WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance
•
Do not touch any electrical switch; do not use any phone in
your building
•
Immediately call your gas supplier from a neighbors phone.
•
Follow the gas suppliers instructions
If you can not reach your gas supplier, call the fire
•
department
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
English and French Installation Manuals available through your
local dealer or visit our website at: www.archgard.com
Les manuels d'installation en anglais et en français son
disponibles chez votre détaillant local ou en visitant notre site
web: www.archgard.com
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
ARCHGARD FIREPLACE PRODUCTS
300 Railway Avenue
Raymond, AB T0K 2S0 Canada
INSTALLATION, OPERATION, AND
MAINTENANCE MANUAL
Chantico 27
Model: 27-DVIE22N-2
GAS FIRED DIRECT VENT
FIREPLACE INSERT
S/N 272090 AND UP
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only) or
mobile home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
WARNING: If the information in these instructions is not
followed exactly, a fire or explosion may result, causing
property damage, personal injury or loss of life.
Gas Fireplace Energy Efficiency Rating
70.73%
Based on CSA P.4.1-15
200-1127-16
April 23, 2025
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Archgard Chantico 27
Summary of Contents for Archgard Chantico 27
- Page 1 English and French Installation Manuals available through your local dealer or visit our website at: www.archgard.com Les manuels d'installation en anglais et en français son disponibles chez votre détaillant local ou en visitant notre site web: www.archgard.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1.0 Introduction 16.0 Surround Installation 2.0 Safety Information 16.1 Surround Dimensions 16.2 Trimmable Surround Dimensions 3.0 Technical Information 16.3 Dimensions of Fronts 3.1 Appliance Certification 16.4 Decorative Trim Dimensions 3.2 Installation Codes 16.5 Decorative Plinth Dimensions 3.3 Specifications 17.0 Firebox Liner Installation 3.4 High Altitude Installation 17.1 Brick Panel Installation... -
Page 3: General Information
The Chantico 27 is one of the most advanced Direct Vent Insert heaters available today. It is solidly designed using the latest technology and manufactured to the highest quality. -
Page 4: Safety Information
For more information, visit www.P65Warnings.ca.gov. Each Archgard Gas Fireplace is checked and tested at the factory prior to being packaged and shipped to our dealers and finally installed in your home. Before leaving this unit with the customer, the installer must ensure that the appliance is firing correctly and that the electrical system is in working order. -
Page 5: Technical Information
Commonwealth of Massachusetts: This appliance has been manufactured in accordance with Massachusetts code 248 CMR 5.00. Approval Code: G1-0717-621. (http://license.reg.state.ma.us/public/licque.asp). Please contact Archgard Industries Ltd., if you have any questions regarding the certification of this appliance. 3.2 Installation Codes This appliance must be installed by a qualified gas appliance installer. The installation must conform with the local codes or, in the absence of local codes, with the current National Fuel Gas Code ANSI Z223.1/ NFPA 54 in the US, or Installation Code CAN/... -
Page 6: Rating Plate
(CO) poisoning and possible death. ONLY DOORS CERTIFIED WITH THE APPLIANCE SHALL BE USED. For use only with barrier part # 27-BS. Follow installation instructions. Made in Canada by: Archgard Industries Ltd. 300 Railway Avenue, Raymond, AB October 2024 303-6027-10 MANUFACTURE DATE:... -
Page 7: Installation Checklist
Installation 5.0 Installation Checklist This standard installation checklist is to be used by the installer in conjunction with, not instead of, the instructions contained within this installation manual. Customer: Date Installed: Install Address: Location of Fireplace: Installer: Solid Fuel Zero Clearance Install: (Section 9.1) IF NO, WHY NOT? Was the bottom of the existing zero clearance removed? Venting: (Section 13.0) -
