Yale Locks
YRC226/246/256 Z-Wave+ System Integrators Guide
Yale Assure Deadbolt Lock
Document Revision: 1
January 2, 2019
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YRC226 Z-Wave+ and is the answer not in the manual?

Questions and answers

Related Manuals for Assa Abloy YRC226 Z-Wave+

Summary of Contents for Assa Abloy YRC226 Z-Wave+

  • Page 1 Yale Locks YRC226/246/256 Z-Wave+ System Integrators Guide Yale Assure Deadbolt Lock Document Revision: 1 January 2, 2019...

  • Page 2: Table Of Contents

    Contents Yale Z-Wave+ Product Info ........................3 Supported Command Classes ........................3 Association Table ............................ 3 Notifications Table ..........................4 Configurable Parameters ......................... 6...

  • Page 3: Yale Z-Wave+ Product Info

    Yale Z-Wave+ Product Info Manufacturer ID: Assa Abloy (0x0129) Z-Wave Device Type: Door Lock Keypad Z-Wave Role Type: Listening Sleeping Slave (LSS) Product ID: 0x0600 Product Type ID: 0x8002 – YRC226-ZW2/YRC246-ZW2/YRC256-ZW2 (Touch Screen Deadbolt) Supported Command Classes Command Class Z-Wave+ Info...

  • Page 4: Notifications Table

    Notifications Table Alarm Alarm Reports Alarm Level Description type 0x00 Master code was changed at keypad Master Code changed. 0xFB Master code was changed over RF 0x70 0x(01-max User added User added. Alarm level = user slot number users) 0x(01-max User deleted 0x21 User was deleted.
  • Page 5 Power to RFM was restored, sent by RF module. The RF Module Power 0x82 0x00 lock doesn’t send any alarm to the RF module when Cycled power is cycled. Disabled user 0x(01-max 0x83 A disabled user pin code was entered at the keypad entered at keypad users) A valid user can be both a normal user and a Non-...

  • Page 6: Configurable Parameters

    Configurable Parameters Configuration Parameter Size Description Parameters Number Level control, 1 = High Volume, 2 = Low Volume, 3 = Silent mode on/off 1 1 byte Silent. Default is 2 or Low Volume Auto Relock on/off 2 1 byte 0x00 = OFF, 0xFF = ON default is 0x00 or OFF Auto Relock time 3 1 byte 10 to 180 seconds default is 30 seconds...
  • Page 7 Yale Assure Lock ® ® Electronic Interconnected Touchscreen ® Installation and Programming Instructions (YRC226/YRC426/YRC620) Inside Outside of Door of Door 4" Touchscreen Shown - 5.5" Available Network Module Before you begin (Optional - Not available on YRC620) DOWNLOAD THE BILT APP for step-by-step installation instructions &...

