Summary of Contents for X-Tronic PX-70
-
Page 3: Table Of Contents
TABLE OF CONTENTS Product Specifications............2 Package Contents .............3 Safety Precautions ............4 Unit Diagram ..............5 Features / Modes ...............6 Voltage Regulation ..............6 Current / Amperage Regulation ..........6 Adjustable USB Interface ............6 Constant Voltage (CV) Mode ..........6 Constant Current (CC) Mode ..........6 Continuous Overcurrent Protection (CONT.OCP) .... -
Page 4: Product Specifications
SPECIFICATIONS Model XTR-PX-70 Power Consumption 160 Watts Power Cord USA Type B - 3-pin Grounded Plug Input Voltage AC 110V 60Hz Dimensions 7.25 L x 4.5” W x 9.0” H Weight 9.5 lbs Working Environment 32°F ~ 104°F / 0°C ~ 40°C Storage Environment -4°F ~ 158°F / -20°C ~ 70°C... -
Page 5: Package Contents
PACKAGE CONTENTS • 160 Watt Main DC Power Supply Meter • 3 High Quality Stackable Banana Plug to Alligator Clip Leads (positive, negative, & ground) • 2 High Quality Banana Plug to Precision Probes (positive & negative) • 2 High Quality Stackable Banana Plug to Hook/Plunger Leads (positive &... -
Page 6: Safety Precautions
SAFETY PRECAUTIONS 1. Always use a grounded outlet for the unit to avoid shock. 2. Always turn the power off and unplug the unit when not in use. 3. Always ensure the fan and intakes are clear of obstruction and is not blocked/obstructed in any way. - Page 7 PANEL DIAGRAM - FRONT 5V/LIMIT CONT.OCP ONCE.OCP LOCK CONT.OCP ONCE.OCP 1. Voltage Display Meter 10. Single Overcurrent Protection Button 2. Current / Amperage Display Meter 11. Lock Indicator 3. Memory Recall Buttons 12. Constant Voltage Output Indicator 4. Voltage Regulation Knob 13.
-
Page 8: Unit Diagram
UNIT DIAGRAM - BACK 1. Fan 2. 5V/30V Switch 3. AC Input Receptical 4. Fuse FEATURES / MODES Voltage Regulation Briefly press the Voltage (V) knob to select the digit that you want to adjust, the digit will blink when it is selected. Then turn the Voltage knob to adjust the voltage to the required setting. -
Page 9: Continuous Overcurrent Protection (Cont.ocp)
Constant Current (CC) Mode In order for the unit to switch to CC Mode, the Amperage limit needs to be set lower than what is needed based on the Voltage limit set. Once the device being powered pulls enough current / amps to hit the set limit, the unit will automatically switch to CC Mode, the C.C indicator will be lit and the Volt will start to vary while keeping the Amps constant. -
Page 10: Lock / Unlock
to remove the load and press the ONCE.OCP button. The voltage and current regulations will be restored and output will resume. LOCK / UNLOCK Press and hold the Voltage knob for two seconds to lock all of the settings currently programed in the unit. Only the Power button will still function when the unit is locked. -
Page 11: Initial Set-Up
1. Open the package and check that all parts are present and are not damaged. If anything is missing or damaged, please contact X-Tronic immediately for assistance (see back cover for contact information). 2. Plug the power cord into the back of the unit. -
Page 12: Maintenance
MAINTENANCE 1. Keep the unit plugged into a GROUNDED outlet at all times during operation. 2. When the unit is not in use, ensure the unit is powered OFF and unplugged. 3. Keep the unit and all components free from dirt, debris, and liquid at all times. -
Page 13: Troubleshooting
• Check to see if fuse needs to be replaced. (See page 10) • Contact X-Tronic International for technical assistance - Contact information on back of manual Hear a • A relay switch has been activated - the clicking “clicking”... -
Page 14: Warranty
(b) any product shipped outside of the United States, the District of Columbia or Canada, or (c) anyone who may have purchased it from someone other than X-Tronic International Inc.. Proof of purchase is required for in- warranty service. We recommend you promptly register this product on our website (www.XTronicUSA.com) to facilitate verification of the date of the original... - Page 15 WHAT DOES THIS WARRANTY NOT COVER? This limited warranty during the Warranty Period does not cover any damage due to: (a) improper use; (b) failure to follow the product instructions or to perform any preventive maintenance; (c) modifications; (d) unauthorized repair; (e) normal wear and tear that comes with household use;...
-
Page 16: Contact Information
Compliments please call or email us. Toll Free: 844-861-4762 Info@XTronicUSA.com Our Business Hours are: Monday - Thursday: 8am - 4pm CST Friday: 8am - Noon CST If you would like to shop for other X-Tronic International Products Please visit our website www.XTronicUSA.com...
