SMC Networks PFCQ531 Series Installation Manual

Flow controller for air preset input / serial communication specification
Hide thumbs Also See for PFCQ531 Series:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
Doc. No. DOC1127113
Installation Manual
PRODUCT NAME
Flow controller for air
Preset input / Serial communication specification
（Setting software and USB driver）
MODEL / Series / Product Number
PFCQ531 Series
[Before using this product]
Read the "End-User License Agreement" shown on the next page carefully
and accept the terms before using this software.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PFCQ531 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks PFCQ531 Series

Summary of Contents for SMC Networks PFCQ531 Series

  • Page 1 Preset input / Serial communication specification （Setting software and USB driver） MODEL / Series / Product Number PFCQ531 Series [Before using this product] Read the "End-User License Agreement" shown on the next page carefully and accept the terms before using this software.

  • Page 2: End User License Agreement

    End-User License Agreement SMC Corporation (hereinafter referred to as "SMC") grants the user (regardless the user is a corporation or an individual) a license to use this software "Controller Setting Software LATC-Configurator" (hereinafter referred to as "Software") provided according to this End-User License agreement (hereinafter referred to as "Agreement") under the articles listed below.

  • Page 3: Installation Procedures

    1. Foreword This document describes how to install the USB driver necessary for connecting a PC and this product with a USB cable when using the setting software for this product (PFCQ Setting software.exe). Before using the PFCQ Setting software (PFCQ Setting software.exe), please make the following preparations.
  • Page 4 When “Ports (COM & LPT)” is not displayed, “SMC Serial Converter” is displayed under “Other devices”. FT232R USB UART Right click the [FT232R USB UART] with ! mark in [Other devices] to select [Update Driver Software]. vi. When the following screen is displayed, select the “Browse my computer for driver software”.
  • Page 5 vii. Click the [Browse] button to select the folder in the folder unzipped after downloading. Then, click [Next]. viii. When the driver is installed, “USB Serial Converter” is displayed under the Device Manager “Universal Serial Bus controllers”. - 4 -...
  • Page 6 ix. Next the "virtual COM port driver" for the communication cable needs to be installed for the software to function properly. Continue the installation of the "virtual COM port driver" following the same procedure beginning from step VI. Then, the driver is installed and “USB Serial Port (COM)” is displayed under “Ports (COM &...
  • Page 7 3. Check of the Communication Port The USB cable assigned communication port number (COM number) can be checked in the Windows device manager. Connect the communication cable LEC-W2A-C to the USB port of the PC using the USB cable (LEC-W2-U). Right click the Windows logo at the lower left of the desk top, and select “Device manager”.
  • Page 8 4. Start up the setting software Connect the product to a USB port on the PC via a USB cable (Type-C), turn on the power to the product, and double-click the icon below. For details on how to operate the subsequent setup software, please refer to the instruction manual (DOC1117087) available on our website.
  • Page 9 Revision history Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 URL: https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. Windows is the registered Trademark or the Trademark of Microsoft Corporation in the United States or other countries. ©...
