Teltonika FTC880 Quick Manual

Teltonika FTC880 Quick Manual

Easy ip69k tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FTC880
Easy IP69K tracker
Quick Manual v1.2 | 2025-06-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTC880 and is the answer not in the manual?

Questions and answers

Related Manuals for Teltonika FTC880

Summary of Contents for Teltonika FTC880

  • Page 1 FTC880 Easy IP69K tracker Quick Manual v1.2 | 2025-06-09...

  • Page 2: Table Of Contents

    CONTENTS Glossary � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3 Configuration (Windows) �...

  • Page 3: Glossary

    GLOSSARY CEP – Circular Error Probable: a statistical statistical NITZ – Network Identity and Time Zone: a mechanism in measure used to describe the accuracy of a positioning GSM, used to provision time, date and other parameters to system, commonly used in the context of GNSS� CEP mobile devices in a network�...

  • Page 4: Safety Information

    This section contains information on how to operate — The device uses a 10 V���30 V DC power supply� The FTC880 safely. By following these requirements and nominal voltage is 12 V DC� The allowed range of recommendations, you will avoid dangerous situations� You voltage is 10 V���30 V DC�...
  • Page 5 In accordance with the General Data Protection Regulation (GDPR), this Data Processing Agreement (DPA) establishes obligations between Teltonika, the data processor, and its The programming must be performed using a PC customers, acting as data controllers. The DPA outlines with autonomic power supply�...

  • Page 6: Know Your Device

    KNOW YOUR DEVICE Top view FTC880 Top view (without cover) 1� GSM antenna 2� GNSS antenna 3� SIM slot Bottom view (without cover) 4� USB Type-C connector 5� Battery socket 6� Navigate LED (Blue LED) 7� Status LED (White LED)

  • Page 7: Set Up Your Device

    SET UP YOUR DEVICE 1� Cover removal 2. Nano-SIM card insert You will receive your device partly closed� Gently remove Insert SIM card as shown� side cover� Make sure Nano-SIM card cut- off corner is pointing towards SIM slot� 3. Attaching cover back 4�...

  • Page 8: Pinout

    PINOUT PIN1 PIN2 Pin name Description number VCC (10-30)V (Red) Power supply (+10-30 V DC) DC (+) GND (-) (Black) Ground...

  • Page 9: Pc Connection (Windows)

    PC CONNECTION (WINDOWS) CONFIGURATION (WINDOWS) 1� Power-up FTC880 with DC voltage (10-30V) power Most Teltonika devices are shipped with default factory settings.Use Telematics Configuration Tool (TCT) to change supply using power wires� LEDs should start blinking� these settings according to your needs.

  • Page 10: Quick Sms Configuration

    « setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0» Before SMS text, one space symbol should be inserted� This space is dedicated for device SMS password� GPRS SETTINGS: Teltonika Tracker 2001 – APN 2002 – APN username (leave field empty if there is no setparam 2001;internet; 2002:internet1;2003:internet2;...
  • Page 11 (if device has made is off a record) After successful SMS configuration, FTC880 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using SMS parameters �...

  • Page 12: Mounting Recommendations

    MOUNTING RECOMMENDATIONS DEVICE FASTENING — Locate the battery in your vehicle� If present remove the battery cover to access the battery� — There is a double sided tape on the back of the device, use it to attach the device on the battery, so that the GNSS antenna and LEDs indicators are facing up�...

  • Page 13: Troubleshooting

    Description on success? on failure? Troubleshooting section provides guidance to resolve frequently encountered issues during the setup and Restarts the cpureset operational phases of the FTC880 device. device Returns status COMMON ISSUES AND SOLUTIONS (FAQ) getstatus of the device Returns...

  • Page 14: Led Indications

    LED INDICATIONS BASIC CHARACTERISTICS NAVIGATION LED Module FTC880-QJAB0: Quectel EG915U-EU with Behaviour Meaning Name AG3335 Permanently switched GNSS signal is not received Technology LTE CAT 1/GSM/GPRS/GNSS GNSS Blinking every second Normal mode, GNSS is working GNSS is turned off because:...
  • Page 15 LTE FDD (CAT 1): Max. 10 Mbps (DL) / Max. Nano-SIM 5 Mbps (UL) Data transfer GSM (GPRS): Max. 85.6 Kbps (DL) / Max. Memory 128MB internal flash memory 85.6 Kbps (UL) Physical Specification Class 5 for GSM850/900: 30±5dBM Transmit power Class 3 for GSM1800/1900: 29±5dBM Class 3 for LTE-FDD: 26±5dBM Dimensions...
  • Page 16 Auto geofence, Towing detection, Static navigation, Custom scenarios Deep Sleep, Online Deep Sleep, Power Sleep modes Off Sleep Configuration and FOTA WEB, Teltonika Configuration Tool firmware update (TCT) Time Synchronization GNSS, NITZ, NTP Ignition detection Accelerometer, External Power Voltage...

  • Page 17: Certification And Approvals

    Full User‘s Manual version can be found in our Wiki The Australian Standard AS/NZS 4417.1 and AS/NZS 4417.2 Hereby, Teltonika declare under our sole responsibility Marking of electrical products to indicate compliance with that the above described product is in conformity with the regulations –...

  • Page 18: Company Details

    Teltonika Wiki� Copyright © 2025, Teltonika� Specifications and information given in this document are subject to change by Teltonika without prior notice�...
