- Page 1 FTC881 Special and small waterproof tracker Quick Manual v1.0...
-
Page 2: Table Of Contents
CONTENT Know your device ........................................3 Pinout ...........................................4 Set up your device ......................................5 PC Connection (Windows) ....................................6 How to install USB drivers (Windows) ................................6 Configuration (Windows) ....................................7 Mounting recommendations.....................................8 Safety information ......................................9 Quick Manual v1.0 // FTC881... -
Page 3: Know Your Device
KNOW YOUR DEVICE BOTTOM VIEW (WITHOUT COVER) TOP VIEW (WITHOUT COVER) TOP VIEW BATTERY NAVIGATE GNSS SOCKET ANTENA STATUS SLOT Quick Manual v1.0 // FTC881... -
Page 4: Pinout
PINOUT PIN1 PIN2 PIN NUMBER PIN NAME DESCRIPTION VCC (10-70)V DC (Red) Power supply (+10- 70 V DC) GND (-) (Black) Ground FTC881 pinout Quick Manual v1.0 // FTC881... -
Page 5: Set Up Your Device
SET UP YOUR DEVICE HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY COVER REMOVAL COVER REMOVAL SIM CARD INSERT You will receivyour device partly closed. Gently remove side cover. Insert SIM card as shown. Make sure Nano-SIM card cut-off corner is pointing towards SIM slot. -
Page 6: Pc Connection (Windows)
Extract and run TeltonikaCOMDriver.exe. Click Next in driver installation window. In the following window click Install button. Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. wiki.teltonika-gps.com/images/d/d0/TeltonikaCOMDriver.zip Quick Manual v1.0 // FTC881... -
Page 7: Configuration (Windows)
CONFIGURATION (WINDOWS) At first FTC881 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator tool (TCT). wiki.teltonika-gps.com/view/QSG_New_platform MS .NET REQUIREMENTS Operating system MS .NET Framework version... -
Page 8: Mounting Recommendations
MOUNTING RECOMMENDATIONS DEVICE FASTENING • Locate the battery in your vehicle. If present remove the battery cover to access the battery. • There is a double sided tape on the back of the device, use it to attach the device on the battery, so that the GNSS antenna and LEDs indicators are facing up. -
Page 9: Safety Information
SAFETY INFORMATION Do not disassemble the device. If the device is damaged, the power supply cables are not isolated or the isolation is damaged, DO NOT touch the device before unplugging the power supply. This message contains information on how to operate FTC881 All wireless data transferring devices produce safely.
