- Page 1 2/3/2025 PICKLEBALL POSTS Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
P a g e Contents Introduction ..............................2 Product Details: ............................2 Safety Information for the Installer: ....................... 3 Important Safety Information ........................3 Assembly Precautions ..........................3 Site Specific Precautions: ..........................3 Component List ............................... 4 Installation Instructions: ..........................5 Unit Assembly Details ............................. -
Page 3: Introduction
Product Specifications: • Models: ➢ PBR ➢ PBR – BP ➢ PBR – F (Free Standing Pickleball) • Footing Option: Depending on the model, the posts can be installed into a ground sleeve, base-plated with chemset anchor studs and free-standing. -
Page 4: Safety Information For The Installer
P a g e Safety Information for the Installer: Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the tower location during and after installation. -
Page 5: Component List
P a g e Component List PBR-BP PBR-F Components Non-Winder Post Winder Post Ratchet Winder Post Caps Tennis Post Collar Ground Sleeve Sleeve Cap Support Bar 75 mm dia. Castor with Brake 75 mm dia. Castor without Brake M10 x 100 mm S/S Hex Bolt, Double Flat Washer, S/Washer &... -
Page 6: Installation Instructions
P a g e Note: The Ratchet Winder Mechanism comes pre-installed on the Winder Post. Installation Instructions: 1A. Site Preparation: • Before commencing any groundwork, please survey the ground/field for any underground electrical line, water line and sewage line. • It is advised that the soil is tested to know its strength. - Page 7 P a g e Figure 2: EP75 & EL75 Footing Details B. EHC75p and EHC75s: Figure 3: EHC75p Footing Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au...
- Page 8 P a g e Figure 4: EHC75s Footing Details C. Free Standing Post Installation: ➢ The castor wheels are already fitted to the end posts. ➢ Use the supplied bolts to connect the winder and non-winder posts to the support bar.
-
Page 9: Unit Assembly Details
Figure 5: Net Installation Details Unit Assembly Details 1. PBR Footing and Assembly Details Figure 6: PBR Footing & Assembly Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 10: Trw75-Bp Footing And Assembly Details
P a g e 2. PBR-BP Footing and Assembly Details Figure 7: PBR-BP Footing and Assembly Details 3. PBR-F Assembly Details Figure 8: PBR-F Assembly Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 11: Maintenance
P a g e | 10 Maintenance: All our towers are designed to require a minimal level of maintenance. However, it is advisable to do: • Regular Inspections: Check for any signs of wear or damage. Tighten bolts on the winder mechanism and replace nets or padding as needed. -
Page 12: Certificate Of Compliance
P a g e | 11 Certificate of Compliance: All our products have been structurally designed and are made using structural-grade steel. All the workmanship is completed following the relevant Australian Standards. Our Products comply with the following Australian Standards. 1. -
Page 13: Warranty Certificate
P a g e | 12 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The Pickleball Posts has 10 years of warranty.