Page 8: Appliance Overview
Installation 6.0 Appliance Overview 6.1 Rating Plate Location Figure 6.1.01: 6.2 Appliance Overview The Proflame II control board is located on the right side* of the fireplace behind the surround. The valve is located on the left side* of the fireplace behind the surround. The fan is located on the inside of the rear fireplace shell and can be accessed from the rear of the fireplace or through the front of the fireplace by removing the burner. -
Page 9: Leveling The Appliance
Installation CONTROLS IN CONTROLS OUT Figure 6.2.03: Figure 6.2.04: 6.3 Leveling the Appliance The 27-DVIE22N-2 is equipped with front and rear leveling bolts. The fireplace has the ability to independently level left/right and front/back. Leveling is done from the bottom of the unit Front Bolts Rear Bolts Figure 6.3.01:... -
Page 10: Appliance Dimensions
Installation 8.0 Appliance Dimensions 8.1 Control Panel Locations The control panels can be mounted in the following different ways. They are shipped in the “Controls In” configuration. They can be moved to the “Controls Out” configuration by removing the two mounting screw on each side and swinging the panels out and re- installing the screws. - Page 11 Installation 26.548in 2.500in Shown with 14.235in Deep Surround 15.600in 10.491in 17.790in 13.370in 26.448in 22.820in 17.928in 16.906in 38.157in 16.743in Figure 8.1.02: Metric Equivalents Inches Inches Inches Inches FRONT 38.157 96.92 17.79 45.19 13.37 33.96 26.448 67.18 BOTTOM 26.548 67.43 15.6 39.62 14.235 36.16 6.35...
-
Page 12: Minimum Opening Dimensions
Installation 9.0 Minimum Opening Dimensions Dimension Dimension Reference (Controls In) (Controls Out) 17.928" (45.54 cm)* 17.928" (45.54 cm)* 11.991" (30.46 cm) 10.491" (26.65 cm) Figure 9.0.01: 15.875" (40.32 cm) 14.375" (36.51 cm) 4.5" (11.43 cm) 0" 16" (40.64 cm) 15.75" (40.0 cm) 29.625"... -
Page 13: Factory Built Fireplaces
Installation 9.1 Factory Built Fireplaces The following information applies to Factory Built (metal) Wood-Burning Fireplace installations: Trim panels must not seal ventilation openings in the fireplace. Any parts that are removed must be saved and reinstalled if the insert is ever removed. If the factory-built fireplace has no gas access hole(s) provided, an access hole of 1 1/2” (38.1 mm) or less may be drilled through the lower sides or bottom of the firebox in a proper workmanship-like manner. -
Page 14: Refacing A Masonry Fireplace
Installation 9.2 Refacing a Masonry Fireplace Using Steel Studs and Cement Board on Wood Fireplaces Brick or rock facing may be removed and replaced with noncombustible material such as steel studs and cement board. WARNING: Only facing material may be removed. All other masonry material must not be cut out, chipped away, or removed. WARNING: Louvers or any air circulation around existing solid fuel fireplace must not be blocked or covered. -
Page 15: Clearances To Combustibles
Installation 10.0 Clearances to Combustibles WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury or loss of life. CAUTION: This appliance is designed for use in any masonry or factory-built, wood-burning fireplace. It cannot be enclosed by combustible material and used as a factory built gas fireplace (zero clearance fireplace). -
Page 16: Hearth Clearances
Installation 10.3 Hearth Clearances WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance 16” may result in property damage or personal injury. Non Combustible Any hearth that extends outward in front of the insert must not have any combustible material closer than 3" (76.2 mm) to the bottom Zone of the gas fireplace insert regardless of whether a noncombustible material covers the combustible material. -
Page 17: Heat Sensitive Flooring Materials
