- Page 1 TRW75 2/3/2025 TENNIS POSTS Installation, Operation & Maintenance Manual PLAY HARD SPORTS EQUIPMENT 13 Alex Fisher Drive Burleigh Heads, QLD 4220...
-
Page 2: Table Of Contents
Installation Instructions: ..........................5 Unit Assembly Details ............................. 8 TRW75 Footing and Assembly Details ....................8 TRW75-BP Footing and Assembly Details ..................9 TRW75-2 Half Court Tennis Posts Footing and Assembly Details ...........10 Maintenance: ..............................11 Safety Guidelines (Usage) ..........................11 Certificate of Compliance: ..........................12 Warranty Certificate: ............................13... -
Page 3: Introduction
P a g e Introduction Thank you for choosing the TRW75 Ratchet Winder Tennis Posts from Play Hard Sports Equipment Australia. Our Excalibur Tennis Posts are designed for durability and performance. This manual provides detailed information on the installation, maintenance, usage, and warranty details of the TRW75 Tennis Posts supplied by Play Hard Sports Equipment Australia. -
Page 4: Safety Information For The Installer
P a g e Safety Information for the Installer: Important Safety Information • Read the Manual: Ensure you read this manual in full before beginning assembly or installation. • Supervision: Children should be supervised around the tower location during and after installation. -
Page 5: Component List
P a g e Component List Quantity TRW75 TRW75- TRW75- TRW75- Components Non-Winder Post Winder Post Ratchet Winder Post Caps Tennis Post Collar Ground Sleeve Sleeve Cap Bolt Kit M12 x 25 mm S/S Button Head Bolt and Nyloc Nut... -
Page 6: Installation Instructions
P a g e Note: The Ratchet Winder Mechanism comes pre-installed inside the Winder Post. Installation Instructions: 1A. Site Preparation: • Before commencing any groundwork, please survey the ground/field for any underground electrical line, water line and sewage line. • It is advised that the soil is tested to know its strength. - Page 7 P a g e Figure 2: EP75 & EL75 Footing Details B. EHC75p and EHC75s: Figure 3: EHC75p Footing Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au...
- Page 8 P a g e Figure 4: EHC75s Footing Details 2. Net Installation: 1. Once the concrete is set and the court surface has been layered, install the post into the ground sleeves with the wave rails in the posts facing each other. o The non-winder post has an external hook whereas the winder post has a ratchet winder.
-
Page 9: Unit Assembly Details
P a g e Unit Assembly Details 1. TRW75 Footing and Assembly Details Figure 6: TRW75 Footing & Assembly Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 10: Trw75-Bp Footing And Assembly Details
P a g e 2. TRW75-BP Footing and Assembly Details Figure 7: TRW75-BP Footing and Assembly Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au | W: www.playhardsports.com.au... -
Page 11: Trw75-2 Half Court Tennis Posts Footing And Assembly Details
| 10 3. TRW75-2 Half Court Tennis Posts Footing and Assembly Details Figure 8: TRW75-2 Half Court Tennis Posts Footing and Assembly Details 13 Alex Fisher Drive, Burleigh Heads, QLD 4220 (Australia) Ph: 1300 851 518 | +61 7 5593 4494 Email: email@playhardsports.com.au... -
Page 12: Maintenance
P a g e | 11 Maintenance: All our towers are designed to require a minimal level of maintenance. However, it is advisable to do: • Regular Inspections: Check for any signs of wear or damage. Tighten bolts on the winder mechanism and replace nets or padding as needed. -
Page 13: Certificate Of Compliance
P a g e | 12 Certificate of Compliance: All our products have been structurally designed and are made using structural-grade steel. All the workmanship is completed following the relevant Australian Standards. Our Products comply with the following Australian Standards. 1. -
Page 14: Warranty Certificate
P a g e | 13 Warranty Certificate: When you purchase a Play Hard Sports Equipment product you have the peace of mind in knowing that your product is covered by Play Hard Sports Equipment’s manufacturer’s warranty against faulty workmanship and materials. The Tennis Posts has 10 years of warranty.
