- Page 1 S100 2/2/2025 Basketball Unit Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
Site Specific Precautions: ..........................4 Component List ............................... 5 Footing Details ..............................6 S100 Footing Details .......................... 6 S100-BP Footing Details ........................7 S100 (Sleeve) Footing Details ......................8 Installation Instructions: ..........................9 Maintenance: ..............................11 Safety Guidelines (Usage) ..........................11 Certificate of Compliance: ..........................12 Warranty Certificate: ............................13... -
Page 3: Introduction
P a g e Introduction Thank you for choosing the S100 Basketball System from Play Hard Sports Equipment Australia. Our Basketball Towers are designed for durability and performance and are suitable for commercial use. This manual provides detailed information on the installation, maintenance, usage, and warranty details of the S100 Basketball Tower supplied by Play Hard Sports Equipment Australia. - Page 4 ‘M’ per AS2870. Site-specific footing and slab engineering must be done for other Soil Classes. We also offer site-specific engineering drawings if required with additional charges. Figure 1: S100 Basketball Tower 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia)
-
Page 5: Safety Information For The Installer
P a g e Safety Information for the Installer: Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the tower location during and after installation. -
Page 6: Component List
P a g e Component List Figure 2: S100 Basketball Tower Parts List Quantity per Tower S100 S100 - BP S100 Components (Sleeve) Main Post Extension Arm Backboard Frame Ring Ground Sleeve Sleeve Cap Bolt Kit M16 x 50 mm H.T. Gal Hex Bolt, Spring... -
Page 7: Footing Details
Note: Pole Plate and bolt kits are packed inside the ring box. Please check your order. If any parts are missing, please call us immediately Footing Details 1. S100 Footing Details Figure 3: S100 Footing Detail 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 8: S100-Bp Footing Details
P a g e 2. S100-BP Footing Details Figure 4: S100-BP Footing Detail 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 9: S100 (Sleeve) Footing Details
P a g e 3. S100 (Sleeve) Footing Details Figure 5: S100 (Sleeve) Option 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 10: Installation Instructions
1B. Post Installation: A. S100 Concreted to the ground: ➢ Bore Drill a 600 mm Diameter and 1000 mm Deep Hole. ➢ If the Ground Level at the hole position is lower than the playing surface, then box up around the hole site to achieve the concrete depth of 1000mm. - Page 11 P a g e | 10 ➢ Pour the concrete into the hole. (Prevent any concrete from getting inside the ground sleeve). ➢ If the Ground Level at the hole position is lower than the playing surface, then box up around the hole site to achieve the concrete depth of 800mm. (Please be mindful that only 100mm of box-up is acceptable) ➢...
-
Page 12: Maintenance
P a g e | 11 4. Attaching the Ring • Align the bolt holes in the backboard, the extension arm and the ring and insert the M10 x 90mm Gal Hex Bolt, Double Flat Washer, Spring Washer and Nut without damaging the thread. -
Page 13: Certificate Of Compliance
P a g e | 12 Certificate of Compliance: All our products have been structurally designed and are made using structural-grade steel. All the workmanship is completed following the relevant Australian Standards. Our Products comply with the following Australian Standards. 1. -
Page 14: Warranty Certificate
P a g e | 13 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The Basketball Tower Structure has 25 years of warranty.