Installation 10.4 Heat Sensitive Flooring Materials Ambiance fireplaces are heating products, designed to produce a large amount of radiant and convective heat. The clearances specified above are intended to be minimum clearance distances to combustible materials, however, flooring directly adjacent to the minimum hearth clearances may reach temperatures of up to 180°F (82°C) or higher depending on the installation. -
Page 18: Gas Connections
2 psi dry gas meter the unit will rate lower as the calculation has to correct for the higher pressure in the meter. If the unit is over- rated, contact your authorized Archgard dealer. The following calculation equation gives a rough estimation as it does not correct for temperature and pressure. -
Page 19: Conversion Kit Instructions
Installation 12.0 Conversion Kit Instructions IMPORTANT: This fireplace is Natural gas ready. If converting to LP gas, follow instructions below. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or productions of carbon monoxide may result, causing property damage, personal injury or loss of life. -
Page 20: Convert The Gas Valve
Installation 12.3 Convert the Gas Valve WARNING: Installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. Verify that the following items are present in the package: • Pressure regulator assembly (E) • Two (2) screws (F) •... -
Page 21: Venting Instructions
Installation 13.0 Venting Instructions WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. The appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. -
Page 22: Approved Terminations
Installation 13.1 Approved Terminations The following Archgard venting components are available from your local Archgard dealer. Archgard Venting Components Vent Component Part Number Vertical Termination 999-INS-TK 3" x 30' Aluminum Flex Liner 999-INS-FL330 3" x 50' Aluminum Flex Liner 999-INS-FL350... - Page 23 Installation Third Party Venting Components Selkirk Duravent Amerivent 3" Flex (10ft) 95270310 AFE10-03 3ALKE10 3" Flex (25ft) 95270325 AF3-25L 3DFA-25 1730250 3" Flex (30ft) 95270330 3" Flex (35ft) 95270335 AF3-35L 3DFA-35 TC-3AL35 1730350 3" Flex (50ft) 95270350 AF3-50L TC-3AL50 3ALKE50 3"...
-
Page 24: Min/Max Vent Run
Installation 13.2 Min/Max Vent Run Instructions for installing venting and terminations (see list for approved venting and terminations). Install the termination cap being sure to provide sufficient space (around and on top) so you do not impede the flow of air, both into and out of the cap. -
Page 25: Using A Co-Linear To Coaxial Adapter
Installation 13.3 Using a Co-linear to Coaxial Adapter (Partial Length) The gas fireplace can be converted from co-linear to coaxial when it is desired to remove a section of the masonry or certified solid fuel burning fireplace chimney to below the roof line. The following image shows removal to the ceiling. WARNING This appliance must be installed by a qualified gas appliance installer. -
Page 26: General Information
General Information (Full Length) The gas fireplace can be converted from co-linear to coaxial when it is desired to remove a section of the masonry or certified solid fuel burning fireplace chimney to below the roof line. The following image shows removal to the top of the fireplace. WARNING This appliance must be installed by a qualified gas appliance installer. -
Page 27: Barrier Screen Installation
Installation 14.0 Barrier Screen Installation If barrier becomes damaged, the barrier shall be replaced with the manufacturer's barrier for this appliance (Part Number: 27-BS). Screen Top Screen Top WARNING DOOR MUST BE INSTALLED PRIOR TO SCREEN INSTALLATION TO AVOID POSSIBLE DAMAGE OR INJURY. Screen Bottom Screen Bottom Retainer Tabs... -
Page 28: Glass Door Installation
Push the finger rings back. Figure 15.0.01: Figure 15.0.02: 15.1 If Your Glass Breaks In the event your glass cracks or breaks, replace the original door assembly with Archgard replacement door assembly. • Remove the barrier screen (See Section 14.0) •... -
Page 29: Surround Installation
Installation 16.0 Surround Installation Surround options available depend on the control panel configuration (see Section 6.2). Shallow surround options are not available for a installations using the ‘Controls Out’ configuration. Ensure the gas and electrical lines are properly connected to the appliance. -