  • Page 8: Before You Begin

    Before You Begin Template Network Module (Optional - Not available on YRC620) 1/8" 3/32" 1/8" 1" 2-1/8" 4-1/2" (114) 1-3/8" (35mm) Min to 1-3/4" (44.5mm) Max YRL EMICL TSINSTL FUL Rev G...
  • Page 9 Mark Door Reference Lines EXISTING 2-3/8" or 2-3/4" Backset Template YRL EMICL TSINSTL FUL Rev G...
  • Page 10 Preparing Door (if necessary) Template 4" 5.5" 2-3/8" Ø2-1/8" Ø1" 2-3/4" Drill holes 1/2 way thru door then complete from other side to prevent splitting. YRL EMICL TSINSTL FUL Rev G...
  • Page 11 Installing Strike Plates 7-16 / 8-32 x 1" UNCWS Frame 1" Dia. x 1"Deep Frame Inside of Door 1" Dia. x 1/2"Deep Door Frame YRL EMICL TSINSTL FUL Rev G...
  • Page 12 Determining Handing The hand of a door is determined from the secure side of the door. The term "secure" means the side from which you initially unlock and enter. Left Hand “ ”, Hinges Left. Left Hand Reverse " ", Hinges Left. Open Inward.
  • Page 13 Changing Handing (if necessary) 4" Left Hand to 4" Right Hand Shown 4-24 x 1/4" PPHMS DO NOT TAMPER WITH OR LOOSEN E-CLIP AND ITS ASSEMBLY DO NOT LOOSEN THESE 6 SCREWS OR REMOVE COVER YRL EMICL TSINSTL FUL Rev G...
  • Page 14 Changing Handing (if necessary) continued YRL EMICL TSINSTL FUL Rev G...
  • Page 15 Lockset Handing Configurations For 5.5" For 5.5" For 4" 4" Right Hand For 4" 4" Left Hand Test Lever and Thumbturn After handing is changed, check that lever and thumbturn rotate freely. YRL EMICL TSINSTL FUL Rev G...
  • Page 16 Installing Fire Cups Inside of Door Both Fire Cups and a marked Latchbolt must be used to qualify for listing. YRL EMICL TSINSTL FUL Rev G...
  • Page 17 Adjusting Deadbolt Latch (If adjustable deadbolt latch provided) default 2-3/8" position optional 2-3/4" position Pull Press YRL EMICL TSINSTL FUL Rev G...
  • Page 18 Installing Deadbolt Latch & Latchbolt 7-16 / 8-32 x 1" UNCWS Inside of Door Bolt must be in retracted (unlocked) position before installing. Ensure arrow stamped on deadbolt Choose latchbolt based on backset. (2-3/8" or 2-3/4") Curved edge of latchbolt faces direction door closes.
  • Page 19 Installing Exterior Deadbolt M6x55 PPHMS Bolt must be in retracted (unlocked) position. Inside of Door YRL EMICL TSINSTL FUL Rev G...
  • Page 20 Installing Lock Chassis 10-32 x 1-1/2" PPHMS Inside of Door YRL EMICL TSINSTL FUL Rev G...
  • Page 21 Securing Back Plate to Door #6-32 x 1/2" POHMS Inside of Door Drill two pilot holes Ø1/8" x 1/2" deep #6-32 x 1/2" POHMS screws must be used to qualify for listing. YRL EMICL TSINSTL FUL Rev G...
  • Page 22 Testing Deadbolt & Latchbolt Operation Outside of Door YRL EMICL TSINSTL FUL Rev G...

  • Page 23: Remove Battery Cover

    Remove Battery Cover Loosen screw to remove cover. YRL EMICL TSINSTL FUL Rev G...
  • Page 24 Attaching the Cable Assembly Align wire connectors so that tabs slide into slots. Tug gently on cables to test that connectors are secure. Slot Inside of Door Slot Cable must be routed as shown to avoid interference with movement of lock. YRL EMICL TSINSTL FUL Rev G...
  • Page 25 Installing Interior Lock Orientation must match. Do not fasten lock to back plate until properly fitted. Inside of Door Turn thumbturn to adjust slot orientation. YRL EMICL TSINSTL FUL Rev G...
  • Page 26 Installing Interior Lock continued 10-32 x 5/8" POHMS 6-32 x 1" PPHMS Inside of Door DO NOT LOOSEN THIS SCREW YRL EMICL TSINSTL FUL Rev G...
  • Page 27 Installing Interior Lever Inside of Door " SNAP " Inside of Door Pull lever to ensure it is secure. YRL EMICL TSINSTL FUL Rev G...
  • Page 28 Testing Final Latchbolt Operation Inside of Door Outside of Door YRL EMICL TSINSTL FUL Rev G...
  • Page 29 Testing Final Deadbolt Operation If testing fails, go back to beginning of Step 12 and check installation. YRL EMICL TSINSTL FUL Rev G...
  • Page 30 Installing Optional Network Module (Optional - Not available on YRC620) DO NOT install network module with batteries in unit. Damage may occur. Installing Batteries & Cover "Welcome to ..." Tighten screw to replace cover. Bolt must be in retracted (unlocked) position before installing...
  • Page 31 Handing the Lock AFTER installing batteries and cover AFTER a factory reset, create Master code. See 1 of Programming Instructions. After entering the Master code: Press Advanced Lock Settings Press to Select Press Handing the Lock Press to Select Press to complete Lock will cycle motor to complete handing.

  • Page 32: Hardware Troubleshooting

    Hardware Troubleshooting Cycle lock in both the locked and unlocked positions. If problems are found: Bolt will not extend and motor is grinding a. Enter your Master code. b. With the bolt retracted, press menu Option 3 for Advanced Lock Settings. c.

  • Page 33: Resetting Lock To Factory Default

    Changing Lock: Replacing Cylinder To remove cylinder: A. Remove touchscreen from door. B. Remove pan head screw. C. Remove cylinder by letting it drop out of assembly. Touchscreen shown removed from door. Resetting Lock to Factory Default Interior Lock When resetting the lock, all user codes, including the (4"...

