaner 9. Brass Sponge Tip Cleaner 10. -
Page 7: Set-Up & Operation
1. Open the package and check that all parts are present and are not damaged. If anything is missing or damaged, please contact X-Tronic immediately for assistance (see back cover for contact information). 2. Place the soldering iron in the soldering iron holder on the unit. -
Page 8: Function Settings
FUNCTION SETTINGS TEMPERATURE CONVERSION This unit can readout temperatures in either Fahrenheit or Celsius. To change from one to the other, when the unit is powered off, simply press the ▲ button and turn the unit on. The screen will show either C - C or F - F to indicate the unit of measurement being used. -
Page 9: Mute / Unmute
MUTE / UNMUTE FUNCTION The unit beeps when buttons are pushed or when it goes into sleep mode. To toggle between Mute and Unmute Mode turn the unit off. Press and hold the ▼ button while turning the unit back on, the screen will display “on”... -
Page 10: Maintenance
MAINTENANCE SOLDERING TIP PREPARATION • Keep the soldering tip properly tinned. Always use solder with sufficient rosin flux or the tip will de-wet. A well tinned tip will be bright all over when hot, with no dull or discolored spots. •... -
Page 11: Soldering Tip Replacement
WARNING DISCONNECT POWER CORD BEFORE REPLACING A SOLDERING TIP AND/OR A HEATING ELEMENT REPLACING THE SOLDERING TIP 1. Turn off the soldering station, unplug the power cord from the power source and allow the soldering iron to cool down to room temperature. -
Page 12: Heating Element Replacement
REPLACING THE SOLDERING IRON HEATING ELEMENT Bakelite Screw Cap Spring Soldering Tip Cord Collar Metal Tip Ergonomic Retaining Grip Handle Screw Cap Heating Element 1. Turn off the unit and unplug it from the outlet. Allow the soldering iron to cool down to room temperature. Never attempt to handle the tip while the iron is hot. -
Page 13: Troubleshooting
TROUBLESHOOTING ISSUE POSSIBLE SOLUTIONS Unit does not • Ensure the power cord is not damaged and in good have power working condition. • Ensure that the outlet is functional. Soldering Iron • This is expected behavior. The “rattle” is a small ball “Rattles”... -
Page 14: Warranty
(b) any product shipped outside of the United States, the District of Columbia or Canada, or (c) anyone who may have purchased it from someone other than X-Tronic International Inc.. Proof of purchase is required for in- warranty service. We recommend you promptly register this product on our website (www.XTronicUSA.com) to facilitate verification of the date of the original... - Page 15 WHAT DOES THIS WARRANTY NOT COVER? This limited warranty during the Warranty Period does not cover any damage due to: (a) improper use; (b) failure to follow the product instructions or to perform any preventive maintenance; (c) modifications; (d) unauthorized repair; (e) normal wear and tear that comes with household use;...
-
Page 16: Contact Information
Compliments please call or email us. Toll Free: 844-861-4762 Info@XTronicUSA.com Our Business Hours are: Monday - Thursday: 8am - 4pm CST Friday: 8am - Noon CST If you would like to shop for other X-Tronic International Products Please visit our website www.XTronicUSA.com...