Page 30: Surround Dimensions
Installation 16.1 Surround Dimensions Figure 16.1.01: Three Sided Surrounds 27-SKSBS-2 27-SKSBD-2 27-SKLBS-2 27-SKLBD-2 Small Shallow Small Deep Large Shallow Large Deep 10.399" [26.41 cm] 10.399" [26.41 cm] 39.452" [100.21 cm] 45" [114.3 cm] 24.161" [61.37 cm] 28" [71.12 cm] 1" [2.54 cm] 2.5"... -
Page 31: Trimmable Surround Dimensions
Installation 16.2 Trimmable Surround Dimensions Top View 2.769in 2.769in 2.769in 2,769in [7.03 cm] Front View 47.000in [119.38 cm] 47.000in 47.000in Side View 47.000 po 10.660in [7.03 cm] [27.08 cm] 10.660in 10.660in 10.66in 2.769in 2.769in 2.769in [5.92 cm] 2.331in 2.331in 2.331in [7.24 cm] [26.1 cm] 2.849in... -
Page 32: Dimensions Of Fronts
Installation 16.3 Dimensions of Fronts Mission Hills Fronts 27-MHIFSSDBS-2 27-MHIFSSDBD-2 5.726" ( 14.54 cm) 5.5" (13.97 cm) 39.452" (100.21 cm) 24.161" (61.37 cm) 1.5" (3.81 cm) 2.5" (6.35 cm) 2.769" (7.03 cm) 2.312" (5.87 cm) Figure 16.3.01: Mission Hills Front Harrison Mills Fronts 27-SDSHMBS-2 27-SDSHMBD-2... -
Page 33: Decorative Trim Dimensions
Installation 16.4 Decorative Trim Dimensions 79.33cm 31.231in 6.35cm 2.500in 50.93cm 20.052in 6.35cm 2.500in Figure 16.4.01: 79.33cm 31.231in 6.35cm 2.500in 6.35cm 2.500in 6.35cm 2.500in Figure 16.4.02:... -
Page 34: Decorative Plinth Dimensions
Installation 16.5 Decorative Plinth Dimensions Small Plinths For use with 27-SKSBS or 27-SKSBD 2" 27-DPSS2 5.08 cm 4" 39.952" 1.25" 2.539" 27-DPSS4 10.16 cm 101.48 cm 3.18 cm 6.45 cm 6" 27-DPSS6 15.24 cm 2" 27-DPSD2 5.08 cm 4" 39.952" 2.75"... -
Page 35: Firebox Liner Installation
The following steps highlight the procedure for installing brick panel firebox liners. Handle the panels with care as they are delicate. Inspect the panels to ensure that no damage has occurred inside the package. Please report any damage immediately to your Authorized Archgard Dealer. Before you begin: •... - Page 36 Installation Step 4: Slide the REAR PANEL in behind the side panel that was NOTE: the tabs will bend with hand pressure, however, using pliers will give a sharper bend. installed in Step 2. For the left side, start with the clip in this position. Bend baffle tab upwards to 90 Bend Panel tab...
-
Page 37: Media Installation
18.1 Log Set The Archgard pan burner bed and fiber logs are designed to give a realistic fire package, and created to look the same as the day they were originally installed. Care must be given when first installing the logs, and if removed for servicing, as they can be damaged or broken if not handled properly. - Page 38 Installation Log #1: Locate Log 1 and align the holes in the bottom line up with the two locater pins. Push down firmly onto locater pins. Figure 18.1.02: Log #2: Locate log #2 using the locator pin on the burner for the left side. Sit the right side of the log into the notch of log #1 (as shown in inset).
- Page 39 Installation Log #4: Locate Log #4 and align the two holes in the log with the two locater pins in the center of the burner. Push down onto locator pins as shown. Figure 18.1.05: Log #5: Locate Log #6 and align the hole in the bottom with the locater pin in the burner. Place the other end of the log in the locator pin of log #2.
-
Page 40: Ember Placement
Installation NOTE Logs #1, #3 and #4 have been crafted to allow airflow from under the logs. DO NOT crush the bottom of the logs to make these sit flush with the top of the burner. Care must also be taken to not completely block the front of the logs with embers. Figure 18.1.08: 18.2 Ember Placement Place black embers around logs as shown, do not completely block the holes in the burner. - Page 41 Installation Platinum Ember Placement Platinum embers provide a brighter glow than the black embers. When using a mixture of both the firebox will be filled with a naturalistic glow. Note: DO NOT block burner openings with platinum embers or any other material. Step 1: Remove embers from the bag.
