- Page 1 S125r 2/2/2025 Basketball Unit Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
Important Safety Information ........................5 Assembly Precautions ..........................5 Site Specific Precautions: ..........................5 Component List ............................... 6 Footing Details ..............................8 S125r Footing Details ........................8 Installation Instructions: ..........................9 Operating Instructions ..........................12 Maintenance: ..............................13 Safety Guidelines (Usage) ..........................13 Certificate of Compliance: ..........................14... -
Page 3: Introduction
Structural Engineers. S125r is designed to be used in Multi Sports Courts, where the Basketball size is 28m and the Netball court size is 30.5m. The main post sits on the netball court baseline and when rotated for basketball use, the extension arm will place the backboard 1.2M inside the basketball baseline. - Page 4 P a g e • Net Tie System: Patented Waverail system • Backboard: Regulation Size 1800mm x 1050mm ➢ B1810p: Polyboard Backboard ➢ B1810a: Acrylic Backboard ➢ B1810g: Glass Backboard • Color Options: Standard Hot-Dip Galvanized. Various paint color options are available on request. •...
- Page 5 P a g e Figure 1: S125r Rotating Basketball/Netball Tower 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au...
-
Page 6: Safety Information For The Installer
P a g e Safety Information for the Installer: Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the tower location during and after installation. •... -
Page 7: Component List
P a g e Component List Figure 2: S125r Rotating Basketball/Netball Tower Parts List Quantity per Tower S125r S125r - BP S125r Components (Sleeve) Main Post (127 OD) Extension Arm Backboard Frame Locking Collar Basketball Ring Netball Ring SN90r/S125r Hand Tool... - Page 8 P a g e M10 x 90mm Gal Hex Bolt, Spring Washer, Double Flat Washer & Nut M10 x 30mm Gal Hex Bolt, Spring Washer, Flat Washer & Nut M16 Threaded Rods or Chemset Reo 502 with levelling Nut and Washer (Not Included in the Package) Note: Locking Collar and bolt kits are packed inside the ring box.
-
Page 9: Footing Details
P a g e Footing Details 1. S125r Footing Details Figure 3: S125r Footing Detail 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 10: Installation Instructions
P a g e Figure 4: S125r Full Rotation Space Requirement Installation Instructions: 1A. Site Preparation: • Before commencing any groundwork, please survey the ground/field for any underground electrical line, water line and sewage line. Also, check for any overhead electrical lines. - Page 11 P a g e | 10 ➢ The concrete must be of a minimum 20 MPA, with a slump of 80 – 100 mm, and a maximum aggregate of size 20mm. ➢ Trowel the concrete sloping away from the pole to prevent water from pooling around the post base.
- Page 12 P a g e | 11 4. Attaching the Basketball Ring: • Align the bolt holes in the backboard, the extension arm and the ring and insert the M10 x 90mm Gal Hex Bolt, Double Flat Washer, Spring Washer and Nut without damaging the thread.
-
Page 13: Operating Instructions
P a g e | 12 Operating Instructions The rotating basketball/netball system is easy to operate. We can use the supplied hand to position the tower for either basketball or netball. Step 1: Release (by pulling the bolt down and turning 90 degrees) the spring- loaded head releasing the bolt with the supplied hand tool as shown in Figure 5. -
Page 14: Maintenance
P a g e | 13 Step 3: Once rotated 180 degrees, the spring-loaded head bolt will automatically engage. For safety, always check the head is accurately locked into place with the hand tool. Note: Please store the hand tool in a safe place and must be operated by a responsible person only Figure 7: Step 3 Maintenance:... -
Page 15: Certificate Of Compliance
P a g e | 14 Certificate of Compliance: All our products have been structurally designed and are made using structural-grade steel. All the workmanship is completed following the relevant Australian Standards. Our Products comply with the following Australian Standards. 1. -
Page 16: Warranty Certificate
P a g e | 15 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The Basketball Tower Structure has 25 years of warranty.
