- Page 1 GAME CHANGER / 2/2/2025 POWER PRO BASKETBALL UNIT Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Warnings And Safety Information
P a g e Warnings & Safety Information Failure to follow these warnings and instructions may result in injury or property damage. Do not attempt to assemble this equipment without following the assembly instructions. Proper and complete assembly is required to reduce the risk of personal injury or equipment damage. The owner of this equipment is responsible to ensure all players are aware of these conditions for the safe use and operation of the equipment. - Page 3 P a g e Shifting Spanner (2) Ladder (2) Masking Tape Straight Edge Spirit Level Capable Adult (2 Min.) Component Sheet & Bolt Kit Contents Please check your order. If any parts are missing please call immediately. Note: Part , part N and the brackets on part D are for Game Changer only. Contents of part L (bolt kit): 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494...
-
Page 4: Installation Steps
P a g e Kit No. Parts M12 x 25mm Bolt M10 x 170mm Bolt and Nyloc Nut M10 Nylon Washer (Already attached to F & G) M10 Washer M12 x 170mm Bolt and Nyloc Nut M12 Washer M10 x 83mm Bolt and Nyloc Nut M10 Washer M10 x 50mm Bolt and Nyloc Nut M10 Nylon Washer (Already attached to F &... - Page 5 P a g e 10. Fill the hole with concrete making sure you don’t move the ground sleeve. 11. Trowel the concrete sloping away from pole to prevent water pooling around pole base. 12. While concrete mix is still fresh ensure that ground sleeve is still level in all necessary directions and axes.
- Page 6 P a g e Note: Do not over tighten Nyloc Nuts. They should be tightened to reduce play but still allow the pivoting parts to move without tension. Place part B into Part A with the rotation latch facing the side and tighten the bolt from kit No.
- Page 7 P a g e 16. Fix part E through the top holes of part D using No. 2 bolt kit. Then attach part F to part D using the remaining contents of bolt kit No. 2. 17. Attach part G to part E using bolt kit No.
- Page 8 P a g e Side view of step 20. 21. Use the No. 6 bolt kit bolts with a washer on each and push them through the holes in part J. Then push the bolts through part H and fix the top bolts first followed by the bottom bolts.
- Page 9 P a g e 23. Put net onto ring as per instructions below: Note: Ensure that the net is the correct way up. 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au...
-
Page 10: Operation Information
P a g e Operation Information To rotate the system, pull down the spring loaded locking mechanism on part B and twist it to the side to lock it in the lowered position. Rotate the top half of the system using the handle on the pole section. Once in position, release the spring loaded latch to lock the system in position. -
Page 11: Warranty Certificate
P a g e | 10 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The GAME CHANGER &...