-
Page 42: Complete Log Set
Installation 18.3 Complete Log Set Log 6 Log 2 Log 1 Log 3 Log 5 Log 4 Figure 18.3.01: Item # Item Description Unit 310-6270 Complete Log Set 310-6270-1 Log 1 310-6270-2 Log 2 310-6270-3 Log 3 310-6270-4 Log 4 310-6270-5 Log 5 310-6270-6... -
Page 43: Operation
Each Archgard Gas Fireplace is checked and tested at the factory prior to being packaged and shipped to our dealers and finally installed in your home. Brigantia recommends that before leaving this unit with the customer, the installer must ensure that the appliance is firing correctly and that the electrical system is in working order. -
Page 44: Lighting Instructions
Operation 19.3 Lighting Instructions The following information may be found on the fireplace rating plate. See Section 6.1 for the rating plate location. Figure 19.3.01:... -
Page 45: Dynamic Start Advantage
Operation 19.4 Dynamic Start Advantage This fireplace comes standard with the Dynamic Start Advantage. This new electronic ignition system is the latest in fireplace technology. It helps to create a better draft, better flame appearance, less condensation on the glass, and years of carefree operation. How the system works: When starting a solid fuel wood burning fireplace you build a fire. -
Page 46: Remote Control Operation
Operation 19.5 Remote Control Operation IMPORTANT The Proflame II Remote is an integrated part of the Proflame II System, which consists of a Proflame II Remote, to be used in conjunction with Integrated Fireplace Control (Proflame II Control Module). Figure 19.5.01 The Proflame II Remote provides for controlling the following hearth appliance functions: Main Burner ON/OFF Main Burner flame modulation (6 levels) - Page 47 Operation Handheld Remote Display Continuous Pilot on Demand Figure 19.5.02 WARNING THE REMOTE AND RECEIVER ARE RADIO FREQUENCY DEVICES. PLACING THE REMOTE IN OR NEAR METAL ENCLOSURES MAY REDUCE THE SIGNAL RANGE. Handheld Remote (optional) Figure 19.5.03...
- Page 48 Operation Initializing the System for Handheld / Wall Mount Remote Operation Connect IFC Control Module to AC power supply. A single “beep” will indicate the presence of power. NOTE: This will initiate Pilot Start-up in Manual Mode. The pilot will spark repeatedly and ignite if gas has been supplied to the unit. Sync the control board to the remote to turn main burner and pilot off using the steps below.
- Page 49 Operation Temperature Indication Display With the system in the “OFF” position, press the Thermostat Key and the Mode Key at the same time to switch between Fahrenheit (F) or Celsius (C). Verify on the LCD screen the correct designation is visible. Figure 19.5.06: This function is disabled when in SMART Thermostat Mode and does not operate in the first two minutes of Variable Flame Control...
- Page 50 Operation Room Thermostat (Remote Operation) The Remote Control can operate as a room thermostat. The thermostat can be set to a desired temperature to control the comfort level in a room. To activate this function: • Press the Thermostat Key. The LCD display on the remote will change to show that the room thermostat is “ON”...
- Page 51 Operation CPI vs IPI: Continuous Pilot on Demand Ignition (CPI): In this mode the pilot runs continuously even when the main burner is off. The Continuous Pilot on Demand Ignition operates on a seven day cycle. If the main burner is not turned on for seven continuous days, the pilot will turn itself off.
- Page 52 Operation Key Lock This function will lock the keys to avoid unsupervised operation. • To activate this function, press the MODE and UP Keys at the same time • To deactivate this function, press the MODE and UP Keys at the same time Figure 19.5.13: Low Battery Power Detection (Less than 4V) Remote...
