- Page 1 MULTIPLAY22 7/04/25 BASKETBALL/NETBALL TOWER Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
Maintenance ............................12 Safety Guidelines (Usage) ........................12 Certificate of Compliance: ........................13 Warranty Certificate: .......................... 14 Image 1: Multiplay22 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 3: Introduction
P a g e 1. Introduction Thank you for choosing the Multiplay 22 – S125r Rotating Basketball/Netball System from Play Hard Sports Equipment Australia. Our Basketball Towers are designed for durability and performance and are suitable for commercial use. This manual provides detailed information on the installation, maintenance, usage, and warranty details of the Multiplay 22 Rotating Basketball/Netball Tower supplied by Play Hard Sports Equipment Australia. - Page 4 P a g e • Material: 127 OD Pole and 150 x 100 RHS Extension Arm are made from Steel and then hot-dip galvanised after fabrication. • Basketball Ring: ➢ R11b/ProRim ➢ OzRing • Netball Ring: ➢ NR31 Ring • Net Tie System: Patented Waverail system •...
-
Page 5: Safety Information For The Installer
P a g e 2. Safety Information for the Installer 2.1. Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the tower location during and after installation. •... -
Page 6: Component List
P a g e 3. Component List Figure 1: MULTIPLAY22 Parts List Quantity per Tower Multiplay Multiplay 22 Multiplay 22 Components (Sleeve) Main Post (127 OD) Extension Arm Backboard Frame Locking Collar Basketball Ring NR31 Netball Ring SN90r/S125r Hand Tool... -
Page 7: S132 Footing Details
P a g e 4. Footing Details Figure 2: S132 Footing Details Figure 2: Multiplay22 Footing Detail 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 8: Installation Instructions
P a g e 5. Installation Instructions 5.1. Site Preparation: • Before commencing any groundwork, please survey the ground/field for any underground electrical line, water line and sewage line. Also, check for any overhead electrical lines. • It is advised that the soil is tested to know its strength. All our towers have been structurally designed to suit ‘A’, ‘S’... -
Page 9: Attaching The Backboard
P a g e 5.4. Attaching the Height Adjusting Frame • Identify the side that attaches to the extension arm on the height adjusting frame • Hang the frame via an angled bracket at the back end of the frame on top of the frame at the extension arm 5.5. - Page 10 P a g e 5.7. Attaching the Netball Ring • Attach the Netball Ring to the bracket at the end of the extension arm using M10 x 30mm Gal Bolt, Flat Washer and Nyloc Nut Note: Use anti-seize lubricants on all bolts during the installation process 6.
- Page 11 P a g e | 10 Step 3: Once rotated 180 degrees, the spring-loaded head bolt will automatically engage. For safety, always check the head is accurately locked into place with the hand tool. Note: Please store the hand tool in a safe place and must be operated by a responsible person only Figure 5: Step 3 Step 4: Use the SHF hand tool to adjust the Basketball Ring...
- Page 12 P a g e | 11 Figure 7: Height Adjusting Frame Instructions Step 5: Use the NR31 Ring tool to lower the Netball Ring height from senior height to junior height and vice-versa. Note: Please store the hand tool in a safe place and must be operated by a responsible person only 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494...
-
Page 13: Maintenance
P a g e | 12 7. Maintenance All our towers are designed to require a minimal level of maintenance. However, it is advisable to do: • Regular Inspections: Check for any signs of wear or damage. Tighten bolts and replace nets or padding as needed. -
Page 14: Certificate Of Compliance
P a g e | 13 9. Certificate of Compliance: All our products have been structurally designed and are made using structural-grade steel. All the workmanship is completed following the relevant Australian Standards. Our Products comply with the following Australian Standards. 1. -
Page 15: Warranty Certificate
P a g e | 14 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The Basketball Tower Structure has 25 years of warranty.
