Teltonika FTC921 First Start-Up Quick Start Manual

Small and smart tracker

Hide thumbs Also See for FTC921:

https://wiki.teltonika-gps.com/view/FTC921_First_Start

FTC921 First Start

FTC921

> FTC921 First Start

Small and smart tracker

Contents

1 HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY

HOW TO INSERT MICRO-SIM CARD AND CONNECT THE

BATTERY

Gently remove FTC921 cover using plastic pry tool from one side.

Gently remove FTC921 cover using plastic pry tool from another side.

Insert Nano-SIM card as shown. Make sure that Nano-SIM card cut-off corner is pointing

forward to slot.

Connect the battery as shown on device. Position the battery in place where it does not

obstruct other components.

Attach device cover back. Device is ready to be connected.

Nano-SIM card insertion/removal must be performed when device is powered off –

external voltage and internal battery disconnected. Otherwise Nano-SIM card might be

damaged or device will not detect it.

PC CONNECTION (WINDOWS)

1. Power- up FTC921 with DC voltage (10-90V) power supply using power wires. LEDs should start

blinking.

2. Connect device to computer using Micro-USB cable and install USB driver, see "How to install

USB drivers (Windows)1"

Table of Contents

Do you have a question about the FTC921 and is the answer not in the manual?

Page 1 PC CONNECTION (WINDOWS) 1. Power- up FTC921 with DC voltage (10-90V) power supply using power wires. LEDs should start blinking. 2. Connect device to computer using Micro-USB cable and install USB driver, see “How to install...
Page 2 5. Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. CONFIGURATION (WINDOWS) At first FTC921 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator tool (TCT).