-
Page 53: Maintenance
Maintenance 20.0 Maintenance CAUTION: Do not conduct maintenance on the appliance while it is operating or while it is still hot. Always verify proper operation after servicing. 20.1 Cleaning the Appliance The exterior painted surfaces, glass, and metal plated trims may be cleaned with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive cleaner. -
Page 54: Servicing Under Warranty
All service work under warranty must be conducted by a qualified Archgard service technician. Before servicing, read the terms and conditions of the warranty at the back of this manual. Contact the authorized Archgard dealer where you purchased the appliance from and provide them with details of the problem, along with the initial installation information (from the front of this manual). -
Page 55: Adjusting The Primary Air
Replace the fuse with one which has the same specifications using the existing fuse holder. Replace the fuse holder Replace surround and resupply power. Light the fireplace to verify proper operation. Fuse type: T3.15AL250V Archgard Part Number: RP-305-2080 Figure 20.7.01:... -
Page 56: Replacing The Control Board
Maintenance 20.8 Replacing the Control Board CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 57: Replacing The Valve
Maintenance 20.9 Replacing the Valve Before you begin: CAUTION: Label all wires prior to disconnection when • Disconnect power and gas supply to the fireplace. servicing controls. Wiring errors can cause improper and • Ensure the fireplace is off and cool before servicing. dangerous operation. -
Page 58: Replacing The Burner
Maintenance 20.10 Replacing the Burner Before you begin: • Disconnect power and gas supply to the fireplace. • Ensure the fireplace is off and cool before servicing. • Remove the barrier screen and door. • Remove log set and embers. •... -
Page 59: Replacing The Pilot
Maintenance 20.11 Replacing the Pilot CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. - Page 60 Maintenance Clip the zip ties securing the cables. Remove the pilot. Figure 20.11.06: Figure 20.11.05: Remove the burner (see Section 20.10). Remove the (3) screws securing the top of the lower baffle. Figure 20.11.07: Figure 20.11.08: Remove the (2) screws securing the bottom of the lower 10.
- Page 61 Maintenance 11. Remove the (10) 1/4 “ hex head screw securing the access 12. Remove the access cover. cover. Figure 20.11.11: Figure 20.11.12: 13. Thread the wires on the new pilot through the pilot extrusion. 14. Thread the wires through the opening on the bottom right side of the fireplace.
-
Page 62: Replacing The Fan
Maintenance 20.12 Replacing the Fan CAUTION Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 63: To Access From The Back
Maintenance CAUTION Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 64: Wiring Schematic
Maintenance 20.13 Wiring Schematic SW1 Botton(red) Sync button On/Off override jumper Figure 20.13.01... -
Page 65: Troubleshooting
Maintenance 20.14 Troubleshooting Issue Solution The pilot igniter won't spark. 1. Ensure the ON/OFF override jumper is installed correctly. 2. Ensure main power is ON and new batteries are installed in the remote control (3 x AAA) and backup battery pack on the control board (4 x AA). 3. -
Page 66: Frequently Asked Questions
Q. My fan/blower makes a “whirring” or “humming” noise. A. Your Archgard gas appliance uses a powerful fan to push heated air into your room. It is not unusual to hear a “humming” noise when your fan is running. Note: the sound will change depending on the setting that your fan speed control is set at. -
Page 67: Replacement Parts List
Maintenance 22.0 Replacement Parts List Item # Item Description Unit 200-1127-16 Owner’s Manual 200-1127F-15 Owner's Manual (French) 308-6060 SIT Proflame II Dynamic Start Advantage with Continuous Pilot on Demand 308-6024 SIT Pro Flame II Wall Mountable Remote 308-6017 SIT 885 Gas Valve c/w Step Motor 305-6002 Module Main Wiring Harness (5 wire) 305-6003... -
Page 68: Archgard Limited Warranty
“lifetime”. All warranty repairs Any defective part, in our judgment, will be repaired or replaced are to be performed by an authorized Archgard Dealer during the at Archgard’s discretion. The dealer must obtain approval from warranty period. - Page 69 NOTES...
-
Page 70: Warranty Registration
POSTAGE WARRANTY REGISTRATION ARCHGARD INDUSTRIES LTD. PO BOX 318 RAYMOND, AB T0K 2S0 FOLD DOWN AT LINE FOLD DOWN AT LINE & TAPE CLOSED Model # : Serial #: Date Installed: Name: Address: City: State/Prov: ZIP: Phone: ( _____ ) Dealer’s Name &... - Page 71 NOTES...
- Page 72 ARCHGARD INDUSTRIES LTD. 300 RAILWAY AVENUE RAYMOND, AB T0K 2S0 CANADA WWW.ARCHGARD.COM...