  • Page 34: Programming Instructions

    Programming Instructions Touchscreen "P" Key (Return to Previous) Interior Lock Low Battery Indicator Lockout Mode Privacy Mode Button Speaker Lock Activation Master Code must be created before any further programming. Max User Codes = 250 with Z-Wave Plus or ZigBee network module Max User Codes = 25 without network module or with iM1 network module Max User Codes = 12 with Bluetooth YRL EMICL TSINSTL FUL...
  • Page 35 Creating Master Code Creating a Master Code must be performed upon installation or after resetting the lock to factory default. Programming and use of lock is not possible until this step has been successfully completed. "Register Master Code. Press the gear key to continue."...

  • Page 36: Creating User

    Creating User Codes Master code must be created first. *Max user codes = 250 with Z-Wave or ZigBee network module Max user codes = 25 without network module or with iM1 network module Max user codes = 12 with Bluetooth "Menu Mode, enter number, press the gear key...

  • Page 37: Factory Settings

    Unlocking Door with Code Enter Code Press Factory Settings Factory Setting Settings Registration required* Master Code Automatic Re-lock Disabled Inside Indicator Light Disabled (Off) One Touch Locking Enabled Privacy Button Setting Disabled Volume Setting Enabled (Low) Language Setting English Lockout Mode Disabled Wrong Code Entry Limit 5 Times...
  • Page 38 Definitions All Code Lockout Mode: This feature is enabled by the Master code. When enabled, it restricts all user (except Master) code access. When attempting to enter a code while the unit is in Lockout, the locked padlock will appear on the screen. Automatic Re-lock Time: After a successful unlock, the unit will re-lock automatically after duration selected in the Advanced Lock Settings (Main Menu selection #3).
  • Page 39 Model 226 Feature Programming Through Menu Mode Using Master code* 1. Touch screen with back of hand or palm to activate. 2. Enter 4-8 digit master code* followed by key. Lock Response: "Menu mode, enter number, press key to continue." 3.
  • Page 40 Model 620 Feature Programming Through Menu Mode Using Master code* 1. Touch screen with back of hand or palm to activate. 2. Enter 4-8 digit master code* followed by key. Lock Response: "Menu mode, enter number, press key to continue." 3.

  • Page 41: Programming Troubleshooting

    Programming Troubleshooting Symptom Suggested Action • • • • • • • • • • • • • • • • • • • • • • • • • • • YRL EMICL TSINSTL FUL Rev G...
  • Page 42 Product Support Tel 1-855-213-5841 • www.yalehome.com Yale® ,Yale Real Living® and Assure Lock® are registered trademarks of Assa Abloy Residential Group. Other products' brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only. © Copyright 2018. All rights reserved. Reproduction in whole or in part without the express written permission of Assa Abloy Residential Group is prohibited.
  • Page 43 Yale Z -Wave Plus Module ® ® ® Installation and Programming Instructions Installing the Z -Wave Plus Module ® IMPORTANT: the batteries must be removed prior to removing and/or inserting the network module: • Remove battery cover and batteries. • Remove and/or insert Network Module. •...
  • Page 44 Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company. Yale® and Yale Real Living® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group Company. Other products’ brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only.
  • Page 45 Yale ZigBee Module ® ® ® Installation and Programming Instructions Installing the ZigBee Module ® IMPORTANT: the batteries must be removed prior to removing and/or inserting the network module: • Remove battery cover. • Remove batteries. • Remove and/or insert network module. •...
  • Page 46 Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company. Yale® and Yale Real Living® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group Company. Other products’ brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only.
  • Page 47 Yale iM1 Network Module ® ® Installation and Programming Instructions Installing the Yale iM1 Network Module IMPORTANT: the batteries must be removed prior to removing and/or inserting the network module: • Remove battery cover and batteries. • Remove and/or insert Network Module. •...
  • Page 48 Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company. Yale®, Yale Real Living® and Assure Lock® are registered trademarks of Yale Security Inc., an ASSA ABLOY Group Company. nexTouch™ is a trademark of Yale Security Inc., an ASSA ABLOY Group Company.
  • Page 49 Yale Z-Wave Plus Smart Module ® ® ® Installation Guide Please use this procedure only when network primary controller is missing or otherwise inoperable. Adding a Yale Z-Wave Plus Smart Module to your Assure Lock & Z-Wave System ® 1. Install the Yale Smart Module into the slot above the battery compartment IMPORTANT: The batteries must be removed before removing the Yale Smart Module: •...
  • Page 50 CAN ICES-3B/NMB-3B 24/7 Tech Support : 1-855-492-0505 • www.yalehome.com Yale® is a registered trademark of ASSA ABLOY Residential Group. Other products' brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only. © Copyright 2019. All rights reserved. Reproduction in whole or in part without the...
